Resolution in pixels and their common designation:
Connectivity with Janet Videoconferencing Switching Service (JVCSS)
The HDX connected to the Codian MCU using H.264 Video and G.722.1 audio in
both directions. It interoperated successfully also negotiating 720p resolution on
the H.239 channel.
Received audio level was measured as peaking to -4dBm.
Procedure for making a call
1. Press the Call button on the remote control
2. Select connection speed
3. Input IP address or E.164 number
4. Press the Call button again.
Local Contacts Directory and Recent Call list are also available from the user
interface.
1920 x 1080 1080p
1280 x 720
720p
1024 x 576
W4CIF
704 x 576
4CIF
576 x 448
448p
512 x 288
WCIF
352 x 288
CIF
352 x 240
SIF
320 x 240
QVGA
13
