Summary of Contents for geratech EGE-UHD-HDB-2538
- Page 1 EGE-UHD-HDB-2538 UHD 2×1 HDMI/VGA over HDBaseT Wallplate Scaler...
- Page 2 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler...
-
Page 3: Copyright Notice
The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document. Geratech also makes no commitment to update or to keep current the information contained in this document. -
Page 4: Safety Precautions
UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •... -
Page 5: Table Of Contents
UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler CONTENTS 1. INTRODUCTION ..............1 2. APPLICATIONS ............... 1 3. PACKAGE CONTENTS ............1 4. SYSTEM REQUIREMENTS ............. 1 5. FEATURES ................2 6. OPERATION CONTROLS AND FUNCTIONS ......2 6.1 Front Panel ................. 2 6.2 Rear Panel ................ -
Page 6: Introduction
UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler 1. INTRODUCTION This product is an HDMI/VGA switch with audio embedding and scaled HDBaseT output. The wall plate is designed for use with EU or UK two-gang sized enclosures and comes with an EU 2-gang style faceplate. This transmitter can send high definition uncompressed audio/ video along with Ethernet over a single cable up to a distance of 100 meters at1080p@60Hz. -
Page 7: Features
UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler 5. FEATURES • HDMI 2.0 and DVI 1.0 compatible • HDCP 2.2 and HDCP 1.x compliant • 1 HDMI input • 1 VGA input with 3.5mm mini-jack audio input • Supports HDMI input resolutions up to 4K@60Hz (4:4:4, 8-bit) •... - Page 8 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler LINK LED: This LED will illuminate solidly when a live connection with a compatible receiver is active. VGA IN Port & LED: Connect to VGA source equipment such as a PC or laptop.
-
Page 9: Rear Panel
UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler 6.2 Rear Panel DC 12V 2-pin Terminal Block: Connect a 12V DC power adapter to the twin terminal block and connect it to an AC wall outlet for power. Note: Optional, not required when powered by PoH from the receiver. -
Page 10: Osd Menu
UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler 6.4 OSD Menu All functions of this unit can be controlled by using the OSD (On Screen Display) which is activated by pressing the MENU button on the front of the unit. Use the + (PLUS), −... - Page 11 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler 2560×1600@60RB 720×480p@60 720×576p@60 1280×720p@50 1280×720p@60 1920×1080p@24 1920×1080p@25 1920×1080p@30 1920×1080p@50 1920×1080p@60 2560×1080p@50 2560×1080p@60 3840×2160p@24 3840×2169p@25 3840×2160p@30 4096×2160p@24 4096×2160p@25 4096×2160p@30 FULL Best Fit Pan Scan Letterbox Aspect Under 2 Under 1 Follow In Overscan...
- Page 12 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler 60 Seconds 3 Minutes 5 Minutes 10 Minutes Auto Switch PC Auto Setup [Current Status] PC H Position 0~250 PC V Position 0~250 PC Setup PC Phase 0~255 PC Clock 0~250 (125) PC Reset 1) Video: Selects the input source to display.
- Page 13 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler PICTURE 2ND LEVEL 3RD LEVEL R 0 ~ 1023 (512) Color Gain 0 ~ 1023 (512) Color Gain G Color Gain B 0 ~ 1023 (512) Color Offset R 0 ~ 1023 (512)
- Page 14 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler AUDIO 2ND LEVEL 3RD LEVEL FOLLOW VIDEO Audio Line In Volume 0~100 (80) Audio Mute Reset Audio 1) Audio: Provides control over the analog audio routing in the unit. Selecting “Follow Video” pairs the HDMI source with its embedded digital audio and the VGA source with the analog audio input.
- Page 15 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler 2ND LEVEL 3RD LEVEL 0~60 (30) H Position 0~60 (30) V Position 0~100 (80) 5 Sec 10 Sec 15 Sec Timer 20 Sec 25 Sec 30 Sec 35 Sec 40 Sec Transparent 0 ~ 50 (50)
- Page 16 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler EDID 2ND LEVEL 3RD LEVEL Int 1080p (2Ch) Int 4K (3G-2Ch) HDMI EDID Int 4K (6G-2Ch) OUTPUT EDID Status [Current Status] 1) HDMI EDID: Select the EDID to use with the HDMI input.
-
Page 17: Serial Commands
UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler RESET 2ND LEVEL 3RD LEVEL Reset All 1) Reset All: Reset all of the unit’s settings back to their factory defaults. INFORMATION 2ND LEVEL 3RD LEVEL Video Input Output [System Information Display]... - Page 18 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler SET OUT AUTO MODE N1 Set the auto switching behavior of the unit. Available values for N1: [Off] [Auto Switch] GET OUT AUTO MODE Show the current auto switching mode of the unit.
