geratech EGE-HDMV-441SL Manual

4×1 hdmi seamless quad switcher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
E G E - H D M V - 4 4 1 S L
4×1 HDMI Seamless Quad Switcher

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EGE-HDMV-441SL and is the answer not in the manual?

Questions and answers

Related Manuals for geratech EGE-HDMV-441SL

Summary of Contents for geratech EGE-HDMV-441SL

  • Page 1 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher...
  • Page 3 Geratech Technology assumes no responsibility for any inaccuracies that may be contained in this document. Geratech also makes no commitment to update or to keep current the information contained in this document.
  • Page 4 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •...

  • Page 5: Table Of Contents

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher CONTENTS 1. Introduction .................1 2. Applications ................1 3. Package Contents ..............1 4. System Requirements ............1 5. Features................2 6. Operation Controls and Functions ........2 6.1 Front Panel ..............2 6.2 Rear Panel...............3 6.3 Remote Control ...............4...

  • Page 6: Introduction

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher 1. INTRODUCTION This HDMI Switcher is a high performance, low latency, multi-windowing system that can be easily configured for a variety of professional video processing tasks. Up to 4 different input sources may be freely selected and arranged and output to a single display.

  • Page 7: Features

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher 5. FEATURES • Seamless switching between sources and windows • Supports PiP, PoP, and multi-window display • Easy individual window size and position and layer priority adjustment •...

  • Page 8: Rear Panel

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher (1~4). It is possible for a single input to be displayed in multiple windows simultaneously. WINDOW A~H: Press buttons A~D will put the unit into full screen single window mode and display the associated channel’s currently selected source (1~4).

  • Page 9: Remote Control

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher USB cable. The unit should appear as an empty USB drive on your PC named “USB UPDATE”. Drag or copy the logo file into the new “USB UPDATE” drive on your PC and the upload will automatically proceed.

  • Page 10: Osd Menu

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher Chroma Key*: Press to toggle the Chroma Key function on/off. Note: Channel 1 is always the background and channel 2 is always the keyed foreground image.
  • Page 11 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 I/O Setup Output Windows Window A (cont.) Window B Window C Window D Window E Window F Window G...
  • Page 12 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 Image Adjust Brightness 0~100 (50) Adjust 0~100 (50) 0~100 (50) 0~100 (50) Value Reset Menu Exit Contrast Adjust 0~100 (50)
  • Page 13 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 Window Channel 1~4 Size Width Unit Setup Select Width Ten Width Hundred Height Unit Height Ten Height Hundred Value Rest...
  • Page 14 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 Chromakey User 1 Minimum for R/G/B 000~255 (0) Setup Maximum for R/G/B 222~255 (255) 000~255 (0) User 2 Minimum for R/G/B...
  • Page 15 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher Note: •  Values in bold or ( ) are factory default settings. •  The “Chromakey Setup” feature only works with Inputs 1 & 2. Input 1 is always the background video and Input 2 is always the top layer with the key applied to it.

  • Page 16: Rs-232 Protocol

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher 6.5 RS-232 Protocol SWITCHER REMOTE CONTROLLER Assignment Assignment ► ◄ Baud Rate: 115200bps Data Bits: 8 Parity: None Flow Control: None Stop Bits: 1...

  • Page 17: Rs-232 And Telnet Commands

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher 6.6 RS-232 and Telnet Commands COMMAND DESCRIPTION HELP/? Displays all available commands. SPOW M Turn the unit’s power on or off (stand-by). M = 0 [off], 1 [on] RPOW Display the current power state.
  • Page 18 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher COMMAND DESCRIPTION SOSDG M Set the transparency level of the OSD. M = 0~10 (Default = 5) ROSDG Display the current OSD transparency value. SBRI N M Set the brightness value for a channel.
  • Page 19 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher COMMAND DESCRIPTION SSWAP M Activate the image swap feature between the specified channels. Available values for M: 0 [Swap CH1 & CH2] 1 [Swap CH1 &...
  • Page 20 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher COMMAND DESCRIPTION RVSIZE Display the current vertical size of the specified channel. N = 1~4 [channel] SHPOS N M Set the horizontal position (in pixels) of the top- left pixel of the specified channel.
  • Page 21 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher COMMAND DESCRIPTION SRECALL M Select the Window mode or user Favorite channel arrangement to use. Available values for M: 1 [Window A] 2 [Window B] 3 [Window C] 4 [Window D]...
  • Page 22 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher COMMAND DESCRIPTION SROTATE M Set the full screen output rotation angle. Available values for M: 0 [no rotation] 1 [90° right] 2 [180°] 3 [90°...
  • Page 23 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher COMMAND DESCRIPTION RCHRC N Display the current brightness value of the selected chroma key item. Available values for N: 0 [User 1, G max] 1 [User 1, G min] 2 [User 1, R max] 3 [User 1, R min]...
  • Page 24 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher COMMAND DESCRIPTION IPCONFIG Display the current Ethernet information. DEFAULT Reset the unit to factory defaults. SVICH N M Set the selected channel to display the specified video input.

