Summary of Contents for Beam SatRADIO RST820

  • Page 1 Satellite and Radio Communications System RST820 SatRADIO User and Installation Manual Beam Communications Pty. Ltd.
  • Page 2 Information furnished by Beam Communications Pty Ltd (Beam) is believed to be accurate and reliable. However, no responsibility is assumed by Beam for its use, or for any infringement of patents or other rights of third parties, which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of Beam.
  • Page 3: Package Contents

    Package Contents The RST820 package contents  1 x RST820 unit – including Iridium transceiver (internal)  1 x DC power cable  1 x Hex-Wrench for SIM cover  1 x Printed user manual  1 x Mounting Bracket Set (2 parts) ...
  • Page 4: Sim Pin

    User information  Please record your serial number here for future reference: Model: BEAM RST820  Serial no.: This number can be copied from the white shipping label on the RST820 box eg. 100A2800 The following PIN codes may be required to use your RST820, please complete these details for future reference.
  • Page 5: Table Of Contents

    Conventions in this Manual ...... 6 – U Exposure to Radio Frequency Signals ..7 OPERATION NDERSTANDING THE ..........18 OPERATION ABOUT BEAM COMMUNICATIONS ..... 8 LED S ..........19 TATUS Call (Orange) ......... 19 RST820 S RADIO ....9 BOUT YOUR Signal .............
  • Page 6: Safety Information

    Safety Information IMPORTANT! Please read the following information carefully before installing and using this BEAM equipment. Failing to follow instructions may compromise the safety of the product and may result in personal injury and/or equipment damage. Please consult your supplier if you have any further questions.
  • Page 7: Exposure To Radio Frequency Signals

    Exposure to Radio Frequency Signals Your wireless mobile telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. International agencies have set standards and recommendations for the protection of public exposure to RF electromagnetic energy.
  • Page 8: About Beam Communications

    About BEAM Communications BEAM Communications, is an authorised manufacturer of Iridium Satellite products. BEAM develops subscriber products that utilise the Iridium satellite network of Low Earth Orbit satellites, known as LEOs. The Iridium network is extensively used around the world by commercial enterprises and defence agencies.
  • Page 9: About Your Rst820 Satradio

    About your RST820 SatRADIO The RST820 is a Portable Radio over Satellite system for connecting a radio network to a base station or phone call party over the Iridium network. The RST820 extends your existing Radio network using an Iridium satellite link with an easy-to- deploy portable solution in a self-contained rugged carry case.
  • Page 10: Using Rst820 Satradio

    Using RST820 SatRADIO The RST820 is software configurable to operate in a number of ways to best suit your situation. This mostly relates to how the satellite call is initiated. Auto-answer. Regardless of any locally initiated call out operation, the SatRADIO can be setup to auto-answer an incoming call.
  • Page 11: Getting Started

    Getting Started The RST820 requires that a valid Iridium or Telstra Mobile Satellite SIM card to be installed. This is not included in the RST820 kit and you should consult your place of purchase is you do not have an active SIM card enabled to make Iridium Satellite calls. Warning: To prevent possible damage, make sure the RST820 system is completely switched OFF before installation.
  • Page 12: Rst820 Connector Overview

    Connecting to the Log Port (if required) Connect a PC/Laptop to the Log port to use the Beam Management System. The Log Port should only be used for configuration and control of the terminal equipment.
  • Page 13 Page 13 of 31...
  • Page 14: Rst820 Operation

    RST820 Operation System Power up After installation has been completed, the RST820 system is now ready to be switched on. To turn on the system: 1. Apply power to the attached radio and RST820. 2. Wait for the Signal LED to stay solid green or, the DPL Satellite Handset (if fitted) to show registered status.
  • Page 15: Using A Radio Handset - Dtmf Model

    Using a Radio Handset – DTMF Model Using a DTMF compatible Two-way Radio it is possible to make or receive a call over the satellite network on the Radio device. To make a call from a Radio handset a PIN is required.
  • Page 16: Accessing Quick (Speed) Dials From Radio Handset

    SatRADIO. Dial PIN, then a digit between 0->9 then *, to identify the quick dial number. The quick dials can be programmed only using the Beam Management System when connected with a PC to the Log port.
  • Page 17: Intelligent Handset Mode (If Fitted)

    Repeat steps above for transferring the next call when required. NOTE 1: “AutoDial” (in Beam Management Settings) must be disabled. NOTE 2: “Auto Answer” (in Beam Management Settings) must be disabled. NOTE 3: If the “Dial” input remains in the ENABLED (+ve) position after the call is ended, this instructs the RST820 to operate in “auto-redial”...
  • Page 18: Autodial Mode - Quick Dial

