- Page 1 Hamwells logo staand Hamwells productlogo HomeSpa Hamwells logo liggend User Manual 2020 V1.5...
- Page 2 HomeSpa user manual | 2020 v1.5 Hamwells logo staand © 2020 Hamwells Nederland B.V. Pelgrimsstraat 3, 3029 BH Rotterdam The Netherlands T +31 (0)85 - 303 64 96 E info@hamwells.com I www.hamwells.com Hamwells productlogo V 1.5 Hamwells logo liggend...
- Page 3 Introduction Dear User, We are pleased that you have chosen the HomeSpa and congratulate you on this choice. Keep this manual in a safe place and use it as your first point of reference. The HomeSpa is a new product. We would therefore greatly appreciate receiving any improvements or suggestions.
-
Page 4: Table Of Contents
HomeSpa user manual | 2020 v1.5 Contents Safety Hardware settings Safety instructions Hardware info Specifications HomeSpa Hardware status The HomeSpa Network settings WiFi connection Operating the HomeSpa Display Cleaning settings Performance Indicators Start cleaning program Turn on/off the HomeSpa Ignore Quick rinse... -
Page 5: Safety
Safety... -
Page 6: Safety Instructions
Our telephone service is available from Monday to Friday from 09:00 to 17:00 (CET). • New users who do not know how to use the HomeSpa should be instructed. • Never attempt to repair, disassemble or make modifications to this product. - Page 7 HomeSpa user manual | 2020 v1.5 • If you have filled a baby bath with the handshower, use a thermometer to check whether the water has the correct temperature! • The hand shower always dispenses tap water. The water used in the FreshCycles (from the rain shower) is continuously filtered, purified and refreshed.
-
Page 8: Specifications Homespa
Specifications HomeSpa... -
Page 9: The Homespa
HomeSpa user manual | 2020 v1.5 The HomeSpa Dimensions technical cabinet 2142 mm (L) x 280 mm (W) x 220 mm (D) Weight 30 kilogram Power consumption 450W Power supply 240V/50Hz 30mA Max. power consumption 500W Rain shower Handshower Display... -
Page 10: Operating The Homespa
Operating the HomeSpa... -
Page 11: Display
HomeSpa user manual | 2020 v1.5 Display ruikname Display symbols Display symbols HomeSpa control Temperature indicator Weather app 10. Timer (shower time) Language settings 11. Temperature limiter (set at 38 °C) Cleaning programs 12. Shower mode indication System settings 13. Classic shower/FreshCycles... -
Page 12: Performance Indicators
HomeSpa user manual | 2020 v1.5 Performance Indicators The performance indicators indicate in real time whether the optimal values are achieved for the most efficient use of the shower. The following values are measured: FreshCycles indicator This indicates the ratio in time between the use of the classic shower versus the use of the Refresh Cycles. -
Page 13: Turn On/Off The Homespa
HomeSpa user manual | 2020 v1.5 Turning the HomeSpa on and off e-Shower activeren To turn the HomeSpa on or off, press the rotary push button. 08:41 Push button to activate e-Shower Lorem ipsum Druk de knop in om de e-Shower te activeren... -
Page 14: Classic Shower
HomeSpa user manual | 2020 v1.5 Classic shower ruikname During the classic shower, the HomeSpa works like a normal shower and drains the water immediately. The Classic shower mode is the default mode. Klassieke modus During the shower you can switch between the classic shower and FreshCycles with the button at the bottom left. -
Page 15: Freshcycles
HomeSpa user manual | 2020 v1.5 FreshCycles During the FreshCycle mode water is circulated. The rain shower will start once the FreshCycles opstart reservoir is filled with water. 08:41 You can start the FreshCycles with the name e-Shower ingebruikname button at the bottom left. -
Page 16: Quick Rinse
Snel spoelen Temper Snel spoelen na elke FreshCycles sessie. 08:41 The HomeSpa is cleaning. You can stop the U kunt deze direct starten (Nu starten). U kunt ook per keer 30 seconden erbij doen. (+00:30) cleaning program prematurely with the button at the bottom right. -
Page 17: Deep Clean
Complete reiniging na elke FreshCycles sessie. 08:41 U kunt deze direct starten (Nu starten). U kunt The HomeSpa is cleaning. You can stop ook per keer 30 seconden erbij doen. (+00:30) the cleaning program prematurely with the button at the bottom right. - Page 18 HomeSpa user manual | 2020 v1.5 uikname Setting the temperature Setting the desired temperature is done by by rotating the Home button. Temperatuur hoger zetten 08:41 Classic shower Unlock Fresh Cycles Hoger lager zetten van de temperatuur...
