- Page 1 User Guide GT eSports Racing Wheel...
- Page 2 Due to continuous improvement, the actual product may differ from the manual. This manual is for reference only.
-
Page 3: Safety Notice
Safety notice Please read the Manual carefully before you use the racing wheel. Please do not open the racing wheel, otherwise the supplier will not afford warranty service. This product does not have waterproof function, please keep it away from rain, moisture and other items containing liquid such as vape, cup and so forth. -
Page 4: Interface Introduction
Interface introduction... -
Page 5: Interface Notes
Interface notes 1 - 2 and 3 - 4 two way toggles and 15 - 22 integrated warning leds (as well as backlit buttons) are present only on GT-PRO spec wheels. To use the POV switch (up, down, left, right) you are supposed to just gently move the joystick knob into the desired direction. -
Page 6: Usb Connection
USB connection Alignment key Connect the steering wheel to your PC by only using the provided cable. Please note that the wheel connector it’s keyed as the picture on the right, so it fits only one way. Once the plug it’s correctly seated into the body receptacle, secure it by turning the retaining ring as next picture. - Page 7 Paddle shifters calibration Introduction: Although all the racing wheels are already tested and should work correctly straight out the box, you might need to adjust the shifter sensor activation point for a correct use on your setup. If the paddles are already set correct- ly, you may skip these steps.
- Page 8 onnect the steering wheel to your PC Connect the racing wheel to your PC with the provided coiled USB cable, wait for your computer to recognize the device and in Control Panel, access the Game Controllers window.
- Page 9 Select your wheel Select your Cube Controls GT Wheel from the list and open the properties panel. You should now see a window that displays all your steering wheels buttons:...
- Page 10 Adjusting the trimmers Carefully place a small philips screwdriver inside the screw hole leaved by the screw you removed in the previous step, and move it slightly until it engages the trimmer. It sits around 10mm below the surface of the main body. There is one trimmer for each right (upshift) and left (downshift) paddles.
-
Page 11: Wheel Installation
Wheel installation Our universal hub on the back of the wheel body allows the user to install various adapter, or even connect it directly to your FFB base. Highlighted in blue the M5x0.8 metric holes. In gray, 5,5mm through holes. Both of them are available in 70mm or 50.8mm bolt pattern. - Page 12 Paddle shifters adjustment Paddle shifters can be easily adjusted to better suit your hand size and driving preferences. T10 drive needed. Length can be adjusted by slightly loosening the two screws highlighted in the right picture, and sliding forward/backwards the carbon paddle.
-
Page 13: Useful Tips
Make sure your rig is grounded correctly. Main wheel body and hub are connected to the wheel own USB ground. Each wheel comes with an auxiliary USB connector that comes out from the main hub. This will be used with our Cube Controls quick release kit. - Page 14 Shifters maintenance If lubricant dries up you might experience the paddle shifter not coming back to its original position freely. Once a year it’s highly recom- mended to put a really small drop of lubricant (sewing machine oil or similar) on the points as the drawing on the right indicates, just where the lever body touches the base of the shifter when...
- Page 15 Notes...
- Page 16 hello@cubecontrols.com...