- Page 19 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler SET OUT A TIMING N1 Set the output resolution to use for the HDBaseT output. Available values for N1: [Native] [640×480@60] [800×600@60] [1024×768@60] [1280×720@60] [1280×768@60] [1280×800@60] [1280×1024@60] [1360×768@60] [1440×900@60] [1400×1050@60] [1600×1200@60] [1680×1050@60] [1920×1080@60]...
- Page 20 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler SET OUT A CONTRAST N1 Set the contrast level of the HDBaseT output. N1 = 0~60 [Contrast] GET OUT A CONTRAST Show the current contrast level. SET OUT A BRIGHTNESS N1 Set the brightness level of the HDBaseT output.
- Page 21 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler SET OUT A ASPECT RATIO N1 Set the aspect ratio of the video shown on the HDBaseT output. Available values for N1: [Overscan] [Full] [Best Fit] [Pan Scan] [Letterbox] [Under 2] [Under 1] [Follow In] GET OUT A ASPECT RATIO...
- Page 22 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler SET OUT A R OFFSET N1 Set the HDBaseT output's red gain level. N1 = 0~1023 [Red Offset] GET OUT A R OFFSET Show the current red gain level. SET OUT A G OFFSET N1...
- Page 23 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler GET AUDIO IN TYPE LIST List all available audio input sources. SET AUDIO OUT A MUTE N1 Enable or disable muting the audio output. Available values for N1: [Mute Enabled] [Mute Disabled] GET AUDIO OUT A MUTE...
- Page 24 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler SET OUT A OSD HPOSITION N1 Set the horizontal position of the OSD. N1 = 0~60 [H Position] GET OUT A OSD HPOSITION Show the current horizontal position of the OSD. SET OUT A OSD TRANSPARENCY N1...
- Page 25 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler SET UART 1 DATA BITS N1 Set the RS-232 data bits. Available values for N1: [5 Bits] [6 Bits] [7 Bits] [8 Bits] GET UART 1 DATA BITS Show the current number of RS-232 data bits.
- Page 26 UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler SET AUTOMATION EVENT N1 UART A N2 Enable or disable the specified Automation Event's RS-232 response. N1 = 1~3 [Automation Event Number] Available values for N2: [Enable] [Disable] GET AUTOMATION EVENT N1 UART A...
-
Page 27: Connection Diagram
UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler 7. CONNECTION DIAGRAM... -
Page 28: Specifications
UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler 8. SPECIFICATIONS 8.1 Technical Specifications HDMI Bandwidth 18Gbps VGA Bandwidth 165MHz HDBaseT Bandwidth 10.2Gbps Input Ports 1×HDMI (Type-A) 1×VGA (HD-15) 1×Stereo Audio (3.5mm) Output Ports 1×HDBaseT (RJ-45) Pass-through Ports 1×LAN (RJ-45) Service Port 1×USB 2.0 (Type A) -
Page 29: Video Specifications
UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler 8.2 Video Specifications Input Output Supported Resolutions (Hz) HDMI HDBaseT 720×400p@70/85 640×480p@60/72/75/85 720×480i@60 720×480p@60 720×576i@50 720×576p@50 ... -
Page 30: Audio Specifications
UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler 3840×2160p@24/25/30 3840×2160p@50/60 (4:2:0) 3840×2160p@24, HDR10 3840×2160p@50/60 (4:2:0), HDR10 3840×2160p@50/60 4096×2160p@24/25/30 4096×2160p@50/60 (4:2:0) ... -
Page 31: Cable Specifications
UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler 8.4 Cable Specifications 1080p 4K30 4K60 Cable Length (4:4:4) (4:4:4) 8-bit 12-bit 8-bit 8-bit High Speed HDMI Cable HDMI Input VGA Cable VGA Input Ethernet Cable Cat.5e/6 100m Cat.6A/7 100m 100m ... -
Page 32: Acronyms
UHD 2×1 HDMI/VGA over EGE-UHD-HDB-2538 HDBaseT Wallplate Scaler 9. ACRONYMS ACRONYM COMPLETE TERM Analog-to-Digital Converter ASCII American Standard Code for Information Interchange Cat.5e Enhanced Category 5 cable Cat.6 Category 6 cable Cat.6A Augmented Category 6 cable Cat.7 Category 7 cable... - Page 34 www.geratech.eu...
