Customer Information The Pro-24 (Model RP-224) complies with FCC Part 68 Rules. On the upper panel of this product is a label that contains, among other information, the FCC Registration Number and Ringer Equivalence Number (REN is 0.8B). If requested, this information must be provided to the telephone company.
Zone Expansion In addition to its eight hardwired zones, the Pro-24 can support up to another 16 such zones (24 total) which are derived through the connection of either 8 hardwired and 8 wireless zones or 16 wireless zones (8 or 16 wireless expanders module).
Page 6
Partitions Any zone or group of zones can be assigned to any of 8 independent partitions. Partitioning allows a single Pro-24 to protect each dwelling in a multi-family house, several departments in a commercial or institutional facility, and even several closely situated stores a strip mall. Each partition supports zone-sharing and cross-zoning.
Page 7
Power Supply Expansion Although the Pro-24’s Main Board provides 600 mA of auxiliary power, 250 for Switch Aux and 900 for Bell, the use of a number of additional system modules and detectors will likely exceed this limitation. As a result, the Pro- 24 permits the addition of up to eight remoteable Power Supply Expansion Modules, each operating from AC power and connected to the 4-wire BUS.
Page 8
Printer Adapter Module (Not for UL Installations) A printer module, designed to interface between the Pro-24’s 4-wire Expansion Bus and a Centronics-type parallel printer, will allow for the printing of all significant system events, as they occur, including Access Control activities (see above) if applicable.
Page 9
Figure 1-2, on page 1-6, provides an overview of the Pro-24’s architecture and capabilities. You may wish to look this figure over to obtain a “big picture” of the system before continuing.
The Pro-24 is sold with one of four keypads, a metal cabinet, and various accessories. Figure 1-3 shows the typical packaging contents. Refer to Table 1-1, below, and Table 1-2, which begins on page 1-8, for further information. Description: Panel and Keypad Product No.
Page 12
RP296EBA00A Bus Adapter (Cable) used for local PC-based Uploading/Downloading operations: connected between a PC’s serial (COM) port and the Pro-24’s J1 connector; requires Upload/Download software (above) and includes a required converter adapter terminated in a female DB25-type connector (it may be necessary to obtain a 25-pin male to 9-pin female adapter if required by your PC’s COM Port)
Page 13
Control Panel Input Power: 16.5 Volts AC @ 40 Volt-Amps (VA) (via transformer) Rechargeable Standby Battery: 12 Volts 6 Amp-Hours (AH), typical Power Outputs Auxiliary Power: 12 Volts DC @ 600 mA, maximum 12 Volts DC @ 160 mA, max. for UL installations Switched Auxiliary: 12 Volts DC @ 250 mA, maximum ** 12 Volts DC @ 80 mA, max.
Page 14
Power Supply Expansion Module Input Power: 16.5 Volts AC @ 40 VA (via transformer) Rechargeable Standby Battery: 12 Volts 6 Amp-Hours (AH), typical Power Outputs Auxiliary Power: 12 Volts DC @ 600 mA, maximum Bell/LS (External) Sounder Output: 12 Volts DC @ 900 mA, maximum Control Panel Connection: 4-wire BUS, up to 1000 ft (300m) from panel Dimensions:...
Because such pipes ultimately route their way into the earth, the attachment, to the pipe, of a suitable metal clamp and a length of wire can make an effective ground connection for the Pro-24.
(e.g. 22-16) which takes into account the number of detectors and the amount of wire required only 4-wire Smoke Detectors can be used with the Pro-24; 2-wire Smoke Detectors are not supported for proper 4-wire Smoke Detector supervision, a Power Supervision Relay is required.
Page 17
Wiring to External Sounders connect suitable wire to the external sounding device(s), whether a bell, an electronic siren, or a loudspeaker External Sounders consider a larger wire gauge (e.g. 18-16) if the distance separating the BELL/S sounder(s) and the panel is significant; consider also the sounder’(s)s + –...
Page 18
(refer to Figures 2-2, 2-3, 2-5, and 2-6: found on pages 2-9, 2-10, 2-11, and 2-11, respectively) Prepare each Keypad(s) and Expansion Module(s) you plan to install according to the information found in the table below: COMPONENT/MODULE AREA COMMENTS Keypads and Program each device’s I.D.
Page 19
Wiring the Zone Expansion Module(s) TERMINALS COMMENTS each Zone Expansion Module must be given a unique I.D. number identifying it to the system; if not yet done, use the table on page 2-4 to set DIP Switches the DIP switches appropriately; the first Expansion Module must be given the I.D.
