_ REMOVING THE CONCORD ULTIMAX

To make the removal of the CONCORD ULTIMAX easier we recommend you first
remove the seat (A) (see „REMOVING THE SEAT").
Always mount and remove the CONCORD ULTIMAX without a child in it!
Push the release button (09) outward and move the
support leg (10) into its top-most position.
Turn the ISOFIX SYSTEM (08)
control knob on the front of the
CONCORD ULTIMAX I-Size base to
the left and move the base forward.
Push the ISOFIX SYSTEM unlocking buttons
(13), on the left and right of the base, so that
the ISOFIX adapters (15) are released from the
receptacles and the base springs forward.
Lift the CONCORD ULTIMAX out of the car seat.
Turn the ISOFIX SYSTEM (08) control knob to the right
until the ISOFIX adapter (15) is fully extended.
32

_ USING THE RECLINING ADJUSTMENT

Move the reclining adjustment operating lever (05) at the front of the seat
upwards and bring the seat into the desired position.
By releasing the lever (05) the seat is locked.
33
