Summary of Contents for geratech EGE-UHD-1042FS
- Page 1 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching...
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 4 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching SAFETY PRECAUTIONS Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •...
-
Page 5: Table Of Contents
EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching CONTENTS 1. Introduction ..................1 2. Applications ..................1 3. Package Contents ................1 4. System Requirements ..............1 5. Features...................2 6. Operation Controls and Functions ..........3 6.1 Front Panel ..................3 6.2 Rear Panel...................5 6.3 Remote Control ................6 6.4 OSD Menu ...................8... -
Page 6: Introduction
EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 1. INTRODUCTION This 10 by 2 HDMI UHD Matrix is an advanced solution for switching up to 10 HDMI inputs to two HDMI outputs. It provides high performance pass-through of video/audio and is capable of receiving and transmitting 300MHz/9Gbps bandwidth rate with no data loss. -
Page 7: Features
EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 5. FEATURES • Supports UHD resolutions up to 4K2K@24/25/30Hz & 4K2K YUV420@60Hz • Supports HDTV resolutions up to 1080@60Hz, ‘Deep Color’ 36/30/24-bit and PC resolutions up to WUXGA@60Hz(RB) • Supports 3D • Supports pass-through of audio formats: LPCM 2/5.1/7.1CH, Dolby Digital 2~5.1CH, DTS 2~5.1CH, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos and DTS-HD Master... -
Page 8: Operation Controls And Functions
EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel IN 1 IN 2 IN 3 IN 4 IN 5 OUT A CANCEL MENU LOCK POWER 10X2 HDMI MATRIX FAST SWITCH IN 6 IN 7... - Page 9 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching press OUTA and select an input from IN1~10 then press OUTB and select an input from IN1~10 again and press ENTER to confirm the selection. eg. To preset 2’s figure, MENU → ENTER → Matrix Preset → Enter → Preset2 → IN2 → OUTA → IN8 → OUTB →...
-
Page 10: Rear Panel
EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 6.2 Rear Panel HDMI IN HDMI OUT SERV. CONTROL RS232 IR IN DC 5V HDMI IN Connect from source equipment such as Blu-ray/DVD/PS3 players, Set-Top-Box or any HDMI equipped source device for input signal sending. -
Page 11: Remote Control
EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 6.3 Remote Control POWER POWER MUTE Press this button to switch On or set the device to standby mode. MUTE Press this button to mute video and audio on OUT A or B or on all output. - Page 12 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching PRESET Press this button to recall the preset setting from 1~10. Press and select from IN1~10 then press TAKE to confirm the recall selection or press CANCEL to exit the selection. To reset the Preset setting, enter into menu and select Preset setting from IN1~10 then press OUTA and select an input from IN1~10 then press OUTB and select an input from IN1~10 again and press ENTER to confirm the selection.
-
Page 13: Osd Menu
EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 6.4 OSD Menu Main Menu Sub Menu Description Default EDID Mode All Input port is using same EDID. In menu “EDID All”, can select suitable EDID. Appoint Each Input port can select individual EDID. - Page 14 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching Main Menu Sub Menu Description Default EDID IN5 Same EDID All Select Input 5’s EDID Same EDID All EDID IN6 Same EDID All Select Input 6’s EDID Same EDID All EDID IN7 Same EDID All Select Input 7’s EDID...
- Page 15 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching Main Menu Sub Menu Description Default IN10 Standard Set IN10 in Apple/ Standard Standard mode /Apple Exit Network IP Mode DHCP , Static DHCP Setup Setup Static IP 192.168.1.50 Mask Setup Static Netmask 255.255.255.0...
- Page 16 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching Main Menu Sub Menu Description Default Native Content: native resolution Video Format Content: deep color, 2D or 3D, 4K2K Audio Format Content: PCM, BitStream, HBR Exit Sink B Info Same Sink A...
-
Page 17: Rs-232 Protocols
EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 6.5 RS-232 Protocols Switch Remote Control Assignment Assignment Baud Rate: 115200bps Data bit: 8 bits Parity: None Flow Control: None Stop Bit: 1 6.6 IR Pin Definitions IR Receiver IR Signal Power... -
Page 18: Ip Searching Software Application And Installation
10x2 HDMI 4K UHD Matrix Fast Switching 6.7 IP Searching Software Application and Installation Please download the software from www.geratech.com with file name CDPS V2.000 and save it in a directory where you may use it later. Connect the Control System with PC/Laptop through the Ethernet port through an active network system and open the CDPS V2.000 application. -
Page 19: Telnet & Rs-232 Commands
EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 6.8 Telnet & RS-232 Commands Description of Command Name Description parameter Power Off (Standby) NONE Power On NONE Set Output A Source N=1-10 Set Output B Source N=1-10 Set All Outputs Source... - Page 20 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching Description of Command Name Description parameter SOURCEDET Show All Input Signal NONE SOURCEDET N1 Show Input N1 Signal N1=1-10 SINKINFO Show Output NONE Information INNAME Show Input Name NONE INNAME N1 N2...
-
Page 21: Telnet Control
EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 6.9 Telnet Control To access the telnet control in Windows 7, click on ‘Start’ menu and type “cmd” in the Search field then press enter. Under Windows XP go to the ‘Start’ menu and click on “Run”, type “cmd” and press enter. - Page 22 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching Type HELP or ? to bring out all the commands. Note: All the commands will be not executed unless followed by a carriage return. Commands are case-insensitive. If the IP is changed then the IP Address required for...
-
Page 23: Webgui Control
EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 6.10 WebGUI Control On a PC/Laptop that is connected to an active network system, open a web browser and type device’s IP address (available inside the OSD menu) on the web address entry bar. - Page 24 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching Click on Matrix Control to set the EDID mode for each and all inputs. Click on Settings to set each input’s HDCP Control and Preset Configuration. Click on Network Configuration to set the device’s IP configuration. Once the changes are saved the system will reset the IP address on device automatically and user will need to re-enter the IP address to continue the WebGUI function.
-
Page 25: Connection Diagram
EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 7. CONNECTION DIAGRAM PC/NB DVD or Blu-ray Player HDMI IN HDMI OUT SERV. CONTROL RS232 IR IN DC 5V 60° POWER MUTE CANCEL MENU TAKE PRESET LOCK CR-151 HD TV HD TV... -
Page 26: Specifications
EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 8. SPECIFICATIONS Video Bandwidth 300MHz / 9Gbps Input Ports 10 x HDMI, 1 x IR Extender, 1 x RJ-45 (Control), 1 x RS-232, 1 x USB (Firmware update only) Output ports 2 x HDMI... - Page 27 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching DVI and HDMI Supported Resolutions Input Output 640x480@60/72/75 720x480@60 720x576p@50 800x600@60/72/75 1024x768@60/70/75 1280x720@50/60 1280x720p@60 1280x768@60 1280x800@60 1280x1024@60 1360x768@60 1600x1200@60 1920x1080i@50/60 1920x1080p@24/25/30/50/60 1920x1200@60(RB) 3840x2160@24/25/30 3840x2160@50/60 YUV420 4096x2160@24/25/30 4096x2160@50/60 YUV420...
- Page 28 www.egerate-store.com...