Page 20
Wiring the Power Supply Expansion Module CONNECTIONS COMMENTS each Power Supply (Expansion) Module must be given a unique DIP Switches I.D. number identifying it to the system; use the table on page 2-4 to set the DIP switches appropriately the first four terminals at the left of the Power Supply Module are for the connection to the Expansion Bus, originating at the Main Board because the Power Supply Module has its own source of power-derived through its connection to AC Power-do NOT connect the RED wire from...
One of the necessary factors required in making for a successful installation is the proper use of wire and cable. Like all hardwired security systems, the Pro-24 relies on wire to carry power and data to the Keypads, Expansion Modules, detectors, and any external sounder(s) which may be part of the installation. If the wire is too long or not thick enough for the quantity and types of components in use, excessive voltage drops could develop and deprive such devices of sufficient power–resulting in unreliable system operation and weak-sounding annunciators.
Page 22
40 – 60 ft 12 – 20 m 60 – 100 ft 20 – 30 m Table 2-2: Wiring Between the Pro-24 Main Board and the 16.5VAC / 40VA Plug-In Transformer Maximum Combined Length Wire Gauge of All Expansion BUS Wiring...
Page 23
Figure 2-1 Figure 2-2 Installation and Programming Manual...
Page 24
Figure 2-3 Zone Terminations Figure 2-4 Closed-circuit and Open-circuit loops: Not for use in UL Installations 2-10 Installation and Programming Manual...
Section 3: Programming Your Pro-24 As a source of general reference, the following table lists the options available when programming an Pro-24 installation. Except for this reference, this section will concern itself only with such programming from an LCD Keypad only.
Page 28
A. Preparing the LCD Keypad: 1- Remove all Power from Your Pro-24 a) If your Pro-24 has NOT been wired to an LCD Keypad, remove all power (AC and Standby Battery) if present, and skip to Step 2. b) If your Pro-24 and at least one LCD Keypad have already been physically installed and/or wired together, remove all power (AC and Standby Battery) if present, and skip to Step 3.
Page 29
Pro-24 has: already been programmed c) carefully enter the Pro-24’s default Installer Code: [ 0 protected the programmed configuration ] [ 2 ] [ 9 ] [ 6 ] (which will appear as ,,,,) and...
Page 30
DATA IS SAVED DATA IS SAVED PLEASE WAIT ... PLEASE WAIT ... k) after a moment, the system will enter its ordinary j) when the Pro-24’s factory defaults have been operating mode restored, this display will appear PARTITION 1 PARTITION 1 --:-- ...
The LCD Keypad has been designed to assist not only the alarm system user, but the installer, as well, in the programming of all system’s parameters. The elements of the LCD Keypad are shown in Figure 3-1 see below, and described in Table 3-2 see page 3-5. Figure 3-1: The LCD Keypad The keys on the LCD Keypad have multiple uses that depend upon the operation being performed.
3-5 to reference the item call outs. The Pro-24 permits a total of 74 characters (letters, numbers, and symbols) for use in labeling. A list of these characters is found in the lower half of the table. A sample exercise is provided at the bottom of the page.
Page 33
The LCD Keypad offers you the facility to navigate through the menu structure as you see fit–to reach your desired destination(s). Before beginning, be sure your Pro-24 is connected to an LCD Keypad which has been given the physical I.D. of “01”, and to a power source (AC and Standby Battery). After applying power to your system, locate the display produced by your keypad.
Page 34
INSTALLER PROG: 1)SYSTEM ↓ The SYSTEM category is one of Pro-24’s eight programming classifications. Each category contains one or more sub-categories–all of which contribute to the system’s total operation. Each of the eight classifications is listed and briefly summarized below:...
Page 35
INSTALLER PROG: Notice the arrow pointing down in the lower right of the display. It indicates that, in addition to the category known as 1)SYSTEM, there are more categories which 1)SYSTEM ↓ follow. Think of the eight programming classifications as a vertically-arranged list, shown INSTALLER PROG: at the left, through which you can navigate with either the UP-arrow (STAT) or 2)ZONES...
Page 36
UP-arrow to move the cursor available Zone Types: to the left and re-enter the proper digit(s). In the Pro-24, the type of zone described in the example is known You must press [ENTER] to confirm your as 10)I+INSTANT (meaning Interior + Instant).
Page 37
8- At this point, you may either can either press the DOWN-arrow once to press [ENTER] to save the changes you access the following display, made; they will be stored in the Pro-24’s ADD A MODULE: configuration until such time as they should 2)ZONE EXP.
Page 38
HOME IMPORTANT: 1. The shaded boxes refer to pages where more information about the topic can be found. 2. Confirm all programmed selections by pressing the [ENTER] key before going on to the next item. 3. To return to the “HOME” column, press the [.] key, as required, until any one of the categories in the “HOME”...
