- Page 1 Herni USER MANUAL Version: 04-2020...
-
Page 2: Table Of Contents
Herni Table of contents I. General information Page Introduction Purpose and indication Relevant information Warranty Service and repair Practical instructions Declaration of conformity Installation in the car - with ISOFIX Adjusting the head rest 1.10 Using the 3-point-harness II. Safety instructions Safety instructions III. -
Page 3: General Information Page
I. General information 1.1 Introduction You have chosen the car seat "IPAI-LGT" and get hereby a high quality product from our house. We would like to thank you for your trust in us. To make sure you find joy with this product and to ensure it helps you to make everyday life easier, we present you this manual. -
Page 4: Relevant Information
1.5 Service and repair Service and repairs on the IPAI-LGT may only be carried out by specialized dealers. If you have any problems, contact your local dealer. For repairs you will only receive original spare parts. -
Page 5: Declaration Of Conformity
Herni I. General information 1.3 Relevant information 1.7 Declaration of conformity • Page 4 •... -
Page 6: Installation In The Car - With Isofix
Herni I. General information 1.8 Installation in the car - with ISOFIX The IPAI-LGT will be installed tightly with the ISOFIX-locking arms (05) in your car. Your child will then be buckled up with the vehicle‘s 3- point belt. 1. If your vehicle is not equipped with ISOFIX... -
Page 7: Adjusting The Head Rest
Herni I. General information 7. Push both ISOFIX locking arms (05) into the insertion aids (02) until the ISOFIX locking arms (05) snap into place on both sides with a „click“ sound. ATTENTION! The green safety button (07) must be visible on both sides so that the child seat is properly attached. -
Page 8: Using The 3-Point-Harness
Herni I. General information 3. Place the child seat on the vehicle seat. 4. Let your child sit down in the child seat and check the height. Repeat this process until the headrest (22) is at the correct height. 1.10 Using the 3-point-harness 1. - Page 9 Herni I. General information 4. Place the lap belt (15) also on the other side of the seat cushion in the light red belt guide (04). ATTENTION! The lap belt (15) must run as low as possible over your child‘s hips on both sides. 5.
-
Page 10: Safety Instructions
Herni II. Safety instructions · Before use, the components must be checked for perfect function and condition. · The user manual must always be carried with the child car seat. · The safety of your child is only guaranteed if the seat is installed correctly and if the child is fixed exactly. -
Page 11: Handling And Functions Of The Basic Seat
3.2 Positioning of side supports As standard, the IPAI-LGT is equipped with a pair of anatomically shaped thorax pads . This can support children with poor upper body control in their posture. -
Page 12: Adjusting The Back Angle
Herni III. Handling and functions of the basic seat 3.3 Adjusting the back angle If the IPAI-LGT was installed in the car using ISOFIX, it is possible to pull the seat unit forward by driving out the ISOFIX tabs... -
Page 13: Using The Optional Accessories
Herni IV. Using the optional accessories 4.1 Wedge pillow fig. 1 Installation instructions: 1. Place the IPAI-LGT on a stable work surface. 2. Now take the wedge pillow as well as the 4 Velcro strips from the packaging. -
Page 14: Abduction Block
Herni IV. Using the optional accessories 4.2 Abduction block fig. 1 Installation instructions: 1. Place the IPAI-LGT on a stable work surface. 2. Now take the mounting plate , the two Velcro strips , and the abduction block out of the packaging. -
Page 15: Security Tray
4.4 Protection mat 1. Position the mat on the car seat without blocking the ISOFIX connectors. 2. Place the IPAI-LGT in the center of the protection mat and secure it as described in chapter 1.8 to 1.10. • Page 14•... -
Page 16: Belt To Connect The Chest Straps
Herni IV. Using the optional accessories 4.5 Belts to connect the chest straps fig. 1 1. Remove the belt end caps . Now thread the . belts out of the belt adjusters 2. Now guide the belt through the belt clip shown in figure 2. -
Page 17: Guarantee
• 24 months warranty on all solid parts from date of delivery. • 12 months warranty on all moving parts from date of delivery. For parts that were not manufactured by Hernik GMBH, please refer to the warranty policy of the respective manufacturer (Römer-Britax Kindersicherheit GmbH). -
Page 18: Maintenance & Product Care
VII. Maintenance & product care 7.1 Pulling of the cover Please ensure that you only use original BRITAX- RÖMER or HERNIK replacement seat covers, as the seat cover is an integral part of the child safety seat and fulfills important functions to ensure the perfect functioning of the seat. -
Page 19: Technical Characteristics
Herni VIII. Technical characteristics Standard equipment: • 5-point-harness with upholstery, height adjustable • ISOFIX adapter, adjustable • head rest, height adjustable • side impact protection SICT • three parts, removable and breathable cover (washable at 30 °C) • side supports, height adjustable •... - Page 20 Herni HERNIK GmbH Bodenseestrasse 25 83059 Kolbermoor • Germany +49 8031-2068044 • +49 8031-2069215 info@hernik.de • www.hernik.de • Seite 13 •...