- Page 19 Temperature lock is reset after switching the shower off. 08:41 Classic shower Unlock Fresh Cycles Temperatuur hoger zetten dan 38 graden (ontgrendel). Maximum temperatuur is 43 min is 25. The maximum temperature of the HomeSpa is 43 °C. The minimum temperature is 25 °C.
- Page 20 HomeSpa user manual | 2020 v1.5 De weer app Weather app If there is an internet connection, you can view the weather app while showering. You can set your location in the user settings (see page 21). Maassluis, NL Maassluis, NL 25°...
-
Page 21: User Settings
User settings... -
Page 22: Adjust Settings
HomeSpa user manual | 2020 v1.5 Instellingen temp Adjusting the settings Navigate with the buttons above and go to settings. There are 4 menu options User settings Hardware settings Instellingen Cleaning settings Lock settings Gebruikersinstellingen Lorem ipsum User settings Hardware settings... -
Page 23: Set The Start Temperature
HomeSpa user manual | 2020 v1.5 Setting the start temperature You can set the default start temperature. For safety reasons it is not possible to set a temperature above 38 °C. Instellingen temperatuur temperatuur Go to settings and select user settings. -
Page 24: Set Start Mode
Instellingen Start modus en Start modus In smart mode, the last saved settings are The blue bar on the left side remembered as long as the HomeSpa is restarted of the menu indicates the within a minute. current mode. Instellingen... -
Page 25: Set Screen Color
HomeSpa user manual | 2020 v1.5 Setting the screen color You can set the default screen color scheme. Go to settings and select user settings. Select screen color. You can choose between a dark screen or a light screen. Instellingen Start modus... -
Page 26: Set The Shower Timer Mode
Instellingen douchetimer modus HomeSpa user manual | 2020 v1.5 Setting the shower timer mode Instellingen Douche timer Modus Gebruikersinstellingen Set shower timer mode. Go to user settings Lorem ipsum Default temperature etimer modus r modus Start mode Select Shower timer mode... -
Page 27: Set The Shower Time
Instellen douchetijd HomeSpa user manual | 2020 v1.5 Setting the shower time Instellingen Stel douchetijd in Gebruikersinstellingen Set shower time. Go to user settings Default temperature Lorem ipsum Start mode Select Set shower time Shower timer mode Lorem ipsum User settings... -
Page 28: Set Location
HomeSpa user manual | 2020 v1.5 Setting your location The HomeSpa uses geolocation services to determine your location. These are not all equally accurate. You can set and save the most appropriate location to be able to provide, for example, the most accurate weather report possible. -
Page 29: Hardware Settings
Hardware settings... -
Page 30: Hardware Info
HomeSpa user manual | 2020 v1.5 Hardware info This information is important for the Service Engineer. Go to settings and select hardware settings. Hardware instellingen info nstellingen info Select hardware info. A hardware info list now appears. Instellingen Hardware inf... -
Page 31: Hardware Status
HomeSpa user manual | 2020 v1.5 Hardware status This information is important for the Service Engineer. Go to settings and select hardware settings. atus Hardware instellingen info nstellingen status Select hardware status. A hardware status list now appears. dware status... -
Page 32: Network Settings
Lorem ipsum Lock settings menu See Wi-Fi connection on the next page to proceed with setting up your connection Select *With some models of the HomeSpa it is not possible to set the Hardware status Wifi accespoint e status Wifi accespoint Stel Wifi... -
Page 33: Wifi Connection
HomeSpa user manual | 2020 v1.5 Wi-Fi connection You can use wireless internet via Wi-Fi via the HomeSpa. You can make a Wi-Fi connection with your smartphone, tablet or computer. Follow the steps below: Activate Wi-Fi access point on the homeSpa (see page 33). - Page 34 HomeSpa user manual | 2020 v1.5 Wi-Fi HomeSpa user interface ® Wi-Fi HomeSpa Configuration status Ready for configuration Network SSID Choose your Wi-Fi Name Rescan button Hamwells Nederland Rescan Type your password Password Wi-Fi status WiFi status: undefined - Connect...