Page 39
Installation and Programming Manual 3-13...
Page 40
For example, to use Quick Keys to set or change the Bell Timeout period: first, from the normal Pro-24 User display enter the Installer Programming Mode by pressing [.] + [7] + [1], enter your Installer Code (the factory default is 0 2 9 6) and press [ENTER]...
Page 41
Fire Alarm Wireless Module time intervals relating to the operation of the wireless module Times specifies the amount of time that the Pro-24’s wireless module will tolerate unwanted radio frequencies capable of blocking (jamming) signals produced by the system’s transmitters...
Page 42
INSTALLER PROG: 1)SYSTEM ↓ SYSTEM: TIME DEFINE (cont’d) Quick Key Item Default Range Explanation TIME DEFINE (cont’d) specifies the Start Time and Zone Test Period for Zone Test Times Zone Testing (see page 3-32 for additional information) HR:00 00-24 this feature permits an automatic self- Start Test At: MIN:00 00-59...
Page 43
INSTALLER PROG: 1)SYSTEM ↓ SYSTEM: SYSTEM CONTROL Quick Key Item Default Explanation ↓ SYSTEM CONTROL Controls Specific System Operations Quick Arm if YES: eliminates the need for a User Code when arming to the STAY or AWAY modes if NO: a valid User Code is required for arming to STAY or AWAY 2 02 Quick UO...
Page 44
2 21 Summer/Winter Clock if YES: the Pro-24 will automatically set its Time of Day clock one hour ahead in the spring (on the first Sunday in April) to conform to USA Daylight Savings Time and one hour back in the fall (on the last Sunday...
Page 45
Initially, the pager’s phone number must be programmed as a “Follow-Me” device in the Pro-24’s User Functions if YES: allows enhanced event information to be provided to the numeric or alphanumeric pager, which will be delivered and displayed once the call is made.
Page 46
(see the Pro-24 User’s Manual for details) 3-20...
Page 47
Quick Key Item Default Explanation SYSTEM LABEL Creates and Edits System and Partition Labels RISCO Global Allows editing of the global (system) label PARTITION 1 Partitions 1 through 8 Allows editing of the label used to name each partition PARTITION 2...
Page 48
INSTALLER PROG: 1)SYSTEM ↓ SYSTEM: SERVICE INFORMATION Quick Key Item Default Explanation SERVICE Supplies Servicing Information Accessible to the INFORMATION System’s Users ORBIT allows the placement and/or editing of the name of the Service Name SECURITY alarm company from whom service may be obtained allows the placement and/or editing of the phone Service Phone SYSTEM...
Page 49
2) Zones The following parameters are used for programming the characteristics of each of the system’s protective zones. With the display showing: INSTALLER PROG: 2)ZONES ¤ press [ENTER] to begin. The first sub-category, ONE BY ONE, SUBJECT: ZONES 1)ONE BY ONE ↓...
Page 50
IMPORTANT: in One-By-One, the listing of each zone’s parameters are sequential; thus, once Zone 1’s parameters have been programmed, they will be followed by Zone 2’s, then Zone 3’s, and so forth if you choose to program one or more of the system’s zones using the One-By-One method, changes you make to any (or all) of the Zone Parameters will NOT be recorded unless you go through the entire One-by-One list–which ends with the Zone Label parameter...
Page 51
ZONES: ZONE PARTITIONS INSTALLER PROG: 2)ZONES ZONES: ZONE TYPE ↓ Quick Key Item Default Explanation PARTITIONS all zones programs the Partition Assignment(s) for each zone SUBJECT: ZONES assigned 2)PARTITIONS ¤ Partition 1 from this display, press [ENTER] specify its two-digit Zone Number press [ENTER] again P=12345678 Z=xx Y..
Page 52
INSTALLER PROG: ZONES: ZONE TYPE (cont’d) 2)ZONES ↓ Quick Key Item Default Explanation ZONE TYPE (cont’d) usually intended for non-entry/exit doors, window 3 xx Instant default for protection, shock detection (but generally NOT for all zones motion detectors) except causes an immediate intrusion alarm if violated (after the expiration of the Exit Delay) 1 and 2 I+Exit/Entry 1...
Page 53
INSTALLER PROG: ZONES: ZONE TYPE (cont’d) 2)ZONES ↓ Quick Key Item Default Explanation ZONE TYPE (cont’d) usually assigned to an infrequently-used door, a movable skylight, and, if used, to window foil protecting non-movable glass its intent is to alert the system user if a violation occurs during the disarmed period if the system is armed (to either AWAY or STAY): a violation of this zone causes an immediate intrusion...
