  • Page 1 EGE-HD-541FS 5×1 HDMI/MHL Fast Switcher, IR, RS232 Controll...
  • Page 2 EGE-HD-541FS 5×1 HDMI/MHL Fast Switcher, IR, RS232 Controll...
  • Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Geratech assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Geratech assumes no responsibility for any inaccuracies that may be contained in this document.
  • Page 4 EGE-HD-541FS 5×1 HDMI/MHL Fast Switcher, IR, RS232 Controll SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •...

  • Page 5: Table Of Contents

    EGE-HD-541FS 5×1 HDMI/MHL Fast Switcher, IR, RS232 Controll CONTENTS 1. Introduction ................1 2. Applications ................1 3. Package Contents ..............1 4. System Requirements .............. 1 5. Features..................2 6. Operation Controls and Functions ......... 3 6.1 Front Panel ................3 6.2 Rear Panel................

  • Page 6: Introduction

    EGE-HD-541FS 5×1 HDMI/MHL Fast Switcher, IR, RS232 Controll 1. INTRODUCTION The 5 by 1 HDMI/MHL Fast Switcher has MHL (Mobile High-Definition Link) interface integrated on its fifth input which can be used to share high definition video and audio from any of your MHL-ready mobile devices on an HDTV, and simultaneously charge the device whilst connected.

  • Page 7: Features

    EGE-HD-541FS 5×1 HDMI/MHL Fast Switcher, IR, RS232 Controll 5. FEATURES • Supports InstaPort Technology • Supports five HDMI input ports, the fifth port is an HDMI/MHL port • Supports one HDMI output • Supports video resolutions up to 1080p@60 Hz •...

  • Page 8: Operation Controls And Functions

    EGE-HD-541FS 5×1 HDMI/MHL Fast Switcher, IR, RS232 Controll 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel 5X1 HDMI/MHL FAST SWITCHER CFSW-51MHL INPUT POWER IR Receiver Supports reception of IR codes from the system's IR remote control only. INPUT Buttons and LEDs Press the 'INPUT' source button to select the required input source, the blue LED will indicate the selected source.

  • Page 9: Rear Panel

    EGE-HD-541FS 5×1 HDMI/MHL Fast Switcher, IR, RS232 Controll 6.2 Rear Panel HDMI IN RS232 MHL/HDMI HDMI OUT DC 5V IR IN IR IN Connect to the supplied IR extender cable for receiving the IR remote signal for this device only.

  • Page 10: Remote Control

    EGE-HD-541FS 5×1 HDMI/MHL Fast Switcher, IR, RS232 Controll 6.3 Remote Control Power HDMI 1 HDMI 2 HDMI 3 Press this button to switch the device on or to put the device HDMI 4 HDMI 5 HDMI 6 HDMI 7 HDMI 8 Vol + into standby mode.

  • Page 11: Rs-232 Protocol

    EGE-HD-541FS 5×1 HDMI/MHL Fast Switcher, IR, RS232 Controll 6.4 RS-232 Protocol CFSW-51MHL REMOTE CONTROL Assignment Assignment ► ◄ Baud Rate: 19200 bps Data Bit: 8-bit Parity: None Flow Control: None Stop Bit: 1-bit COMMANDS ACTION POWER 00 Power Off (standby)

  • Page 12: Remote Command Protocol

    EGE-HD-541FS 5×1 HDMI/MHL Fast Switcher, IR, RS232 Controll 6.5 Remote Command Protocol Opcode Key Name Opcode Key Name Opcode Key Name 0x00 0x2B 0x4D-0x4F Select Enter Reserved 0x01 0x2C Clear 0x50 Angle 0x02 Down 0x2D-02xF Reserved 0x51 Subpicture 0x03 Left...

  • Page 13: Connection Diagram

    EGE-HD-541FS 5×1 HDMI/MHL Fast Switcher, IR, RS232 Controll 7. CONNECTION DIAGRAM Set-top Box Blu-ray Player Smartphone Satellite Receiver Media Player MHL to HDMI Input HDMI Input HDMI HDMI HDMI HDMI Input Input Input Input RS-232 Power Supply HDMI IN RS232...

  • Page 14: Specifications

    EGE-HD-541FS 5×1 HDMI/MHL Fast Switcher, IR, RS232 Controll 8. SPECIFICATIONS Video Bandwidth 225 MHz/6.75 Gbps Input Ports 5×HDMI Output Port 1×HDMI Resolution Support VGA~WUXGA@60 (RB) 480i/p, 576i/p, 720p@50/60/120 1080i@50/60, 1080p@24/30/50/60 (MHL only supports 1080p@30 & 1080i@60) ESD Protection Human body model: ±8 kV (air-gap discharge)
  • Page 15 www.egerate-store.com...
