  • Page 1 TV LED PANTALLA ANCHA 24”/32”/40” K24DLM7F K32DLM7H K40DLM7F MANUAL DE USUARIO ..............1 USER MANUAL ................45 MANUEL UTILISATEUR..............89 BENUTZERHANDBUCH..............133 MANUAL DO USUÁRIO..............177 MANUAL DEL USUARIO Lea atentamente este manual antes del uso y consérvelo como referencia en el futuro. www.tdsystems.es...
  • Page 2 IMPORTANT INSTRUCTIONS SAFETY INSTRUCTIONS The exclamation The lightning flash and CAUTION: TO REDUCE THE RISK point within the arrow head within the triangle is a warning OF ELECTRIC SHOCK. DO NOT triangle is a warning sign alerting you of REMOVE COVER (OR BACK). important sign alerting you of NO USER SERVICEABLE PARTS...
  • Page 3 - If the product does not operate when used according to the operating instructions. choice for any servicing or repair. CAUTION- TO REDUCE THE RISK OR PERSONAL INJURY OR PRODUCT/PROPERTY DAMAGE: as a television. Do not use this product for any other purpose. periods of direct sunlight.
  • Page 4 DISPOSAL OF OLD ELECTRICAL APPLIANCES separately in order to optimize the recovery and recycling of the materials they Consumers should contact their local authority or retailer for information concerning the correct disposal of their old appliance. for long periods of time. ACCESSORIES IMPORTANT INSTRUCTIONS ................45 BATTERY HANDLING AND USAGE ..............46...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS FEATURES .............. GETTING STARTED BUTTON FUNCTIONS ..................52 CONNECTING EXTERNAL DEVICES ..............55 CONNECTING EXTERNAL DEVICES TO YOUR LED TV ........55 SETTINGS .......................58 INITIAL SETUP ....................58 NNECT EXTERNAL ANTENNA TO UNIT ............58 HDMI CONNECTION AV (COMPOSITE VIDEO) CONNECTION YPBPR CONNECTION USB CONNECTION SELECT INPUT SOURCE .................62 MAIN MENU OPERATION ................63...
  • Page 6 FEATURES 24”/32”/40” LED Display With Hotel Lock Support Auto TV Scanning Support Digital Broadcasting Reception Support TV Guide Function Support TELETEXT (Europe) Function Support USB Multimedia Playback Support Multi-languages On Screen Display Support Full Function Remote Control Support HDMI, YPBPR AV, VGA, PC AUDIO a nd CI Input Support EARPHONE and COAXIAL Output Support PVR Function Support TIME SHIFT Function...
  • Page 7 What is Included/TV Placement Setup Unit and Accessories Stand Support AUDIO 24”/32”/40” WIDESCREEN LED TV K24DLM7F K32DLM7H K40DLM7F DTV/RADIO TEXT INFO ENTRADA MENU SALIR Base Stand USER MANUAL IMAGEN SONIDO TAMAÑO GUÍA DETENER GRABAR LIST Please read this manual carefully before using, and keep it for future reference.

  • Page 8: Getting Started

    K40DLM7F 200mm 200mm Four mounting holes (size M6 screw) 4 Screws 4*15BBH Wall Mounting The TV is provided with mounting holes for a VESA approved wall mounting bracket (NOT SUPPLIED). The VESA mounting pattern is 100X100mm/200 x 100mm/200X 200mm. Remove the screws holding the base to the base bracket and lift the base away (do not remove the base mounting brackets).

  • Page 9: Button Functions

    K24DLM7F VOL+ VOL- MENÚ ENTRADA K32DLM7H VOL+ VOL- MENÚ ENTRADA Button Functions 2. ENTRADA : To select the input source. 3. MENÚ : To enter menu setting page. 4. VOL- : To decrease the volume level. 5. VOL+ : To increase the volume level.
  • Page 10 S.SONIDO Auriculares VIDEO AUDIO PC AUDIO ANTENA DIGITAL K24DLM7F PC AUDIO VIDEO AUDIO ANTENA HDMI1 K32DLM7H...
  • Page 11 PC AUDIO VIDEO AUDIO ANTENA HDMI1 Auriculares Auriculares of the tv will not sound. 2. USB charger. 3. CI+: Connect a CI module 4. YPbPr(mini) 5. S.SONIDO DIGITAL: This port is to extract the sound from the tv. 6. HDMI 7.

  • Page 12: Connecting External Devices

    Connecting to External Devices Connecting external devices to your LED TV PC AUDIO VIDEO AUDIO ANTENA HDMI1 Audio cable cable HDMI cable VHF/UHF antenna RF Coaxial cable Composite cable cable TV cable receiver/satellite box company Component cable...
  • Page 13 AUDIO AUDIO:Switch the audio channel when DVD or multimedia playing. :Auto Power Off Timer. FAV: Show the list of favourite channels. 0-9: Change the channel directly. DTV/RADIO enter DTV or RADIO mode. Return to the previous channel tuned. VOL: Increase and decrease volume. TEXT P: Next and Previous channel.
  • Page 14 TAMAÑO Press to select the different picture size. AUDIO GUÍA Show the Electronic Program Guide. : Freeze a multi-page changing on Teletext mode. TS:In DETENER/ GRABAR/ LIST: :Previous file or chapter. :Next file or chapter. TEXT INFO ENTRADA :Press the appropriate colour to direct access functions in TELETEXT or EPG OSD mode.

  • Page 15: Settings

    Settings Initial Setup NOTE: The picture is for reference only. CONNECT EXTERNAL ANTENNA TO UNIT Install external antenna into antenna jack for best picture. Antenna Outdoor antenna amplifier Indoor antenna amplifier 75 OHM Power plug antenn of antenna plug amplifier...