Page 54
INSTALLER PROG: 2)ZONES ↓ ZONES: ZONE SOUND Quick Key Item Default Explanation ZONE SOUND programs ONLY the sounds produced when each of the system’s zones triggers an alarm reports to the Central Station, if programmed, are unaffected by any of the following selections to program the Zone Sound for any zone: a) from this display, press [ENTER] b) specify its two-digit Zone Number...
Page 55
ZONES: TERMINATION INSTALLER PROG: 2)ZONES ↓ ZONES: LOOP RESPONSE Quick Key Item Default Explanation TERMINATION programs ONLY the terminations used for each of the system’s zones the actual (physical) termination for each zone must be agree with that selected below a listing and explanation of zone terminations can be found in Figure 2-4 on page 2-10 SUBJECT: ZONES...
Page 56
9 minutes) before an alarm will result such linking may be appropriate for use with motion detectors in “hostile” or “false-alarm prone” environments the Pro-24 allows for 10 unique sets (pairs) of zone links (pairs of zones) which can be manually- specified, as required SUBJECT: ZONES 7)CROSS ZONES ¤...
Page 57
INSTALLER PROG: 2)ZONES ↓ ZONES: LABELS Quick Key Item Default Explanation LABELS ZONE 01 allows for the creation and/or editing of up to 10- ZONE 02 characters describing each of the system’s zones ZONE 03 SUBJECT: ZONES ZONE 04 8)LABELS ¤...
Page 58
INSTALLER PROG: 2)ZONES ↓ ZONES: MAINTENANCE Quick Key Item Explanation MAINTENANCE provides some useful tools to perform system maintenance Copy a Zone copies, to a designated zone, all the parameters belonging to a specified zone, except the “Label” parameter COPY ZONES: FROM :01 TO:01 use the cursor keys to select the zone from which a copy is to be made and the zone to which the copy is intended...
Page 59
(e.g. Zone I.D., Partition, Type, Sound, etc.) to any (NOVA) wireless detectors used in the system the capability to receive data from wireless detectors requires that the Pro-24 be equipped with at least one Wireless Zone Expander wireless background information for the Pro-24 is provided in the instructions furnished with the Wireless Expansion Module and the system’s individual transmitters...
Page 60
INSTALLER PROG: ZONES: MAINTENANCE (cont’d) 2)ZONES ↓ Quick Key Item Explanation Zone Self Test this feature provides an automated self test for a selected group of localized intrusion sensors (e.g. glass break detectors, sound Not for UL discriminators, shock sensors) which can respond to an artificial Installations source of noise and/or vibration automated self-testing is especially useful when such sensors...
Page 61
INSTALLER PROG: 2)ZONES ↓ ZONES: MAINTENANCE (cont’d) Quick Key Item Explanation Zone Self Test CHOOSING A TESTING SCHEDULE (cont’d) in Installer Programming, locate: 1)SYSTEM / 1)TIME DEFINE / 7)ZONE TEST TIMES TIME DEFINE: 7)Z.TEST TIMES ¤ when at this display, press [ENTER] to proceed: ZONE TEST TIMES 1)START TST AT:↓...
Page 62
INSTALLER PROG: 2)ZONES ↓ ZONES: MAINTENANCE (cont’d) Quick Key Item Explanation Zone Self Test UO=02 FOLLOWS: (cont’d) 1)SYSTEM ¤ and press [ENTER] SYS.EVENT: UO=02 1)BELL FOLLOW ↓ ii) at this display, press [8] SYS.EVENT: UO=02 8)SENSORS TEST ↑ iii) and press [ENTER] again PATTERN UO=01: 2)PULSE N/O ↑...
Page 63
INSTALLER PROG: 2)ZONES ↓ ZONES: MISCELLANEOUS Quick Key Item Default Explanation MISCELLANEOUS Forced Arming allows the enabling or disabling of forced arming for each of the system’s zones Not for UL forced arming, if enabled for a particular zone(s), Installations permits the system to be armed, even though such zones may be faulted if any zone(s) enabled for forced arming is faulted, the...
Page 64
3) Utility Outputs By adding one or more Utility Output Expansion Modules to the system, an extensive list of switched output possibilities become available. After selecting a System Event used to trigger the intended Utility Output, press [ENTER] to select the desired PATTERN OF OPERATION, and its duration. The programming parameters found in this section allow you to choose the event that will trigger a selected Utility Output, along with the manner in which the output will be applied.
Page 65
Explanation SYSTEM (cont’d) 3 xx Ground Pulse activates when the Pro-24’s dialer must dial out rarely used, this option is typically intended for older phone systems which require a “Ground Start” (a momentary connection between one side of the phone line and “earth” ground) to...
