- Page 1 Herni USER MANUAL version: 07-2019...
-
Page 2: Table Of Contents
Herni TABLE OF CONTENTS I. General information Seite Introduction Purpose and indication Relevant information Declaration of conformity Warranty Service and repair Practical instructions Using the 3-point-harness of the vehicle (Group I) Buckling the child 1.10 Using the 3-point-harness of the vehicle (Group III) II. -
Page 3: Introduction
Yours HERNIK GmbH 1.2 Purpose and indication The STARLIGHT-NXT was developed for the transport of children with special needs in cars. Children with poor head or trunk control (eg infantile cerebral palsy,... -
Page 4: Relevant Information
HERNIK GmbH. 1.4 Declaration of conformity HERNIK GmbH declares in sole responsibility that car seat "STARLIGHT-NXT" complies with the Essential Requirements (Appendix 1 of Directive 93/42 EEC). The product is marked with the CE mark according to the above mentioned directive. -
Page 5: Using The 3-Point-Harness Of The Vehicle (Group I)
Herni I. Allgemeine Informationen 1.8 Using the 3-point-harness of the vehicle (Group I) To be able to absorb the enormous forces during an accident, the STARLIGHT-NXT must be secured with the vehicle's three-point belt according to ECE 44/04 Group I, II + III. An ISOFIX connection alone is not sufficing!!! The fixation as Group I show the following pictures: •... -
Page 6: Buckling The Child
Herni I. General information 1.9 Buckling the child • Loosen the shoulder straps (02) • Open the buckle (15) by pressing the red tab • Put your child in the child seat. • Pass the shoulder straps (02) over your child's shoulders. -
Page 7: Using The 3-Point-Harness Of The Vehicle (Group Iii)
Herni I. General information 1.10 Using the 3-point-harness of the vehicle (Group III) To be able to absorb the enormous forces during an accident, the STARLIGHT-NXT must be secured with the vehicle's three-point belt according to ECE 44/04 Group I, II + III. An ISOFIX connection alone is not sufficing!!! The fixation as Group III show the following pictures: •... -
Page 8: Safety Instructions
Herni II. Safety instructions · Before use, the components must be checked for perfect function and condition. · The instructions for use must always be carried on the child car seat. · The safety of your child is only guaranteed if the seat is installed correctly and if the child is fixed exactly. -
Page 9: Height Adjustment Of The Headrest
Herni III. Height adjustment of the headrest Fig.1 • Pull the locking bracket lightly on the backrest of the seat until it releases from the toothing. Move it together with the headrest to the desired position. Finally, release the bracket so that it can engage again - see Fig. -
Page 10: Installation Of The Xl-Kit
Herni IV. Installation of the XL-Kit Fig. 1 (components) • The XL-Kit allows you to use the STARLIGHT- NXT even for older children (1.20 m max.). If the car seat has not already been ordered with the XL kit, it can be retrofitted with it. The XL-Kit consists of: ... - Page 11 Herni IV. Installation of the XL-Kit Fig. 4 • Pass the strap ends of the beltpad through the openings below the headrest (Fig. 4 + 5) and hook them into the Y-connection part. The Y-connector remains in place as seen in Fig.
- Page 12 Herni IV. Installation des XL-Kits Fig. 7 • If thorax supports were installed, the adapter plate must now be attached - see Fig. 7. To do this, the headrest must be pulled out completely and two strips of self-adhesive loop tape (included in delivery, adhering to the adapter plate) to be glued to the red marked ...
-
Page 13: Using The Optional Accessories
Herni V. Using the optional accessories 5.1 ISOFIX-adapter Installation: 1. Let the installation of the seat and its adjustment been demonstrated to you by the technician. 2. Open the setscrews on the left and right and pull the bracket out to the rear. 3. -
Page 14: Clamp Bow
Herni V. Using the optional accessories 5.2 Clamp bow Installation: 1. Let the installation of the seat and adjustment of it be shown to you during the delivery. 2. Open the setscrews on the left and right and pull the bracket to the rear. 3. -
Page 15: Security Tray
Do not use hard, solid or even sharp- edged objects! 5.4 Lateral supports 1. HERNIK GmbH is not allowed to injure (drill, screw) the body of the STARLIGHT-NXT. Nevertheless it was very important to us to offer lateral supports... -
Page 16: Abduction Block
Herni V. Using the optional accessories 5.5 Abduction block 1. The abduction wedge helps your child to reach a predetermined distance between the knees. In order to loosen or tightening the 5- point belt, the wedge must be removed. ... -
Page 17: Foot Rest / Foot Roll
Herni V. Using the optional accessories 5.7 Foot rest / foot roll 1. The tabs are fixed below the car seat by means of set screws on the base mount, so that the depth can be adjusted. 2. The angle of the handrails can be varied by ... -
Page 18: Guarantee
• 24 months warranty on all solid parts, from date of delivery. • 12 months warranty on all moving parts, from date of delivery. For parts that were not manufactured by Hernik GMBH, please refer to the warranty policy of the respective manufacturer (Römer-Britax Kindersicherheit GmbH). -
Page 19: Maintenance & Product Care
Herni VIII. Maintenance & product care 1. Every 8 weeks check the screw connections for tightness and retighten if necessary. 2. Periodically clean with a dry cloth; if heavily soiled, clean with a mild household cleaner. 3. Remove the cover: •... - Page 20 Herni HERNIK GmbH Auf der Gröb 2 c 83064 Raubling • Germany +49 8035-9580448 • +49 8035-9580446 info@hernik.de • www.hernik.de • Seite 13 •...
