INPUTS
Auriculares HDMI1
VIDEO y L AUDIO R: This connection are used to connect devices with RCA
type cable, red, white and yellow. This is an input socket, and it cannot output
the TV sound.
VGA: Connects the PC or another audio/video device with a VGA cable.
ANTENNA: ANTENNA: Used to connect the TV antenna. It can tune analogue
or DTV channels, both DVB-T and DVB-C. The tuner is not compatible with 4K.
YPbPr: Connects to an external device via composite video (YPbPr).
HEADPHONES: Headphones output.
HDMI: Connects an external device via HDMI. Ports 1 and 2 are 2.0 compatible
and must be used when you want to see 4K content. No other connectors are
capable of playing 4K signals.
CI+: CI+ port slot.
USB: Allows to access digital content stored in a USB memory.
DIGITAL SOUND: Connects the audio output with a digital/standard audio
system.
PC AUDIO: This input is used to play the PC sound on the TV.
2.0 HDMI2 PC AUDIO VGA VIDEO
47
S.SONIDO
L AUDIO R
DIGITAL
