operator guide
Please Note Barron Games X-Putt Models Cannot Be Used For Money Prizes, Only Free Play
or Ticket Redemption. Please disregard all information in this manual pertaining to Cash Prizes
Operator Guide
IT IS THE RESPONSIBILITY OF THE OPERATOR TO MAINTAIN CUSTOMER SAFETY AT ALL TIMES, AND IT IS IMPERATIVE THAT
THE DETAILS SET OUT IN THIS MANUAL AND ANY OTHER MANUAL SUPPLIED WITH THIS MACHINE SHOULD BE FOLLOWED
PRECISELY AND ADHERED TO AT ALL TIMES
Version XP0.1
Page 1
© World Golf Systems ltd
Advertisement
Table of Contents
Related Manuals for Barron Games X-Putt
Summary of Contents for Barron Games X-Putt
- Page 1 Please Note Barron Games X-Putt Models Cannot Be Used For Money Prizes, Only Free Play or Ticket Redemption. Please disregard all information in this manual pertaining to Cash Prizes Operator Guide IT IS THE RESPONSIBILITY OF THE OPERATOR TO MAINTAIN CUSTOMER SAFETY AT ALL TIMES, AND IT IS IMPERATIVE THAT...
-
Page 2: Table Of Contents
operator guide Playing the Game ........................6 Putt for Cash ................................7 Putt for Fun ................................7 Putt for Cash: The Game Challenge and Leader boards ....................9 Gaming Screen Explanation ............................10 Game Scoring Bar ..............................11 Full Game Rules ............................... -
Page 3: Playing The Game
operator guide the game Playing the Game Putt for Fun or Putt for Cash 1. Touch screen to activate game selection 2. Insert Coins to play game 3. The game selection screen will now be £1 for Putt for Fun or £2 for Putt for Cash activated (based on amount of money previously entered). -
Page 4: Putt For Cash
operator guide the game Putt for Cash If the putt is successful the amount of points Based on the amount of points scored the Play your first shot, the hole to hit will be illuminated (e.g. No 1 above). The number of awarded will be displayed at the top of the amount of cash available to win will be displayed points which will be awarded if successful will be... - Page 5 operator guide the game Version XP0.1 Page 8 World Golf Systems Ltd...
-
Page 6: Putt For Cash: The Game Challenge And Leader Boards
Putt for Cash: The Game Challenge and Leader boards At the end of the game The X-Putt Challenge If amongst the highest 10 scores, the players will gives the player the opportunity to collect or play... -
Page 7: Gaming Screen Explanation
operator guide the game Gaming Screen Explanation Instant cash win of £1 if the The scoring bar indicates what the score will be if the next indicated hole (e.g. hole 7) is hit shot is successful (current score + potential score = total) Total amount of Total score winnings achieved... -
Page 8: Game Scoring Bar
operator guide the game Game Scoring Bar The scoring bar is touch sensitive and can be moved to the left and right. By moving the bar to the right the player is able to view the next ‘Cash Win’ position In the above example the player will win £1 once they reach 5000 points They are also able to view the various Bonus Hole... -
Page 9: Full Game Rules
operator guide the game Full Game Rules Version XP0.1 Page 12 World Golf Systems Ltd... -
Page 10: Operator Mode
operator guide operator mode Operator Mode To gain access to the Operator Mode push the ‘Operators button’ (located inside the bay pod, please refer to photo) • Open the game pod door, the operator switch is located next to the coin hopper •... -
Page 11: Cashing Up Process - Summary
operator guide cashing up Cashing up Process - Summary: Push Operator button to access Operator Mode Select View Counters Note down Net Takings Amount Return to Operator screen Select Dump Hopper, ensure payout area is empty Hopper dispenses full Select Start to begin Hopper runs out of coins float amount before it has counted the... -
Page 12: Cashing Up Process - Detailed
operator guide cashing up Cashing Up Process - Detailed • Open the Bay Pod door and push the Operator Switch, the Operators screen will now be displayed Step 1: From the Operators screen select View Counters • The View Counters screen will now be displayed: •... - Page 13 operator guide cashing up • Step 2: The next step is to Dump the contents of the hopper • Select the Dump Hopper button • The Dump Hopper screen will be displayed. Select the Start button to start emptying the hopper Please Note –...
- Page 14 operator guide cashing up • The unit will now count how many coins have been dispensed into the payout area Amount Amount still to dispensed be dispensed If the unit runs out of coins before it has dispensed the full float amount (normally £140) the following message will be •...
- Page 15 operator guide cashing up • Once the float (£140) has been dispensed remove it from the payout area. Select the Continue button • The hopper will now attempt to dump any remaining coins left until it is empty. If any additional coins are dispensed then the following screen and message will be displayed.
-
Page 16: Edit The Leader Board
operator guide leaderboards Edit the Leader board Select the Leader board to remove the initials from e.g. Putt for Fun or Putt for Cash (if available) • Select the option 'Delete' against the initials to remove • • The initials will now be removed from the selected Leader board Select initials to delete Select Leader... -
Page 17: Set Volume
operator guide volume control Set Volume • From the Operator menu select the Volume button • This function is used to change the audio settings e.g. turn the volume up or down or totally mute the sound. 10 % = lowest sound level Max = highest sound level The sound level may be tested by selecting a volume level followed by one of the preset music buttons at the top of •... -
Page 18: Test Menu
operator guide test menu Test Menu From the Operator menu select the Test button • Test Coin Mechanism • This function is used to test that the coin mechanism is operating correctly • Insert one of every coin denomination that the unit accepts. If the coin is successfully read it will be displayed within the appropriate graphic •... -
Page 19: Test Holes
If the trigger mechanism fails to issue a ball touch the Trigger graphic (bottom right) to record the failure and issue a new ball Test Lights This function is used to test the lights within the X-Putt module. If a light fails to illuminate touch the appropriate • graphic to record the failure Version XP0.1... -
Page 20: Test Ball In Play Sensors
Test Ball in Play Sensors • This function is used to test the ‘Ball in Play’ sensors at the front of the X-Putt gaming unit • If two green lights are illuminated then both sets of sensors are aligned correctly •... -
Page 21: Options
operator guide options Options • Currency: This indicates what currency the game unit is operating in e.g. GBP – Pounds Sterling • Game Types: lets you select one of the games or a combination of games: • Putt for Fun (no cash prize) •... -
Page 22: Editing Options
operator guide options Editing Options To edit one of the options touch the required function e.g. Game Types • The functions attached to that line will be displayed: (see screen below for an example) • Select the required function e.g. touch the actual function on the screen Functions... -
Page 23: Regular Operational Maintenance
• X-Putt Module Housing The surrounding housing to the module should be cleaned with a damp cloth or a mild non abrasive detergent. Do not allow cleaning liquids to run into any mechanisms Version XP0.1... -
Page 24: Troubleshooting
operator guide troubleshooting Troubleshooting Symptom Possible Cause Solution No picture on game touch screen No 240v power input Ensure that the game unit has power – check the 3 pin plug at the wall (source) is switched on Turn power off, wait 30 seconds and then switch on again Error displayed on game touch screen Incorrect software action...
