- Page 1 CPCV5 Series Hardware Manual CPCV5-070PR/CPCV5-070WR CPCV5-102BR/CPCV5-101BR [한국어 / ENGLISH] [Version 1.5] COMFILE Technology, Inc.
- Page 2 DC+12V Power <15W (1.2A@DC12V) <15W (1.2A@DC12V) <17W (1.4A@DC12V) <17W (1.4A@DC12V) Consumption Weight 1.14Kg 1.0Kg 1.52Kg 1.52Kg Storage C ~ 80 C ~ 60 Temperature Operating C ~ 60 C ~ 50 Temperature COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 3 COM2 단자. (RS232C 신호, D-SUB 9Pin Male Type) 외부 스위치와 연결할 수 있는 커넥터이며, ATX Power S/W 와 동일 Ext. Power S/W 한 기능을 함 ATX Power S/W ATX 모드 파워 스위치이며, 시스템 부팅 및 종료시킬 수 있음 COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
-
Page 4: Adc Input
COM2 단자. (RS232C 신호, D-SUB 9Pin Male Type) 외부 스위치와 연결할 수 있는 커넥터이며, ATX Power S/W 와 동일 Ext. Power S/W 한 기능을 함 ATX Power S/W ATX 모드 파워 스위치이며, 시스템 부팅 및 종료시킬 수 있음 COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page... - Page 5 LAN2 Port Gigabit Ethernet 포트이며, RJ-45 타입의 커넥터 사용. LAN1 Port Gigabit Ethernet 포트이며, RJ-45 타입의 커넥터 사용. USB Port USB1/USB2 단자이며, USB2.0을 지원함. DC INPUT ø2.5 Adaptor 입력 커넥터. (DC +12V) COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 6 CPCV5 Hardware Manual CPCV5 Manual 3. 외형 치수 [CPCV5-070PR] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 7 CPCV5 Hardware Manual CPCV5 Manual [CPCV5-070WR] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 8 CPCV5 Hardware Manual CPCV5 Manual [CPCV5-102BR] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 9 CPCV5 Hardware Manual CPCV5 Manual [CPCV5-101BR] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
-
Page 10: Panel Cutout
X: Panel Cutout Width, Y: Panel Cutout Height, T: Panel Thickness Unit: mm[in.] CUPC CPCV5-070PR [6.06] [3.62] (open frame type) 1.6 to 5.0 CPCV5-070WR [7.36] [4.88] [0.06 to 0.20] CPCV5-102BR / 1.6 to 5.0 CPCV5-101BR [10.43] [5.98] [0.06 to 0.20] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page... - Page 11 CPCV5 Hardware Manual CPCV5 Manual 외형치수 및 판넬 컷 ▌ [CPCV5-070PR] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 12 CPCV5 Hardware Manual CPCV5 Manual [CPCV5-070WR] [CPCV5-102BR/CPCV5-101BR] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 13 3. 전면 판넬 뒤쪽에서 고정장치의 후크를 CPCV5 고정 홈에 아래 그림처럼 걸어서 뒤로 잡아 당깁니다. 4. 마지막으로 고정장치를 드라이버로 볼팅하여 판넬에 고정시킵니다. (이때 너무 세게 볼팅하면 제품이 손상될 수 있으므로 주의하십시오. 적당히 조여도 고정 됩니다.) 5. 나머지 고정장치도 위와 같이 반복하여 모두 고정시킵니다. [CPCV5-102BR/CPCV5-101BR] [CPCV5-070WR] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 14 RS232C Mode (COM1/COM2) RS485 (COM1) RS422 (COM1) Name Name Name Name Name Name DATA- DATA+ *주의 : RS422/RS485모드는 COM1 Port만 지원됨. BIOS내에 COM1 설정 ‘Transmission Mode Select’를 사용자가 원하는 모드로 변경해 줘야 함. COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 15 * ø 2.5 Adaptor Jack 배선 시 주의사항 - 배선 작업 이전에 본 제품 및 외부전원이 꺼져 있는지 반드시 확인하여 주십시오. - 제품에 전원을 인가하기 전에 정격전압 및 배선상태가 맞는지 확인하여 주십시오. COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 16 CPCV5 Hardware Manual CPCV5 Manual 7. 전자파 인증 ► CPCV5-070PR: CPCV5-070PR KCC Registration No. : MSIP-REM-CUL-CPCV5-070PR ► CPCV5-102BR: CPCV5-102BR KCC Registration No. : MSIP-REM-CUL-CPCV5-102BR ► CPCV5-101BR: TDB ► CPCV5-070WR: TDB COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 17 CPCV5에 대한 추가적인 정보가 필요하시거나 문의사항이 있으시면, 언제든지 당사 사이트를 방문하여 도움을 받으시길 바랍니다. 회 사 명 : 컴파일 테크놀로지㈜ 주 소 : 서울특별시 구로구 구로5동 104-5 홈페이지 : http://www.comfile.co.kr 전화번호 : 02-711-2592, 팩스번호: 02-711-2593 COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
-
Page 18: Hardware Specification
DC+12V Power <15W (1.2A@DC12V) <15W (1.2A@DC12V) <17W (1.4A@DC12V) <17W (1.4A@DC12V) Consumption Weight 1.14Kg 1.0Kg 1.52Kg 1.52Kg Storage C ~ 80 C ~ 60 Temperature Operating C ~ 60 C ~ 50 Temperature COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page... -
