  • Page 1 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching...
  • Page 2 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching...
  • Page 3 Geratech assumes no responsibility for any inaccuracies that may be contained in this document. Geratech also makes no commitment to update or to keep current the information contained in this document.
  • Page 4 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •...

  • Page 5: Table Of Contents

    EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching CONTENTS 1. INTRODUCTION ..............1 2. APPLICATIONS ................ 1 3. PACKAGE CONTENTS ............1 4. SYSTEM REQUIREMENTS ............. 1 5. FEATURES ................1 6. OPERATION CONTROLS AND FUNCTIONS ......2 6.1 Front Panel ................. 2 6.2 Rear Panel ................

  • Page 6: Introduction

    EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 1. INTRODUCTION This 10 by 2 HDMI UHD Matrix is an advanced solution for switching up to 10 HDMI inputs to two HDMI outputs. It provides high performance pass-through of video/audio and is capable of receiving and transmitting 300MHz/9Gbps bandwidth rate with no data loss.

  • Page 7: Operation Controls And Functions

    EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching • • Supports EDID selection function • Supports control via IR, RS-232, Telnet and WebGUI controls • Input port HDCP support Standard and Apple mode. The Apple mode selection to guarantees the use of Apple devices.

  • Page 8: Rear Panel

    EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching PRESET Press this button to recall the preset setting from 1~10. Press and select from IN1~10 then press TAKE to confirm the recall selection or press CANCEL to exit the selection. To reset the Preset setting, enter into menu and select Preset...

  • Page 9: Remote Control

    EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 6.3 Remote Control POWER Press this button to switch On or set the device to standby mode. MUTE Press this button to mute video and audio on OUT A or B or on all output. e.g. To mute output A OUTA >...

  • Page 10: Osd Menu

    EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 6.4 OSD Menu Main Menu Sub Menu Description Default EDID Mode All Input port is using same EDID. In menu “EDID All”, can select suitable EDID. Appoint Each Input port can select individual EDID.
  • Page 11 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching EDID IN5 Same EDID All Select Input 5’s EDID Same EDID All EDID IN6 Same EDID All Select Input 6’s EDID Same EDID All EDID IN7 Same EDID All Select Input 7’s EDID...
  • Page 12 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching Network IP Mode DHCP , Static DHCP Setup Setup Static IP 192.168.1.50 Mask Setup Static Netmask 255.255.255.0 Gate Setup Static Gateway 192.168.5.254 Do Re-Link Re-Link. After setup Network, the system need to...

  • Page 13: Rs-232 Protocols

    EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching Firmware FW Version Display the model number and FW version Update FW Update Exit Factory Do Reset Do system Reset Reset Exit Exit 6.5 RS-232 Protocols Switch Switch Assignment Assignment Baud Rate: 115200bps...

  • Page 14: Ir Pin Definitions

    EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 6.6 IR Pin Definitions 6.7 IP Searching Software Application and Installation Connect the Control System with PC/Laptop through the Ethernet port through an active network system and open the application. Click on Find Devices on Network and a list of the devices connected to the Control System will show up.
  • Page 15 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching SIPADDR XXX.XXX. Set Ethernet IP XXX=0~255 XXX.XXX Address SNETMASK XXX.XXX. Set Ethernet Net Mask XXX=0~255 XXX.XXX SGATEWAY XXX.XXX. Set Ethernet Gateway XXX=0~255 XXX.XXX HTTPPORT N Set Http Port Number N=0~65535 RSTIP IP Configuration Reset NONE To <DHCP>...

  • Page 16: Telnet Control

    EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 6.9 Telnet Control To access the telnet control in Windows 7, click on ‘Start’ menu and type “cmd” in the Search field then press enter. Under Windows XP go to the ‘Start’ menu and click on “Run”, type “cmd” and press enter.

  • Page 17: Webgui Control

    EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 6.10 WebGUI Control On a PC/Laptop that is connected to an active network system, open a web browser and type device’s IP address (available inside the OSD menu) on the web address entry bar.
  • Page 18 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching Click on Matrix Control to set the EDID mode for each and all inputs. Click on Settings to set each input’s HDCP Control and Preset Configuration.

  • Page 19: Connection Diagram

    EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching Click on Network Configuration to set the device’s IP configuration. Once the changes are saved the system will reset the IP address on device automatically and user will need to re-enter the IP address to continue the WebGUI function.

  • Page 20: Specifications

    EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching 8. SPECIFICATIONS Video Bandwidth 300MHz / 9Gbps Input Ports 10 x HDMI, 1 x IR Extender, 1 x RJ-45 (Control), 1 x RS-232, 1 x USB (Firmware update only) Output Ports 2 x HDMI...
  • Page 21 EGE-UHD-1042FS 10x2 HDMI 4K UHD Matrix Fast Switching DVI and HDMI Supported Resolutions Input Output 640x480@60/72/75 720x480@60 720x576p@50 800x600@60/72/75 1024x768@60/70/75 1280x720@50/60 1280x720p@60 1280x768@60 1280x800@60 1280x1024@60 1360x768@60 1600x1200@60 1920x1080i@50/60 1920x1080p@24/25/30/50/60 1920x1200@60(RB) 3840x2160@24/25/30 3840x2160@50/60 YUV420 4096x2160@24/25/30 4096x2160@50/60 YUV420...