    (but not the SAME) to the “AutoDial” mode which is instead enabled from the Beam Management System. Autodial Mode - Quick Dial This mode enables the RST820 to continuously maintain a phone call link to the number in Quick Dial position “0” (if configured). This is ideal for emergency or disaster recovery situations when the terminal may be being used as a primary communication tool or a replacement for a Radio link that is down.
  • Page 19: Led Status

    LED Status Call (Orange) Indicates the status of the call, either a data or voice call. The LED indicates: In Call (Flashing) Waiting to connect (constant) Incoming call (cadence flash) Data port active (constant) Signal The Signal Strength LED gives an indication of how strong the signal is from the Iridium network at your location.
  • Page 20: Intelligent Handset Rst970

    Voice and SMS services over the Iridium network in conjunction with the RST820 terminal interface. A Beam Communications approved extension cable to the Intelligent handset is optionally available. The DPL Handset is inserted and removed from the cup by pushing forward against the spring- loaded arch.
  • Page 21: Data Communications

    Data Communications A 9 pin serial communications port (Comm Port) is provided for data communications over the Iridium satellite channel. Data calls cannot be made when the terminal is busy in a voice call with the handset or radio. The interface is wired DCE, so appears as a normal Hayes modem to a computer. Standard AT Hayes commands can be used to initiate a Data call using this port.
  • Page 22: Internal Rs232 Port Signal Support And Handshaking

    Internal RS232 Port Signal Support and Handshaking On the Comm port, DCD and DSR output signals are related to DTR input and CTS is tied to RTS as shown. The Comm port supports full software XON/XOFF handshaking on data (AT commands bypass this as standard for Hayes modems) or full hardware handshaking on RTS/CTS with DCD carrier indication.
  • Page 23: Radio Interface

    Radio Interface The Remote Status Indicator port provides audio and control/status for interfacing to an external radio. (Cables can be supplied when ordered extra). Pin No. Signal Direction Function nPTT Output Key transmitter. Active low. Requires external 15K ohm pull-up. Max 16V Sat UP Input Rx Audio (unbalanced) from radio for satellite uplink.
  • Page 24 nPTT nRSQ. The PWR input must be connected to a DC supply of 10-32V Connect the DIAL input via a switch to the GND (not GNDi) signal. Connecting directly to GND will disable autodial capability. Page 24 of 31...
  • Page 25: Troubleshooting

    Troubleshooting This chapter provides information to help you troubleshoot problems you may encounter while running the RST820. No lights on RST820 Check that DC power cable is correctly attached and the external supply is adequately specified. No dial tone Check if a data call is in progress and power is connected and equipment is in a normal state Cannot make call, two tone signal heard Phone requires a PIN or PUK, refer to the handbook...
  • Page 26 Your PIN2 is locked. Enter the PIN2 unblocking key (PUK2) or contact our service provider. Your SIM card won’t w ork. Is the card inserted the correct way? Is the gold chip visibly damaged or scratched? Return the card to your service provider.
  • Page 27: Configuration - Technical Notes

    CONFIG port on the SatRADIO with a direct 9 pin serial cable. A utility called “BMS” (Beam Management System) provided on the CD should be installed on the PC. You will need a supervisor PIN in order to be able to use the BMS.
  • Page 28 Gains, Upstream, Downstream & Tones may need to be optimised for a particular radio. Different radio manufacturers have different line levels on their radio interface connections, and therefore to get the best audio these gains may need to be adjusted. VOX threshold.
  • Page 29: Specification Summary

    Specification Summary Electrical Input Power 10-32VDC 5A Power Consumption (Average Power) Standby Mode Talk/Transmit Mode Receive 7W Transmit 7W Intelligent Satellite Handset Voltage +12VDC Audio Line level Digital Control 115kbps RS232 RF Interface (L-Band Transceiver) Frequency range 1616MHz to 1626.5MHz Average Power 7W during a transmit slot (max) Average Power...
  • Page 30 Environmental Operational Temperature -30°C to +60°C Storage Temperature -40°C to +80°C Vibration MIL-STD-810F 514.5 Temperature MIL-STD-810F 501.4 Humidity MIL-STD-810F 507.4 Product Sealing IEC529 rating IP54 Certification RST820 EMC/EMI Compliance EN61000-6-2, EN61000-6-4, EN61000-3-2, EN61000-3- 3, FCC Part 15B Class A, C Tick CISPR22 Class A Additional Certification for Iridium Transceiver: The following harmonised standards have been applied to the design of the L-band transceiver: Standard...
  • Page 31: Beam Warranty Conditions

    The Customer’s sole and exclusive remedy and the limit of BEAM liability for any loss whatsoever, shall not exceed the purchase price paid by the Customer for the product to which a claim is made.