-
Page 35: Cleaning Settings
Cleaning settings... -
Page 36: Start Cleaning Program
HomeSpa user manual | 2020 v1.5 Starting cleaning program The HomeSpa has 3 cleaning programs: Quick rinse: complete system is rinsed with cold water. Hot cleaning: the pump and reservoir are cleaned using hot water and detergent. gramma instellen Schoonmaakprogramma inste Deep cleaning: the complete system is cleaned using cold water and detergent. -
Page 37: Ignore Quick Rinse
HomeSpa user manual | 2020 v1.5 Ignore Quick rinse If the deep clean program was interrupted or the HomeSpa power supply has been cut off, the Quick rinse warning icon will turn orange (see illustration on the right). This will prevent the FreshCycles from starting. -
Page 38: Adjust Water Hardness
HomeSpa user manual | 2020 v1.5 Adjusting water hardness You can set the local water hardness on a scale of 1 to 10. As a result, the cleaning program consumes more or less vinegar. Go to settings and select cleaning settings... -
Page 39: Set Time To Auto Clean
HomeSpa user manual | 2020 v1.5 Setting time to auto clean This is the waiting time in seconds before the HomeSpa cleans itself after a shower. Go to settings and select cleaning settings Schoonmaak instellingen tijd t Select time to auto clean... -
Page 40: Lock Settings
Lock settings... -
Page 41: Lock Settings
HomeSpa user manual | 2020 v1.5 Lock settings Ontgrendel instellingen ndel instellingen The settings can be locked to prevent unauthorized people from changing them. In the settings menu, select Lock settings menu The settings are now locked Instellingen Instellingen Instellingen zijn vergrendeld... -
Page 42: Unlock Settings
HomeSpa user manual | 2020 v1.5 Unlock settings If the settings are locked you can unlock them by means of of a pin code. Go to settings and press unlock. Enter the pin code 3144. Use the buttons left and right for the cursor. Use the rotary push button to change the number. -
Page 43: Cleaning And Maintenance
Cleaning and maintenance... -
Page 44: Cleaning Procedures
This chapter describes the daily and weekly cleaning intervals. The table below is a summary of maintenance. To keep the HomeSpa in perfect condition, the use of aggressive detergents like acetone or thinner is not recommended. Action... -
Page 45: Filter Cleaning
HomeSpa user manual | 2020 v1.5 Filter cleaning Clean the filter after each shower session to prevent the HomeSpa from getting blocked by hairs, soap scum and so on. This can be done manually or in the dishwasher. Remove the filter from the bottom panel Clear out any hair or debris that has accumulated. -
Page 46: Refill The Service Drawer
Fill the service drawer with cleaning vinegar. The reservoir can hold a maximum of 1.5 liters when it is completely empty. Then close the cap and close the service drawer. To keep the HomeSpa in good condition we advise you to only use cleaning vinegar. -
Page 47: Warnings
Warnings... - Page 48 HomeSpa user manual | 2020 v1.5 Warnings The HomeSpa has a number of warnings that need to be observed. You can see them at the bottom of the screen No filter • Problem: filter is not (correctly) placed in front of the pump.
- Page 49 HomeSpa user manual | 2020 v1.5 Fill the service drawer • Problem: the service drawer is empty. • Effects: the cleaning program will be excecuted without cleaning agent • Action: fill the service drawer The following error messages can only be solved by the service engineer! When this list of error messages appears, contact your sales representative.
-
Page 50: List With Error Messages
HomeSpa user manual | 2020 v1.5 00 pump : OK List with 01 NTC temperauture : OK 02 NTC connection : OK error messages 03 thermostat position : OK 04 Thermostat temperature : error 05 water level : OK 06 PID : OK... - Page 51 • Effects: The temperature control of the Classic shower may no longer work correctly • Solution: Try a power cycle from the HomeSpa. Repeatedly there is an electronic defect. 4 thermostate temperature • Problem: An incorrect value of the temperature regulator has been requested.
- Page 52 HomeSpa user manual | 2020 v1.5 8 safety switch • Problem: The values of the temperature sensors do not match. • Effects: The FreshCycles will no longer work correctly, possibly hot water! • Solution: Check temperature sensors and connections. 9 smart stop timeout •...
- Page 53 Hamwells Nederland B.V. Pelgrimsstraat 3, 3029 BH Rotterdam Hamwells logo staand The Netherlands T +31 (0)85 303 6496 E info@hamwells.com I www.hamwells.com Hamwells productlogo © 2020 Hamwells Nederland B.V. All rights reserved. Hamwells logo liggend White...
