USE AND MAINTENANCE INSTRUCTIONS
JOKER LIGHT
EN 795:2012 TYPE B / TESTED AND COMPLIES WITH TS 16415:2013
REF.
FTC/JOKER/L/110
REF.
FTC/JOKER/L/200
REF.
FTC/JOKER/L1A/500
REF.
FTC/JOKER/L2A/110
MANUFACTURING DATE
CAMBIUM SAVER
110 cm
200 cm
500 cm
110 cm
Cambium saver no ring
Cambium saver no ring
Cambium saver with 1 ring
Cambium saver with 2 rings
Month/Year-Individual number
1355, chemin de Malombre • Z.I. Les Plaines
26780 MALATAVERNE • FRANCE
(+33) 475 528 640 • contact@ftc-tree.com
www.ftc-tree.com
XX/XX-XXXX
Advertisement
Table of Contents
Related Manuals for FTC JOKER LIGHT L/110
Summary of Contents for FTC JOKER LIGHT L/110
- Page 1 REF. FTC/JOKER/L1A/500 Cambium saver with 1 ring 110 cm REF. FTC/JOKER/L2A/110 Cambium saver with 2 rings XX/XX-XXXX MANUFACTURING DATE Month/Year-Individual number 1355, chemin de Malombre • Z.I. Les Plaines 26780 MALATAVERNE • FRANCE (+33) 475 528 640 • contact@ftc-tree.com www.ftc-tree.com...
- Page 2 DESCRIPTION • Anchoring strap as part of a fall-arrest system. • This equipment totally complies with the requirements of European standard EN 795:2012, TYPE B. • Tested and in conformity to TS 16415:2013 for use by 2 persons. Marking Loop seam (intermediate anchor) Main anchor (large ring / small ring / loop)
-
Page 3: General Instructions
• Used with compatible systems (for example: connectors CE EN 362), and by respecting their instructions, as well as the recommendations in these instructions. For information on compatible systems, please contact: FTC - 1355, chemin de Malombre, ZI Les Plaines - 26780 MALATAVERNE • FRANCE • (+33) 475 528 640 • www.ftc-tree.com •... - Page 4 PRECAUTIONS • For all users’ safety, if the product is resold outside of the original country of destination, the reseller must provide these instructions and the annual inspection form written in the language of the country destined to use this product. •...
- Page 5 INSTRUCTIONS FOR USE SETTING UP THE JOKER LIGHT 13 kN Minimum resistance of anchor point RETRIEVING THE JOKER LIGHT Place the retrieval ball on the end of the rope, on the side of the larger ring. 1 - 2 - 3: Pull on the rope until the JOKER LIGHT is pulled free.
- Page 6 • A competent person familiar with the regulatory requirements in effect must inspect the JOKER LIGHT annually. • Check the legibility of the markings, serial numbers and pictograms. (FTC - 1355, chemin de Malombre, ZI Les Plaines - 26780 MALATAVERNE • Only the manufacturer can repair it FRANCE).
-
Page 7: Storage / Transport
STORAGE / TRANSPORT During transport and/or storage, place the JOKER LIGHT far away from: shocks, crushing, grinding, rubbing, dampness, heat, ultra-violet rays, corrosive materials, hydrocarbons, acids, sand, tools, any other sharp objects that could damage it. Keep away from corrosive, over-heated or refrigerated environments. GUARANTEE The JOKER LIGHT is guaranteed for two years against any manufacturer defects. - Page 8 Name of user Name JOKER LIGHT In 110 cm and 200 cm, without ring - Ref. FTC/JOKER/EL/110 and Ref. FTC/JOKER/L/200 In 500 cm with 1 ring - Ref. FTC/JOKER/L1A/500 In 110 cm with 2 rings - Ref. FTC/JOKER/L2A/110 Date of purchase...
- Page 9 MINIMUM BREAKING STRENGTH DATA JOKER LIGHT - simple traction = Minimum Breaking Strength (MBS) 2,320 daN JOKER LIGHT with rings - simple traction = Minimum Breaking Strength (MBS) 1,990 daN JOKER LIGHT with a girth hitch MBS 2,475 daN Loop seam = 650 daN...
- Page 10 ASSEMBLY AND TECHNIQUE Some situations (eg. a very large anchor point) can require a longer cambium saver. It will be lengthened by tying it to another cambium saver with a girth hitch (as shown by illustration). Assembly of 2 JOKER LIGHT = MBS 1,800 daN ASSEMBLY JOKER LIGHT + CHOKER JOKER LIGHT = MBS 1,800 DAN EXAMPLE OF USE ON TRUNK...
-
Page 11: Examples Of Configurations
EXAMPLES OF CONFIGURATIONS Classic with rings Classic with connectors Shortened JOKER LIGHT Double anchoring Ground anchoring... -
Page 12: Declaration Of Conformity
DECLARATION OF CONFORMITY (UE) 2016/425 Manufacturer FTC, ZI Les Plaines, 1355 Chemin de Malombre, 26780 Malataverne, France Declares, under its sole responsibility, that the following product: JOKER LIGHT CAMBIUM SAVER References: FTC/JOKER/L/XXX or FTC/JOKER/L1A/XXX or FTC/JOKER/L2A/XXX Complies with the EU 2016/425 regulation on personal protective equipments.