Page 66
INSTALLER PROG: 3) UO ↓ UTILITY OUTPUT: PARTITION Quick Key Utility Output Follows Default Explanation PARTITION the Utility Output will follow the chosen Partition Event, selected among those listed below: from this display: P=12345678 UO=xx Y..designate the partition(s) whose READY condition will activate the chosen Utility Output by using the [STAY] key to toggle between YES (Y) or NO () and either the [STAT] or [BYP] keys to move the...
Page 67
INSTALLER PROG: UTILITY OUTPUT: PARTITION (cont’d) 3) UO ↓ Quick Key Utility Output Follows Default Explanation PARTITION (cont’d) 2 10 activates the designated Utility Output whenever a Chime Follow keypad in the chosen partition (and programmed to do so), annunciates its CHIME; select by pressing [ENTER] 2 11 Exit/Entry/Follow...
Page 68
INSTALLER PROG: 3) UO ↓ UTILITY OUTPUT: ZONE Quick Key Utility Output Follows Default Explanation the Utility Output will follow the chosen ZONE Zone Event and Zone Number, selected among those listed below: after making your selections, press [ENTER] proceed to PATTERN of OPERATION, and period of duration.
Page 69
Installer Programming, the Quick Utility Output parameter under System Control is disabled (see page 3-17) also refer to the Pro-24’s User’s Manual for clarification and additional information about triggering Utility Output(s) via User Code(s) proceed to PATTERN of OPERATION, on page 3-44.
Page 70
INSTALLER PROG: 3) UO ↓ UTILITY OUTPUT (cont’d) Quick Key Pattern of Operation: Default Explanation choose among the following patterns for the selected utility output. Pulse N/C the Utility Output will always be activated (N/C) seconds before being triggered when triggered it will de-activate for the Pulse Duration specified below, then re- activate automatically if selected, press [ENTER] and choose the...
Page 71
4) Code Maintenance The Pro-24 supports up to 99 unique User Codes (known by a number from “00” through “98”)–each of which can identify different system users–either to the Central Station (if Opening and Closing Reports are utilized), or to those with the need to view the system’s Event Log (see the Pro-24 User’s Manual for details) to determine system...
Page 72
AUTHORITY LEVEL DEGREE OF ACCESS GENERAL COMMENTS • all privileges of the Manager, but with • there are no restrictions these restrictions: in the number of Master • restricted to assigning and changing codes (as long as they Master User Codes belonging to those with don’t exceed the number Authority Levels of Master and below of codes remaining in the...
Page 73
CODE MAINTENANCE: AUTHORITY INSTALLER PROG: 4)CODE MAINT. ↓ CODE MAINTENANCE: PARTITION Quick Key Item Default Explanation AUTHORITY USER used for designating the Authority Level for each of the 98 User Codes (which excludes the Grand Master code–whose Authority Level is fixed) the programmable Authority Levels are: Manager, Master, User, Arm Only, and Maid CODE AUTHORITY:...
Page 74
CODE MAINTENANCE: GRAND MASTER INSTALLER PROG: 4)CODE MAINT. ↓ CODE MAINTENANCE: INSTALLER Quick Key Item Default Explanation GRAND MASTER 1234 the Grand Master is the UserCode with the highest Authority Level (see page 3-46) the system’s owner/chief user can assign and modify the Grand Master code as a function of the User Functions mode;...
INSTALLER PROG: 4)CODE MAINT. ↓ CODE MAINTENANCE: SUB-INSTALLER Quick Key Item Default Explanation SUB-INSTALLER 0299 the Sub-Installer Code allows for limited access within the Installer Programming mode an individual given the Sub-Installer code can be thought of as an assistant to the “lead” Installer–but being restricted to changing only selected programming parameters it’s the job of the individual with the Installer Code to...
Page 76
INSTALLER PROG: 4)CODE MAINT. ↓ CODE MAINTENANCE: CODE LENGTH Quick Key Item Default Explanation • CODE LENGTH the Code Length specifies the number of digits (either 4 or 6) which must be used by the Grand Master, Manager, and Master Codes •...
Page 77
5) Dialer The following table provides instructions for programming all relevant information required for the Pro-24 to contact the Central Station and successfully transmit data With the display showing: INSTALLER PROG: 5)DIALER: ¤ press [ENTER] to begin. The first sub-category, TEL. NUMBERS will appear on the display. You may enter it by pressing [ENTER] OR by pressing the [1] key.