  • Page 25: Telnet Control

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher .7 Telnet Control Before attempting to use telnet control, please ensure that both the unit and the PC/Laptop are connected to the same active networks. To access Telnet in Windows 7, click on the “Start”...
  • Page 26 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher This will connect us to the unit we wish to control. Type “help” to list the available commands. Type “IPCONFIG” to list all IP configurations. Type “IPMODE” to put the unit into static IP/DHCP mode.

  • Page 27: Webgui Control

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher .8 WebGUI Control All primary functions of this unit are controllable via the built in WebGUI. This control is presented across 8 separate tabs, including Image Adjust, Image Swap, Output Resolution, Windows Setup, OSD/LOGO Settings, Window Convert, Chromakey Setup, and Ethernet.

  • Page 28: Image Adjust

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher 6.8.1 Image Adjust Select the “Image Adjust” tab to adjust the contrast, saturation, brightness, brightness and hue of each channel window. Additionally, each channel can be paused/un-paused independently, or all at the same time.

  • Page 29: Output Resolution

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher 6.8.3 Output Resolution Click on the “Output Resolution” tab to set the output resolution for the unit. 6.8.4 Windows Setup (Multi-Window Mode [E~H] only) Click on the “Windows Setup”...

  • Page 30: Osd/Logo Settings

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher Notes: •  The positioning coordinates are measured from the upper-left corner of each channel window and the values depend on the selected output resolution. • ...

  • Page 31: Window Convert

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher 6.8.6 Window Convert (Single Window Mode [A~D] only) Click on the “Window Convert” tab to access controls for mirror mode, 90° rotation and crossfade length.

  • Page 32: Ethernet

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher Note: When Chromakey is enabled, crossfade and rotation functionality is disabled. 6.8.8 Ethernet Click on the “Ethernet” tab to access control of the IP configuration for the unit. The IP Address, Netmask and Gateway can be set manually, or DHCP can be enabled for automatic IP configuration if your local network supports it.

  • Page 33: Connection Diagram

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher 7. CONNECTION DIAGRAMSCREEN CONFIGURATIONS: Camera Set-top Box DVD/Blu-ray Player Game Console HDMI Inputs Internet Connected Router 4 3 2 1 Power Supply HDMI IN HDMI OUT...

  • Page 34: Specifications

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher 8. SPECIFICATIONS 8.1 Technical Specifications Video Bandwidth 225MHz/6.75Gbps Input Ports 4×HDMI Output Ports 1×HDMI Supported Resolutions 480i@60Hz - 1080p@60Hz (12-bit) VGA@60Hz - WUXGA@60Hz (RB) HDMI Cable Length 15m (1080p@60Hz, 12-bit) Power Supply...

  • Page 35: Video Specifications

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher 8.2 Video Specifications Supported PC Resolutions (Hz) Input Output 640×480@60  640×480@72  640×480@75  640×480@85  800×600@56  800×600@60  800×600@72 ...
  • Page 36 E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher Supported TV Resolutions (Hz) Input Output 480i@60  576i@50  480p@60   576p@50   720p@50   720p@60  ...

  • Page 37: Acronyms

    E G E - H D M V - 4 4 1 S L 4×1 HDMI Seamless Quad Switcher 9. Acronyms ACRONYM COMPLETE TERM Command Line Interface Digital Visual Interface EDID Extended Display Identification Data Graphical User Interface High-Definition HDCP High-bandwidth Digital Content Protection HDMI High-Definition Multimedia Interface...
  • Page 38 www.egerate-store.com...
