Femi NG200 Instructions For Use And Maintenance Manual

Femi NG200 Instructions For Use And Maintenance Manual

Band-saw machine

Advertisement

CERTIFICATA
CERTIFIED
GEPRÜFT
CERTIFIE
CERTIFICADA
CERTIFICADA
GECERTIFICEERD
ISTRUZIONI PER L'USO E MANUTENZIONE
INSTRUCTIONS FOR USE AND MAINTENANCE
GEBRAUCHSANLEITUNGEN UND WARTUNG
INSTRUCCIONES PARA EL USO Y MANUTENCION
GEBRUIK- EN ONDERHOUDSAANWIJZINGEN
SEGATRICE A NASTRO
BAND-SAW MACHINE
BANDSÄGEMASCHINE
SCIE A RUBAN
SIERRA DE CINTA
SERRA DE FITA
BANDZAAGMACHINE
MODE D'EMPLOI ET ENTRETIEN
INSTRUÇÕES DE UTILIZAÇÃO
www.femi.it
Art.
NG200
NG201

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NG200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Femi NG200

  • Page 1 SEGATRICE A NASTRO BAND-SAW MACHINE BANDSÄGEMASCHINE SCIE A RUBAN SIERRA DE CINTA SERRA DE FITA BANDZAAGMACHINE Art. NG200 NG201 CERTIFICATA CERTIFIED GEPRÜFT CERTIFIE CERTIFICADA CERTIFICADA GECERTIFICEERD ISTRUZIONI PER L’USO E MANUTENZIONE INSTRUCTIONS FOR USE AND MAINTENANCE GEBRAUCHSANLEITUNGEN UND WARTUNG MODE D’EMPLOI ET ENTRETIEN INSTRUCCIONES PARA EL USO Y MANUTENCION INSTRUÇÕES DE UTILIZAÇÃO...
  • Page 2 Via del Lavoro, 4 - 40023 Castel Guelfo (BO) - ITALIA Tel. +39-0542-670160 - Fax +39-0542-670185 - http://www.femi.it Dichiara che la: SEGATRICE A NASTRO NG200-NG201 è conforme alle disposizioni contenute nelle Direttive: CEE 98/37 - 89/336 - 73/23 COMPLIANCE DECLARATION CE OF THE BUILDER FEMI S.p.A.
  • Page 3: Introduction To Use

    The enclosed CE declaration of conformity together with INDEX the CE brand on the product essentially comprise and are an integral part of the machine : both guarantee product conformity with the aforsaid safety Directives. INTRODUCTION TO USE ........9 RECOMMENDED AND NOT RECOMMENDED USAGE INSTALLATION ............
  • Page 4: Installation

    SAFETY PROCEDURS FOR FURTHER RISK Here is a list of the main parts with the number indicating it in the drawing. WARNING: Command grip Always keep hands away from the working areas Blade tensioning device while the machine is moving: before loading or Sliding blade guide unloading the part, release the run button on Machine body...
  • Page 5 To move the machine while it is still inside the packing, use THREE PHASE VERSION (Fig. 3-4) a fork lift by inserting the two forks in the rooms provided In case of voltage failure in the system, you can wait for under the bearing board the connection to be restored without danger of hazardous Move the machine carefully and avoid sudden movements...
  • Page 6: Oil Type

    SLIDING BLADE GUIDE (Fig. 3) ADJUSTING The sliding blade guide D with integrated protection fitted TENSION OF THE BLADE (Fig. 4) on your sawing machine is used to perform the cut while guiding the necessary part of the blade and fully protecting Turn the handwheel clockwise B till the green indicator the part not used in the cutting process.
  • Page 7 WORKING REPLACING THE BLADE WARNING: When you perform this operation, always wear protective Before any cutting operation, check that all safety gloves to avoid contact with the teeth of the blade. guards are sound and correctly positioned. • make sure that the main switch B (Fig. 3)/(Fig. 8) is on position 0;...
  • Page 8: Maintenance

    If the thickness of the profiled section is to be very thin, ACCESSORIES an outline should be fitted which copies the profile inside the profiled section itself to stop it being crushed between CHOISE OF BLADE the jaws. Your sawing machine is equipped with a bi-metal blade measuring 2140x19x0.9 mm with variable toothing 6/10 teeth per inch, for use in the majority of cuts possible with this machine.
  • Page 9 EVERY WEEK DISPOSAL OF THE MACHINE, PACKING AND • Lubricate the slides of the sliding blade guide and the EMULSION swivel support and the nut screw of the chuck. At the end of the machine life, if the • Remove the chips from the area of the coolant collecting machine must be scraped, contact filter.
  • Page 10: Troubleshooting

    TROUBLESHOOTING PROBLEMS PROBLEMS CAUSES SOLUTIONS SUGGESTED Defective motor, power cable or plug. Specialized personnel should check the machine; do not attempt to repair the motor by yourself. Blown electric panel fuses. Check fuse integrity and replace, if necessary. The motor does not work.
  • Page 11 Variatore di velocità Motore V 230 Hz 50/60 2000Watt Microswitch fine corsa carter Art. Motore V 230 Hz 50 60 Watt Microswitch fine corsa tendi lama Spia tensione lama NG200 ENGLISH NG201 Protection circuit Main switch 100 ˚C Run button...
  • Page 12 6.90.12.60 SCHEMA ELETTRICO: VERSIONE TRIFASE-WIRING DIAGRAM: THREE PHASE VERSION-ELEKTRISCHER SCHALTPLAN: DREHSTROMVERSION-SCHEMA ELECTRIQUE: VERSION TRIPHASEE-ESQUEMA ELECTRICO: VERSIÓN TRIFÁSICA-ESQUEMA ELÉCTRICO: VERSÃO TRIFÁSICA-BEDRADINGSCHEMA: UITVOERING MET DRIE-FASENMOTOR L1 (R) L2 (S) L3 (T) 400V /50HZ R S T -QS1 -FU1 Fig. 2 Fig. 3 V <<...
  • Page 13 6.90.12.60 TAVOLE RICAMBI - SPARE PARTS - ERSATZTEILE - PIECES DE RECHANGE - REPUESTOS - PEÇAS DE MUDANÇA NR. 2 - NG200-201 NR. 1 - NG200-201 NR. 3 - NG200-201 POS. COD./KOD. NOTE/MERKE/ POS. COD./KOD.NOTE/MERKE/NOTES/ POS. COD./KOD.NOTE/MERKE/NOTES/ POS. COD./KOD.NOTE/MERKE/NOTES/ POS.
  • Page 14 6.90.12.60 TAVOLE RICAMBI - SPARE PARTS - ERSATZTEILE - PIECES DE RECHANGE - REPUESTOS - PEÇAS DE MUDANÇA NR. 4 - NG200-201 NR. 5 - NG200-201 POS. COD./KOD.NOTE/MERKE/NOTES/ POS. COD./KOD.NOTE/MERKE/NOTES/ NOTA/NOTAS NOTA/NOTAS UNI 5732 M10x40 5.40.15.65 0.24.14.42 0.82.00.10 UNI 5721 M6 5.13.78.83...