Page 78
INSTALLER PROG: 5)DAILER ↓ DIALER: COMMUNICATION FORMAT Quick Key Item Default Definition COMMUNICATION for each Central Station account in the installation, FORMAT choose the Communication Format, as specified by the Central Station, for reporting customer alarms, troubles, tests, and other events For 1 Telephone 0000...
Page 79
Item Default Explanation ACCESS AND ID specifies the Access and ID Codes required for successful remote communication (using RISCO Group’s Upload/Download software) between the Alarm Company and the Installation Access Code 5678 select a 4-digit Access Code which will be stored in...
Page 80
“Follow Me” communication Follow Me In addition to Central Station reporting, the Pro-24 employs a Follow-Me feature, in which a standard phone call–reporting a system event–can be made to a designated phone number. This procedure is generally useful for informing a homeowner at work, or a business owner at home, that there has been an alarm at a specific premises.
Page 81
Call Back U/D if YES: enables greater security for remote Upload/Download operations by requiring the Pro-24 to call back the pre- programmed telephone number (see Remote U/D Tel No. on page 3-51) to which the Alarm Company’s Upload/Download computer is connected if NO: the Alarm Company’s computer simply calls the...
Page 82
U/D Software calls the account again the Pro-24 picks up this call on the first ring, thus bypassing any interaction with the answering machine remote communication can subsequently take place...
Page 83
Override is enabled (see page 3-55), any entry made to this parameter will be ignored. refers to the number of seconds the Pro-24 will wait if the Dial Tone parameter is enabled (see page 3-54) Dial-tone Time press [ENTER] and select, by using either the...
Page 84
INSTALLER PROG: 5)DAILER ↓ DIALER: REPORT SPLIT Quick Key Item Default Explanation permits the routing of specified events to up REPORT SPLIT to three Central Station Receivers used to report Arming/Disarming (i.e. Closings/Openings) MS ARM/DISARM events to the Central Station for each of the six reporting options below, use the UP- or DOWN-arrow keys to scroll to the desired choice and press [ENTER]...
Page 85
User Functions mode (see the section on User Functions, in the Pro-24 User’s Manual) For each of the six reporting options below, use the or DOWN-arrow keys to scroll to the desired choice and Press [ENTER] Do not make any “Follow Me”...
Page 86
INSTALLER PROG: 5)DAILER ↓ DIALER: ALARM RESTORE Quick Key Item Default Explanation • ALARM RESTORE specifies under what conditions an Alarm Restoral will be reported • such reporting informs the Central Station that the specified condition(s) which occurred during the alarm has changed •...
Page 87
Default Explanation PERIODIC TEST MS Test for Pro-24 Test (Non-Urgent) Reports to the designated Central Station Receiver (see page 3-51), designate the specific time and daily interval that such reports will take place note that if Test Reports are to be sent, they have to...
Page 88
[STAY] and [ENTER] to confirm your choice press [.] to return to the previous programming level Delete All if selected, automatically causes the Pro-24 to reset, to “00”, all previously-programmed Central Station reporting codes (see pages 3-63 through 3-73) doing so does NOT cause any other programmed...
Page 89
6) Report Codes This section provides you with the opportunity to program the codes that will be transmitted by the Pro-24 when it has events to report (e.g. alarms, troubles, restores, supervisory, and tests, etc.) to the Central Station. Note the following: The codes specified for each type of event transmission are a function of the Central Station’s own policies.
Page 90
INSTALLER PROG: 6)REPORT CODES ↓ REPORT CODES: ZONES Quick Key Item Default Explanation ZONES used to report the codes generated when an alarm (or alarm restoral) is sent due to the violation of an armed zone Alarm press [ENTER] to: enter the 2-digit zone number and the corresponding 2-digit reporting code used to represent an alarm on the designated zone...
Page 91
INSTALLER PROG: 6)REPORT CODES ↓ REPORT CODES: ACCESSORY TAMPER Quick Key Item Default Explanation • ACCESSORY used to report the codes generated when the TAMPER tamper switch on a system accessory (i.e. a Keypad or Expansion Module) is violated (or restored) •...
Page 92
Wireless Button Accessory addresses the tamper codes and their restorals given to any wireless buttons used in the installation; press Not for UL [ENTER] Installations Tamper press [ENTER] to begin enter the Wireless Button’s 1-digit I.D. and the corresponding 2-digit report code used to represent a tamper condition Wireless Button Accessory...
Page 93
Pro-24 report code used to represent a trouble condition AC Loss related to the AC Power supplied to the Pro-24 report code used to represent a trouble condition AUX Fail related to the loss of Auxiliary Power (either...
Page 94
PS Module’s 1-digit physical I.D. and the 2- digit report code used to represent a trouble condition related to the AC Power supplied to the Pro-24 AUX Fail press [ENTER] to begin enter the PS Module’s 1-digit physical I.D. and the 2-...
