ProMariner ProMar1 DS Series Owner's Manual And Installation Manual page 10

Typical Wiring
15
Fig. 2 ProMar1 DS 4/4 and 5/5 Dual Bank Charger for 2 12V Batteries
Dedicated 24 VDC Trolling Motor Battery Configuration
with (2) 12 VDC Batteries Connected with a Series Jumper
Note:
Indicates Jumper Series
Indicates Fuse
For Engine Battery Cable 1
Use Cable 1
_
Bat 1
+
Two 12 VDC Batteries Connected with a Series
Jumper for a 24 VDC Trolling Motor
ProMar1
DS
2 Bank
Charger
Cable 2
_ Top View
Bat 2
of Battery
+
Fig. 3 ProMar1 DS 4/4 and 5/5 Dual Bank Charger for 2 12V Batteries
Dedicated 12 VDC Parallel Trolling Motor or House Configuration
Note:
ProMar1
Indicates Jumper Series
DS
Indicates Fuse
2 Bank
Charger
For Engine Battery
Red Jumper
Use Cable 1
Red
Cable 1
Black
Black Jumper
Top View of Battery
Typical Wiring
16
Red
Cable 2
Black
