Pneumatic Construction Tools
This document summarizes the maintenance and service operations for the range of
Pneumatic Construction Tools.
Please use the links below to navigate to your product.
Chipping Hammers
IR2PS, IR3PS, IR5PS
Pickhammers standard
IR9PS, IR12PS
Pickhammers vibration dampened
IR10PV, IR12PV
Paving Breakers
IR15, IR21, IR30, IR40 BV&BS
Jackhammers
IR17 JS&JV
IR23 JS&JV
Doosan purchased Bobcat Company from Ingersoll-Rand Company in
2007. Any reference to Ingersoll-Rand Company or use of trademarks,
service marks, logos, or other proprietary identifying marks belonging
to Ingersoll-Rand Company in this manual is historical or nominative
in nature, and is not meant to suggest a current affiliation between
Ingersoll-Rand Company and Doosan Company or the products of
either.
Revised (10-12)
Maintenance and service operations