Page 95
REPORT CODES: POWER SUPPLY ACCESSORY INSTALLER PROG: 6)REPORT CODES ↓ MODULE TROUBLE RESTORALS Quick Key Item Default Explanation • used to report the codes generated when the POWER SUPPLY following series of troubles related to the ACCESSORY operation of the Power Supply Accessory Module MODULE TROUBLE is detected (or restored) RESTORALS...
Page 96
Auto-Armed as a result of a previously-scheduled user-determined event note that no specific user identification is possible– see the Pro-24 User’s Manual for additional information Remote Armed press [ENTER] report code used when the system is Remotely-...
Page 97
Auto-Disarmed as a result of a previously-scheduled user-determined event note that no specific user identification is possible– see the Pro-24 User’s Manual for additional information Remote Disarmed press [ENTER] report code used when the system is Remotely-...
Page 98
[see page 3-32 for additional details Cancel Report press [ENTER] report code used when the system sends a user- initiated cancellation of an alarm in progress [see the Pro-24 User’s Manual for additional details] • SPECIAL use this area to supply any converted codes COMMUNICATION...
Page 99
REPORT CODES: ACCESSORY CODES Quick Key Item Default Explanation • ACCESSORY CODE use this area to supply the reporting codes governing the operation of these system Pro-24 Not for UL accessories: Wireless Zone Expansion Module Installations Wireless Button Module Wireless Button Printer Module •...
Page 100
INSTALLER PROG: 6)REPORT CODES ↓ REPORT CODES: ACCESSORY CODES (cont’d) Quick Key Item Default Explanation Wireless Button * press [ENTER] to access each sub-category, below Wireless Button Low report code used to represent its low battery Battery * condition Wireless Button Low report code used to represent the correction of its low Battery Restore * battery condition...
Page 101
4-wire BUS. Walk Testing, another system check (which is not a part of these tests, see page 3-84), can be easily performed from within the Pro-24’s User Functions mode. With the display showing: press [ENTER] to begin.
Page 102
INSTALLER PROG: 7)ACCESSORIES ↓ ACCESSORIES: ADD/DELETE MODULE (cont’d) Quick Key Item Default Explanation ADD/DELETE MODULE (cont’d) Keypad (cont’d) NONE ASSIGNING A PARTITION: ASSIGN TO PAR: KEYP=01 PAR= 1 using the keypad’s [1] through [8] keys, assign “Keypad 01” to the desired partition note that “non-partitioned”...
Page 103
INSTALLER PROG: 7)ACCESSORIES ↓ ACCESSORIES: ADD/DELETE MODULE (cont’d) Quick Key Item Default Explanation ADD/DELETE MODULE (cont’d) Zone Expander NONE at this display: ZONE EXPANDER: ID=1 TYPE=NONE using either the UP- or DOWN-arrow keys, position the cursor over the Zone Expander’s I.D. number for which you wish to assign (or delete) such a unit the first ZE must be assigned to the first I.D.
Page 104
INSTALLER PROG: ACCESSORIES: ADD/DELETE MODULE (cont’d) 7)ACCESSORIES ↓ Quick Key Item Default Explanation ADD/DELETE MODULE (cont’d) Utility Output Module NONE at this display: UTIL OUTPUT: ID=1 TYPE=NONE using either the UP- or DOWN-arrow keys, position the cursor over the Utility Output’s I.D. number for which you wish to assign (or delete) such a unit the first UO must be assigned to the first I.D.
Page 105
ACCESSORIES: ADD/DELETE MODULE (cont’d) INSTALLER PROG: 7)ACCESSORIES ↓ Quick Key Item Default Explanation ADD/DELETE MODULE (cont’d) Power Supply Module NONE at this display: POWER SUPPLY: ID=1 TYPE=NONE using either the UP- or DOWN-arrow keys, position the cursor over the Power Supply Module’s I.D. number for which you wish to assign (or delete) such a unit the first PS must be assigned to the first I.D.
Page 106
INSTALLER PROG: 7)ACCESSORIES ↓ ACCESSORIES: ADD/DELETE MODULE (cont’d) Quick Key Item Default Explanation ADD/DELETE MODULE (cont’d) Event Logging NONE at this display: EVENT LOG: Module TYPE=NONE with the cursor positioned over the “TYPE” field, press the [STAY] key to toggle between and choose among the four selections given: NONE LOG1 (built-in 128 Event Log)
Page 107
INSTALLER PROG: 7)ACCESSORIES ACCESSORIES: ADD/DELETE MODULE (cont’d) ↓ Quick Key Item Default Explanation ADD/DELETE MODULE (cont’d) Wireless Button NONE the Wireless Button Module is a wireless receiver add-on Module designed to process signals from up to eight handheld Wireless Button (arm/disarm/panic) transmitters Not for UL at this display: Installations...
