Specification - LightProcessor PARADIME Installation And Operating Manual

SPECIFICATION

Power Requirements
Dimming Capacity
Control Inputs
Output Connectors
Phantom Power Output
Physical Characteristics
Environment
Conformance
Voltage 230V AC nominal. (194-264V AC)
Link selectable to 115V AC nominal. (100-120V)
Frequency 48-62Hz.
Three phase + neutral + earth
Single phase + neutral + earth with links fitted (10A per channel models only)
Six channels of dimming per dimmer unit.
Maximum load:
Minimum load: All models 100W per channel
Analogue 0 to +10V, via 8-pin locking DIN.
20kOhm input impedance
USITT DMX512 (1990), via 5-pin XLR.
Power output connectors are available covering a range of
international standards.
Hardwired versions are also available with screw terminal connectors.
16V DC unregulated and current limited by 100mA self-resetting fuse.
Weight: between 11 and 14Kg., depending on model and rating.
Dimensions: Rack models
Height: (depending on model) 2, 3 or 4 rack units.
Width: 19 inch rack mounting
Depth: 360mm. (excluding any output sockets)
Wall models
Height: 455mm.
Width: 335mm.
Depth: 105mm.
Other versions may be available to special order.
Temperature
Relative humidity
Pollution
Protection Classification
All Paradimes are designed to meet CE regulations covered by:
LVD (using EN60439 and EN60950)
EMC (EN55014 and EN50082-1)
LightProcessor Paradime, all variants, version 21, September 2003
Page 15
10A models 10A per channel/60A total.
16A models 16A per channel, 3-phase only
32A per phase. 96A total.
20A models 20A per channel, 3-phase only
40A per phase. 120A total.
25A models 25A per channel, 3-phase only
25A per phase. 75A total (3-channels).
10Amp hardwired, hardwired D/P.
Sockets:- 6 x Schuko, 6 x French, 6 x US
6 x Swiss, 6 x UK (15A), 6 x CEE17, Patchpack
12 x Schuko, 12 x French, 12 x UK (15A)
16Amp hardwired, hardwired D/P.
Sockets:- 6 x Schuko, 6 x French, 6 xCEE17,
12 x Schuko, 12 x French, Patchpack
20Amp hardwired. Sockets:- 6 x Japanese C-type
25Amp hardwired.
10Amp hardwired, Sockets:- 12 x UK (15A)
16Amp hardwired
0-30°C
0-90% non-condensing
Degree 2
IP30