Page 19: External Parts
COM2 (RS232C, D-SUB 9Pin Male Type) The connector which can be linked to external switch. Ext. Power S/W Same function with ATX Power S/W. ATX Power S/W ATX mode power switch. Boot or exit the system. COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page... - Page 20 COM2 (RS232C, D-SUB 9Pin Male Type) The connector which can be linked to external switch. Ext. Power S/W Same function with ATX Power S/W. ATX Power S/W ATX mode power switch. Boot or exit the system. COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 21 DVI output for external monitor. LAN2 Port Support Gigabit LAN, with RJ-45 type connector. LAN1 Port Support Gigabit LAN, with RJ-45 type connector. USB Port USB1/USB2 (USB2.0). DC INPUT ø2.5 Adaptor Input Connector (DC +12V). COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 22 CPCV5 Hardware Manual CPCV5 Manual 3. Dimensions [CPCV5-070PR] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 23 CPCV5 Hardware Manual CPCV5 Manual [CPCV5-070WR] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 24 CPCV5 Hardware Manual CPCV5 Manual [CPCV5-102BR] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 25 CPCV5 Hardware Manual CPCV5 Manual [CPCV5-101BR] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 26 X: Panel Cutout Width, Y: Panel Cutout Height, T: Panel Thickness Unit: mm[in.] Model Name CPCV5-070PR [6.06] [3.62] (open frame type) 1.6 to 5.0 CPCV5-070WR [7.36] [4.88] [0.06 to 0.20] 1.6 to 5.0 CPCV5-102BR/ CPCV5-101BR [10.43] [5.98] [0.06 to 0.20] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 27 CPCV5 Hardware Manual CPCV5 Manual Bezel Size & Installation ▌ [CPCV5-070PR] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
- Page 28 CPCV5 Hardware Manual CPCV5 Manual [CPCV5-070WR] [CPCV5-102BR/CPCV5-101BR] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
-
Page 29: Bracket Installation
4. Tighten the bolt against the panel to secure the CPCV5 to the panel. (Be careful not to tighten the bolts too tightly, or the CPCV5 could be damaged.) 5. Repeat steps 3 and 4 for each mounting bracket. [CPCV5-102BR/CPCV5-101BR] [CPCV5-070WR] COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page... -
Page 30: Input/Output Connectors
Name Name Name Name Name Name DATA- DATA+ *Notice : RS422/RS485 function is supported by COM1 Port only. User also needs to go to BIOS to set ‘Transmission Mode Select’ for COM1 COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page... - Page 31 CPCV5 Hardware Manual CPCV5 Manual Power Input Connector ▌ * ø 2.5 Adaptor Jack COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
-
Page 32: Emi/Emc Certifications
CPCV5 Hardware Manual CPCV5 Manual 7. EMI/EMC Certifications ► CPCV5-070PR: CPCV5-070PR KCC Registration No. : MSIP-REM-CUL-CPCV5-070PR ► CPCV5-102BR: CPCV5-102BR KCC Registration No. : MSIP-REM-CUL-CPCV5-102BR ► CPCV5-101BR: TDB ► CPCV5-070WR: TDB COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page... -
Page 33: Warranty Policy
14 Pidgeon Hill Drive, Suite 310, Sterling, VA 20165, U.S.A Telephone Toll-Free : (888) 9CUBLOC, (888) 928 2562 Office : (571) 322 5010 Fax : (571) 322 5011 Office Hours: Monday-Friday 9am-5:30pm EST E-mail Sales: sales@comfiletech.com Technical Support: support@comfiletech.com COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page... - Page 34 CPCV5 Hardware Manual CPCV5 Manual COMFILE Technology, Inc. www.comfiletech.com / www.comfile.co.kr • page...