Page 108
INSTALLER PROG: ACCESSORIES: ADD/DELETE MODULE (cont’d) 7)ACCESSORIES ↓ Quick Key Item Default Explanation ADD/DELETE Wireless Button Module (cont’d) MODULE (cont’d) PLEASE NOTE: the following display will appear if a Wireless ..DELETE.. ARE YOU SURE? Button Module is found and “NONE” has been selected; if so: press [ENTER] to return to the prior display press the [STAY] key to select “Y”, and press...
Page 109
ACCESSORIES: VERIFY MODULE INSTALLER PROG: 7)ACCESSORIES ↓ ACCESSORIES: BUS TEST Quick Key Item Explanation provides a convenient listing of all of the system’s VERIFY MODULE Keypads and Expansion Modules ACCESSORIES: from this display, press [ENTER] 2)VERIFY MDL ¤ VERIFY MODULE: LCD :01 = LCD ↓...
Page 110
When conducted within the User Functions mode, Walk-Testing permits any of the Pro-24’s keypads (whose “Local Buzzers” have been enabled under User Functions–see the Pro-24 User’s Manual) to briefly annunciate any and all zones which have been violated during the test.
Page 111
8) Miscellaneous This section of Installer Programming makes it possible for the Pro-24 to allocate the data it receives from any of the system’s Wireless Buttons–in a process often referred to as “learning-in”. For the system to utilize any Wireless Button, it needs to have installed both the Wireless Expansion Module, along with the Wireless Button Module.
Page 112
Exiting Programming Any changes you make to the programmed parameters are not saved until you properly exit the Installer Programming Mode. This category allows you to quickly save or discard the changes made during any programming session. INSTALLER PROG: 0)EXIT PROGRAM ↑ INSTALLER PROG: 0)EXIT PROGRAM ↓...
6- Without making any changes, exit the Installer Programming Mode. 7- The configuration in the Program Transfer Module’s has now been transferred to the Pro-24. You must now reset its TIME and DATE, which were lost when power was removed.
Page 114
PROGRAMMED SESCOA EVENT REPORTING EVENT ALPHA CODE DIGIT CODE (RECOMMENDED) Identified Opening Identified Closing Opening (Not Identified) Closing (Not Identified) 24 hour report AC Fail AC restoral Low Battery Low Bat. Rest Bell Trouble Bell Trouble Rest Phone Trouble Phone Trouble Rest Duress Opening Out Of Window Closing Out Of Window...
PROGRAMMED SIA EVENT EVENT DIGITS CODE AC restoral AC trouble dummy Burglary alarm Burglary cancelled Burglary alarm restore Burglary trouble restore Burglary trouble Burglary test Automatic closing (‘+ area number’) Forced closing Close area (‘system has been partly armed’) Late close Early close Closing report Automatic closing (‘+ user number’)
Page 117
Emergency alarm Emergency alarm restore Emergency trouble restore Emergency trouble Remote program begin Dummy Automatic communication test Power up Tamper alarm Tamper restoral Communication test (‘manual or automatic’) Untyped zone alarm Untyped zone bypass Untyped alarm restore Untyped trouble restore Untyped zone restoral Untyped zone trouble Untyped zone unbypass...
Rechargeable Standby Battery 12 Volts 7 Amp-Hours (AH) Auxiliary Power 12 Volts DC @ 280 mA, maximum Bell Use Ademco AB12M Smoke Detectors Use ESL/Sentrol models ES-449AT, ES-449C, ES-541CXT; Detection Systems: DS-DS284THC Wiring Use recognized energy-limited cable for connections of up to 100 VA when mounting initiating devices, indicating devices, and supplementary devices.
Page 119
RISCO Group Ltd. and its subsidiaries and affiliates ("Seller") warrants its products to be free from defects in materials and workmanship under normal use for 24 months from the date of production. Because Seller does not install or connect the product and because the product may be used in conjunction with products not manufactured by the Seller, Seller cannot guarantee the performance of the security system which uses this product.
Page 120
Contacting RISCO Group RISCO Group is committed to customer service and product support. You can contact us through our website (www. riscogroup.com) or at the following telephone and fax numbers: UNITED KINGDOM U.S.A Tel: +44-161-655-5500 Toll Free: 1-800-344-2025 sales@riscogroup.co.uk Tel: +305-592-3820 technical@riscogroup.co.uk...