  • Page 16: Hdmi Connection

    HDMI CONNECTION HDMI3 ANTENA S.SONIDO HDMI2 HDMI3 DIGITAL YPbPr(mini) multimedia signal PC/VGA CONNECTION PC AUDIO VIDEO AUDIO use this product as a monitor.

  • Page 17: Av (Composite Video) Connection

    AV (COMPOSITE VIDEO) CONNECTION PC AUDIO VIDEO AUDIO YPBPR CONNECTION HDMI3 ANTENA S.SONIDO HDMI2 HDMI3 DIGITAL YPbPr(mini) use this product as a monitor.

  • Page 18: Usb Connection

    COAXIAL CONNECTION HDMI3 ANTENA S.SONIDO HDMI2 HDMI3 DIGITAL YPbPr(mini) or other audio decoding devices for coaxial audio signal output. USB CONNECTION Auriculares USB Memory Device INSERT A CI CARD HDMI3 S.SONIDO ANTENA HDMI2 HDMI3 DIGITAL YPbPr(mini) Insert your CI card (Conditional Access Module) to watch special digital channels in your area.

  • Page 19: Select Input Source

    EARPHONE CONNECTION Auriculares SELECT INPUT SOURCE First Time Installation Select Language Select Country...

  • Page 20: Main Menu Operation

    Auto Tuning Main Menu Operation Channel Menu-DTV Press MENÚ menu. previous menu.
  • Page 21 Auto Tuning ATV Manual Tuning Current CH Colour System Select the colour system Sound System Select the Sound system Fine-Turn Search Start searching channel DTV Manual Tuning Press Press...
  • Page 22 Program Edit Schedule List...
  • Page 23 it will produce a warning message. Signal Information...

  • Page 24: Picture Menu

    Picture Menu Press MENÚ menu. MENÚ previous menu. Picture Mode the picture is in Personal mode. TIPS:...
  • Page 25 Contrast/ Brightness/ Colour/ Tint / Sharpness Contrast Brightness Colour Tint Use in compensating colour changed with the transmission in the NTSC code. Sharpness Colour Temp menu. User mode. Cold Normal Set to default colour temperature. Warm Increase the red colour for the white. Noise Reduction To filter out and reduces the image noise and improve picture quality.

  • Page 26: Sound Menu

    Select to turn off video noise detection. Detect and reduce low video noise. Middle Detect and reduce moderate video noise. High Detect and reduce enhanced video noise. Default Set as Default. Sound Menu SOUND menu. previous menu.
  • Page 27 Sound Mode Mode directly. Standard Music Preserves the original sound.Good for musical programs. Movie Sports Enhances vocals for sports. Personal Select to customize picture settings. Balance Mode directly. Auto Volume level On or Off. SPDIF Mode...

  • Page 28: Time Menu

    AD Switch It need codestream to support. NOTE: your position. program’s volume automatically. Time Menu Press MENÚ menu. Time Zone...

  • Page 29: Sleep Timer

    Sleep Timer Auto Standby...
  • Page 30 OSD Timer Lock Menu Press MENÚ SYSTEM menu. MENÚ menu...
  • Page 31 Lock System options valid. ， Set Password password. Channel Lock...

  • Page 32: Hotel Mode

    Parental Guidance children. Key Lock Hotel Mode MENÚ previous menu. Hotel Mode...

  • Page 33: Setup Menu

    Source Lock select. Default Source to select. Default Prog Max Volume Import Database Export Database Clear Lock Setup Menu Press MENÚ...

  • Page 34: Osd Language

    menu. OSD Language is selected as menu language. TT Language Audio Languages...
  • Page 35 Subtitle Language Hearing Impaired PVR File System...

  • Page 36: Hdmi Cec

    Aspect Ratio Blue Screen First Time Installation Reset Software Update(USB) HDMI CEC...

  • Page 37: Epg

    CEC Control Audio Receiver Device Auto Power Off TV Auto Power On Device List Device Menu FAVORITE LIST on remote control to enter Favorite List menu page. preferred channel. NOTE: of “DTV Mode > Channel > Programme Edit”...
  • Page 38 Quick select enter Channel List menu page. preferred channel. a channel group. Screen Menu Press MENÚ H-Offset V-Offset...

  • Page 39: Media Operation

    Size Phase Position Reset Media OPERATION set the Input Source to Media .
  • Page 40 Photo Menu...
  • Page 41 Music Menu to enter.
  • Page 42 Movie Menu enter.

  • Page 43: Multimedia Playback Format

    MULTIMEDIA PLAYBACK FORMAT Codec Media File Ext. Remark Audio Video .mpg .avi HEVC .mov MOVIE HEVC .dat .mp4 HEVC MPEG-2 Sample Rate: 8K~48KHz .mp3 MUSIC PHOTO Non-Interlaced .png Interlaced .srt .smi SAMI SUBTITLE .txt TMPlayer...

  • Page 44: Specifications

    The different chip suffix will support different codec. SPECIFICATIONS MODELO K24DLM7F K32DLM7H K40DLM7F Panel size 24” 32” Brightness Static Contrast PC AUDIO Conectividade I / O HDMI Headphone COAXIAL Measurements Stand weight Weight gross weight Power Source Power Consumption Specifications are subject to change without notice!
  • Page 45 Test parameters for measurements The measurement method used 27.5℃ 27.5℃ 27.5℃ temperature(℃) Test voltage in V and FREQUENCY IN HZ Total harmonic distortion (THD) of the electricity supply system HDMI mode HDMI mode HDMI mode Input terminal for the audio and video test content video signal(as content video signal(as content video signal(as...
