LightProcessor PARADIME Installation And Operating Manual page 18

MENU SYSTEM AND USER OPTIONS - cont'd
36 NO DMX SCN?
A scene or chase program selected here will be output if the DMX fail option, menu 33, is set to 'Go No
DMX', DMX is a selected input type and the DMX signal fails or is missing.
361 [
∧ ∧ /∨ ∨ to select scene or chase and press 4. ⇒ STORED OK
4 SET SUPPLY?
Press the 4 - the display will show
41 SET PHASES ?
Press the 4 - the display will show
411 ORDER [ ]
Default = [aut]
Pressing the up or down arrow keys will change the setting within the square brackets on the display.
Subsequent presses will display the different settings available, these are:-
[111]
[123]
[132]
[aut]
Change to the desired option and press 4 to select and memorise the setting. ⇒ STORED OK
42 SET FREQ?
Press 4.
421 FREQ [auto]
Default = [auto]
∧ ∧ /∨ ∨ to select [50Hz], [60Hz] or [auto].
Press 4 to select and memorise the setting. ⇒ STORED OK
5 SET INPUTS?
You may select the input signal type used to control the dimmer from the following list. Where there is more than
one input signal source selected, the highest level received by any channel will be used (HTP)
Press 4.
51 [ ]
Default = DMX+Analog.
Choose from: DMX only, ANALOG only, DMX+ANALOG, WP6, WP9.
Menu
Description
DMX only
Analog only
DMX+Analog
WP9+DMX
WP6 + DMX
WP6 + CONT
DMX  Analog
WP6M
See page 5 for fuller explanations of of the various inputs.
∧ ∧ /∨ ∨ to select option and press 4 to store. ⇒ STORED OK
LightProcessor Paradime, all variants, version 21, September 2003
]
Single phase
3 Phases connected in the order 1,2,3
3 Phases connected in the order 1,3,2
Auto phase order detection
Functionality
DMX input only active
Analogue input only active
DMX and analogue inputs mixed on
HTP basis
Six 0-10V inputs have control over
each scene - any/all scenes can be
mixed on an HTP basis
Latching scene control input for use
with 6-button panel. Mixed with
DMX input on HTP basis
WP6 swaps with DMX according to level of
seventh channel.
Analogue output if no DMX.
Level control of four scenes.
Page 8
