BaseStation 3200 Irrigation Controller
Setting Up Water Source Priorities
With Baseline's BaseStation 3200 irrigation controller, you can use water from multiple sources to run
your irrigation programs. When an irrigation system is connected to multiple water sources, the water
manager usually wants to use the water from each source in a prioritized manner – typically based on
the cost of the water from each source.
The BaseStation 3200 controller supports 8 water sources. If you have control points (with flow devices
and master valves) associated with each water source, the controller can manage each one
independently based on the priorities that you set up.
In order to draw water from separate sources based on priority, your piping structure must be designed
so that your separate water sources feed into the mainline where your valves are attached and you
must have a flow device such as Baseline's BHM series hydrometer with a normally closed master valve
assigned to the control point.
The BaseStation 3200 controller accommodates many ways of configuring water sources, control points,
and mainlines.
You can also configure the BaseStation 3200 irrigation controller to shut down watering based on the
amount water left in a reservoir. Refer to the following documents:
BaseStation 3200 – Stop Watering Based on a Water Source Empty Condition
BaseStation 3200 – Shutting Down Irrigation Due to Low Water in a Pond or Cistern
Overview of the Steps for Setting Up Water Source Priorities
Step 1 – Install the flow devices.
Step 2 – Search for and assign the flow devices.
Step 3 – Search for and assign the master valves.
Step 4 – Assign the master valves and flow devices to the control points.
Step 5 – Set up your control points.
Step 6 – Set up and prioritize your water sources.
Step 7 – Assign water sources to the downstream hydraulic components.
Step 8 – Assign zones to their appropriate mainlines.
Step 9 – Consider the mainline operating limits.
Baseline Support: 866-294-5847
1
www.baselinesystems.com
