If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department. Leaking
gas may cause a fire or explosion which can
cause serious bodily injury or death,
or damage to property.
WARNING: Do not try to light this appliance without
reading the "Lighting" Instructions section of this
manual.
Failure to follow the Dangers, Warnings and Cautions contained in this Owner's Manual may result in serious bodily
injury or death, or in a fire or an explosion causing damage to property.
WARNINGS
Do not store a spare or dis-
connected propane cylinder under
or near this grill.
Improper assembly may be
dangerous. Please carefully follow
the assembly instructions in this
manual.
After a period of storage, and/
or nonuse, the Weber
should be checked for gas leaks
and burner obstructions before
use. See instructions
in this manual for correct
procedures.
Do not operate the Weber
grill if there is a gas leak present.
Do not use a flame to check for
gas leaks.
Combustible materials should
never be within 24 inches of the
top, bottom, back or sides of your
®
Weber
gas grill.
®
Your Weber
gas grill should never
be used by children. Accessible
parts of the grill may be very hot.
Keep young children away while it
is in use.
You should exercise reasonable
care when operating your Weber
gas grill. It will be hot during
cooking or cleaning
and should never be left
unattended, or moved while
in operation.
LP Gas Grill Owner's Guide
You must read this Owners Guide before operating your gas grill
DANGER
Should the burner go out while in
operation, turn the gas valve off.
Open the lid and wait five minutes
before attempting to relight, using
the lighting instructions.
Do not use charcoal or lava rock
in your Weber
Never lean over an open grill or
place hands or fingers on the front
edge of the cooking box.
®
gas grill
Should a grease fire occur, turn
off the burner and leave lid closed
until fire is out.
Do not enlarge valve orifice or
burner ports when cleaning the
®
gas
valve or burner.
The Weber
thoroughly cleaned on a
regular basis.
Propane gas is not natural gas.
The conversion or attempted use
of natural gas in a propane unit or
propane gas in a natural gas unit
is dangerous and will void your
warranty.
Do not attempt to disconnect any
gas fitting while your grill is in
operation.
Use heat-resistant grill mitts or
®
gloves when operating the grill.
Keep any electrical supply cord
away from any heated surfaces.
Combustion byproducts produced
when using this product contain
chemicals known to the state of
1. Do not store spare liquid propane cylinder
within 10 feet (3m) of this appliance.
2. Do not store or use gasoline or other
flammable liquids or vapors within 25 feet
(8m) of this appliance.
WARNING: Follow all leak-check procedures carefully
in this manual prior to grill operation. Do this even if
the grill was dealer-assembled.
NOTICE TO INSTALLER: These instructions must be
left with the owner and the owner should keep them for
future use.
THIS GAS APPLIANCE IS DESIGNED FOR OUTDOOR
USE ONLY.
DANGERS
®
gas grill.
®
gas grill should be
41894
06/02/05
WARNING
California to cause cancer, birth
defects, or other reproductive
harm.
Do not use this grill unless all
parts are in place. The unit must
be properly assembled according
to the instructions outlined in the
"Assembly Instruction" section of
the Owner's Guide.
Do not use the Weber
vehicle trunk, station wagon, mini-
van, sport utility vehicle(SUV), or
recreational vehicle(RV).
Use the regulator that is supplied
with your Weber
®
gas grill.
Do not attempt to disconnect the
gas regulator or any gas fitting
while your grill is in operation.
If you see, smell or hear the hiss
of escaping gas from the propane
cylinder:
1. Move away
from propane
cylinder.
2. Do not attempt
to correct
the problem
yourself.
3. Call your fire
department.
#
®
Q
grill in a
41894

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 41894 and is the answer not in the manual?

Questions and answers

Summary of Contents for Weber 41894

  • Page 1 See instructions in this manual for correct procedures. Do not operate the Weber ® grill if there is a gas leak present. Do not use a flame to check for gas leaks.
  • Page 2: Parts List

    0,6 à 50 x 2,5 cm (1/4 - 20 x 1 po) - 2 © 2004 The following trademarks are registered in the name of Weber-Stephen Products Co., an Illinois corporation, located at 200 East Daniels Road, Palatine, Illinois 60067 U.S.A.
  • Page 3: Instructions De Montage

    ASSEMBLY INSTRUCTIONS DE MONTAGE INSTRUCCIONES DE MONTAJE...
  • Page 4 National Fuel Gas Code: ANSI Z 223.1/NFPA54. • The pressure regulator supplied with the Weber gas grill must be used. This regulator is set for 11 inches of water column (pressure).
  • Page 5 The burners have been flame tested. As a safety precaution however, you should recheck all fittings for leaks before using your Weber gas grill. Shipping and handling may have loosened or damaged a gas fitting.
  • Page 6 Contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com 2) Valve to-regulator connections. WARNING: If there is a leak at connection (2) turn OFF the gas. DO NOT OPERATE THE GRILL.
  • Page 7 à gaz ® Weber ® Votre barbecue à gaz Weber doit en aucun cas être utilisé par un enfant. Les parties accessibles du barbecue peuvent être très chaudes. Lors de son utilisation, tenez le barbecue hors de portée...
  • Page 8 Votre barbecue à gaz Weber est un appareil de cuisson portable à usage extérieur. Le barbecue à gaz Weber permet de griller, de rôtir à la broche, de rôtir et de cuire et donne des résultats qu’il est presque impossible d’égaler avec d’autres appareils ménagers à...
  • Page 9 à la flamme. Toutefois, par mesure de sécurité, il est préférable de vérifier à nouveau l’étanchéité de tous les raccords avant l’utilisation de votre barbecue à gaz Weber Il se peut qu’un raccord de gaz ait été desserré ou endommagé...
  • Page 10 28 cm (11 po) de long. La bouteille de propane doit s’emboîter dans la bague du support de bouteille. MISE EN GARDE: N’utilisez que des bouteilles portant la mention “Gaz propane” Note: Votre barbecue à gaz Weber ® est muni d’un système d’alimen-tation conçu pour l’aspiration de vapeurs à...
  • Page 11 Después de un período de almacenamiento o desuso, se debe revisar si el asador a gas Weber ® tiene fugas y obstrucc-iones en el quemador antes de usarlo. Consulte las instrucc-iones que se incluyen en este manual para obtener los procedimientos correctos.
  • Page 12 éste no se esté usando. ® • Se debe revisar si el asador a gas Weber tiene fugas de gas y cualquier obstrucción en los tubos del quemador antes de utilizarlo. (Consulte las secciones: “Mantenimiento general y mantenimiento anual”).
  • Page 13 Como una precaución por seguridad, sin embargo, debe revisar de nuevo todos los empalmes para ver si hay fugas, antes de utilizar su asador a gas Weber ® . El envío y el manejo pueden haber aflojado o dañado un empalme de gas.
  • Page 14 Contacte al Representante de Servicio a los Clientes en su región usando la información de contacto en nuestro sitio en la Internet. Conéctese a www.weber.com Revise: 2) Las conexiones de la válvula hacia el regulador.
  • Page 15 Si los problemas no pueden corregirse usando cualquiera de estos métodos, por favor contacte al Representante de Atención al Cliente en su área usando la infor- mación de contacto en nuestro sitio web. Conéctese a www.weber.com Problème Les brûleurs produisent une fl...
  • Page 16: Warranty

    Representante de Servicio al cliente de su región, por medio de la hoja de información de contacto que se proporciona con este manual. Si Weber confirma el defecto y aprueba el reclamo, Weber elegirá reemplazar dichas partes sin costo alguno. Si se le solicita devolver partes defectuosas, los costos por transporte se pagarán por anticipado.
