1 Service Navigation 1.4. Maintenance Your product is designed and manufactured to ensure a mini- 1.1. About Lead Free Solder (PbF) mum of maintenance. Use a dry, a soft cloth for routine exterior cleaning. Never use benzine, thinner or other solvents. Distinction of PbF PCB : •...
2 Specifications 2.2. Dimensions 2.1. Specifications* General Power Supply DC 12V (11V - 16V) Test Voltage 14.4V Negative Ground Current Consumption Less than 2.1A (CD mode, 0.5W 4 channels) 50W × 4 (at 1kHz), volume control Maximum Power Output maximum 18W ×...
3 Features • The optional adapter allows you to connect the optional Panasonic CD changer unit (CX-DP880). • The optional adapter allows you to connect the optional iPod® series. • Hands Free Phone System. (The optional Bluetooth hands- free kit: CY-BT100N) •...
4 Technical Descriptions Port Description Vol. (V) FM AM CD 58 (NC) Not connected 4.1. Terminals Description 59 AVREF (Conecting to +5V) 4.8 4.8 4.8 60 AVSS Ground 4.1.1. Main Block 61 ACC ACC detection 4.9 4.9 4.9 62 (NC) Ground IC601 : YESAM404 63 LEVEL...
Page 6
4.1.2. Display Block Port Description IC901 : C0HBA0000195 CONT (P13) DSP IC power control 1 Pin No. Port Description Not connected (NC) Not connected Not connected SEG40 LCD segment data Not connected 3 - 8 SEG6-1 LCD segment data CONT (P17) DSP IC power control 2 9 - 39 SEG39 -9 LCD segment data...
CD RESET Q681,682,683 CD MUTE CD MUTE X1 15 XL601 CD SW1 CD SW1 4 STBY R-CH 20MHz 10 9 CD SW2 CDSW2 X2 14 22 MUTE CD 3.3V 12 11 14 13 R-CH 16 15 CQ-C5153W MAIN(1/2)/ SUB Block...
6 Wiring Connection Diagram Rear Speakers Front Speakers External Mute Motor Antenna Relay Control External Amplifier Control Power Battery Ground Power (ACC or IGN) Extension Connector Jig Part No. Sub Block [YESFZS2067] [7221-06-11] CN302:13P (CN301:13P) Main Block [7221-02-11] (CN251) (CN253) CN251 (AUX1-IN) CN661:18P...
10 Exploded View and Replacement Parts List 10.1. Exploded View (Unit) < Installation Parts Mounting Collar > Display P.C.B [7221-05-11] CD Deck Ass'y Sub P.C.B [7221-06-11] AT001 PA051 CN601 AT051 Main P.C.B [7221-02-11] AT002 Connector P.C.B [7221-03-11] < Installation Parts Trim Plate > CQ-C5153W...
Page 25
10.2. Replacement Parts List Notes : Ref. No. Part No. Part Name & Description Remarks D278 YESAD146 Diode 1. Be sure to make your orders of replacement parts accord- D279 YESAD146 Diode ing to this list. D601 YESAD155 Diode 2. Important safety notice: Components, identified by D602 YESAD147 Zener Diode...
Page 26
Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks C367 YESCC487 Ceramic, 0.47µF 16WV J107 YESRG196 Chip, 0Ω 1/8W C368 YESCC487 Ceramic, 0.47µF 16WV J108 YESRG241 Chip, 0Ω 1/8W C369 YESCC487 Ceramic, 0.47µF 16WV J109 YESRG196...
Page 27
Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks R231 YESRG146 Chip, 3.9kΩ 1/4W R632 YESRG319 Chip, 1kΩ 1/8W R236 YESRG135 Chip, 10kΩ 1/4W R633 YESRG319 Chip, 1kΩ 1/8W R237 YESRG360 Chip, 10kΩ...
Page 28
Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks R730 YESRG388 Chip, 4.3kΩ 1/8W CAPACITORs R731 YESRG404 Chip, 8.2kΩ 1/8W C264 YESCC536 Electrolytic, 4.7µF 25WV Chip, 100k Ω 1/4W R740 YESRG136 C265 YESCC536 Electrolytic, 4.7µF 25WV...
Page 29
Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks D940 YESAD169 D991 YESAD170 D941 YESAD169 D995 YESAD155 Diode CAPACITORs RESISTORs C905 YESCC523 Ceramic, 0.1µF 16WV J901 YESRG132 Chip, 0Ω 1/4W C914 YESCC523 Ceramic, 0.1µF 16WV J902...
Page 30
Ref. No. Part No. Part Name & Description Remarks YESFC02272 Detachable Face Ass'y YESFA07016 Rear Cover YESFX005135 Spring YESFX005138 Knob Spring YESFX005136 Open Button Spring YESFE13250 Button (TUNE/TRACK) YESFE13251 Button (BAND) YESFE13253 Button (SQ) YESFE13252 Button (DISP) YESFE13260 Button, MUTE YESFE13261 Button, OPEN YESFX999068...
Page 32
10.4. CD Player Parts List Ref. No. Part No. Part Name & Description Remarks C227 YESCC439 Ceramic, 0.1µF 25WV Notes : C228 YESCC439 Ceramic, 0.1µF 25WV 1. Be sure to make your orders of replacement parts accord- C229 YESCC439 Ceramic, 0.1µF 25WV C230 YESCC442 Ceramic, 0.01µF 50WV...
Page 33
Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks R142 ERJ3GEY0R00V Chip, 0Ω 1/16W R201 YESRG224 Chip, 100kΩ 1/10W R202 YESRG355 Chip, 1MΩ 1/10W MECAHNICAL PARTS R203 ERJ3GEY0R00V Chip, 0Ω 1/16W MISCELLANEOUS R204 ERJ3GEY0R00V Chip, 0Ω...
Page 34
Ref. No. Part No. Part Name & Description Remarks YERJS01003 Camera Screw, 2*2 YERJS01004 Camera Tapping Screw, 1.7*5 YESJS01148 Screw, 2*4 YERJW01001 P Washer, 3.5*8*0.3 YERJW01002 HL Washer, 1.85*5*0.13 YERJW01003 Lumilar Washer, 3.1*6*0.1 YEJE01028 E-Ring S 1.5 YERJW01005 P Washer, 2.1*4*0.13...
