Summary of Contents for Ingersoll-Rand IR10PV
- Page 1 OPERATION AND MAINTENANCE IR10PV AND IR12PV SERIAL NO: CZ02G00001 This manual contains important safety information and must be made available to personnel who operate and CPN: 85042927 maintain this machine DATE: 07/2002...
- Page 2 Ingersoll-Rand dis trib u tor au tho rised to sell the type 1. The original air end is returned as sem bled and all of equipment in volved or oth er es tab lish ment au tho rised orig i nal seals are intact.
- Page 3 In such cases, the design specifi cation of this machine has been certifi ed as complying with EC directives. Any modifi ca- tion to any part is absolutely prohibited and would result in the CE cer ti fi ca tion and marking being rendered invalid. A declaration of that conformity follows: IR10PV and IR12PV 1-7-2002 1-7-2002...
-
Page 4: Using The Tool
NOTICE IR10PV and IR12PV Pick Hammers are designed for the disintegration of low to medium strength materials (e. g. concrete, masonry bituminous as phalt etc). The tool is intended for vertical or inclined down ward break ing. Ingersoll – Rand is not responsible for customer mod i fi ca tions of tools for applications on which Ingersoll – Rand was not consulted. -
Page 5: Warning Label Identification
WARNING LABEL IDENTIFICATION WARNING FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY. WARNING WARNING WARNING Always wear eye protection Always wear hearing Always turn off the air when operating or perfoming protection when operating supply and disconnect the air maintenance on this tool. -
Page 6: Operation
PLACING TOOL IN SERVICE LUBRICATION OPERATION Accessory Installation WARNING Protec Engine Oil Always use an air line lubricator with these tools. We Always turn off the air supply and disconnect the air rec om mend the following Lubricator– supply hose before installing, re mov ing or ad just ing Unit and Lubricant: any accessory on this tool or before performing any maintenance on this tool. - Page 7 DISASSEMBLING THE IR10PV AND IR12PV PICKHAMMERS GENERAL INSTRUCTIONS CYLINDER DISASSEMBLY • Clean the Pickhammer outer surface. Note: The cylinder assembly should not be disassem- • Do not disassemble the pickhammer any further than bled unless there is evidence of excessive wear of the necessary to replace or repair damaged or worn parts.
-
Page 8: Main Assembly
ASSEMBLY OF THE IR10PV AND IR12PV PICKHAMMERS GENERAL INSTRUCTIONS · Before assembly of the breaker, clean all parts thoroughly Lower the cylinder nut (11) onto the handle and cylinder and lubricate surfaces with a thin fi lm of recommended assembly, engage the handle threads of the nut and tighten oil –... - Page 12 Ingersoll – Rand Company Ingersoll – Rand Company Ltd Portable Power Division P.O. Box 868 Portable Power Division 501 Sandford Avenue Swan Lane Mocksville, Hindley Green North Carolina 27028 Wigan WN2 4EZ United Kingdom www.portablepower.irco.com...
