ADC Transport System Cable DS1C Specification Sheet page 4

O r d e r i n g I n f o r m a t i o n
Description
22 AWG STC,
Dual Shield, Riser
Jacket color: Gray
Packaging: Reel
Equivalent to 600C Series
*To designate reel length,
replace XX as follows:
02 = 304 m (1000 ft)
04 = 609 m (2000 ft)
05 = 762 m (2500 ft)
06 = 914 m (3000 ft)
10 = 1524 m (5000 ft)
Web Site: www.adc.com
From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080
Fax: +1-952-917-3237 • For a listing of ADC's global sales office locations, please refer to our web site.
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may
verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products orfeatures
contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
101298AE 10/06 Original © 2006 ADC Telecommunications, Inc. All Rights Reserved
Number Unit
of Pairs Makeup
1 None
2 None
4 None
6 None
8 None
12 None
16 None
20 None
25 None
28 25 & 3
30 25 & 5
32 25 & 7
50 2 @ 12, 2 @ 13
56 2 @ 20, 1 @ 16
100 4 @ 25
Outer Weight
Diameter Kg/Km
mm (inches) (lbs/1000')
6.6 (.26) 52 (35)
7.1 (.28) 60 (40)
8.3 (.33) 74 (50)
9.1 (.36) 89 (60)
9.3 (.37) 113 (76)
10.6 (.42) 149 (100)
12.7 (.50) 193 (130)
12.9 (.51) 233 (157)
14.7 (.58) 278 (187)
14.9 (.59) 297 (200)
15.2 (.60) 307 (206)
15.4 (.61) 327 (220)
19.8 (.78) 554 (375)
20.5 (.81) 573 (385)
25.4 (1.0) 976 (659)
Catalog Number
DSR-01222SDGYXX
DSR-02222SDGYXX
DSR-04222SDGYXX
DSR-06222SDGYXX
DSR-08222SDGYXX
DSR-12222SDGYXX
DSR-16222SDGYXX
DSR-20222SDGYXX
DSR-25222SDGYXX
DSR-28222SDGYXX
DSR-30222SDGYXX
DSR-32222SDGYXX
DSR-50222SDGYXX
DSR-56222SDGYXX
DSR-00222SDGYXX
