- Page 1 SKU#: BG-L001 Air Ride Hockey Table Instruction Manual Assembly, Operation, and Care Instructions Serial #: Distributed By: Sales Person: Technical Service #: +1-716-866-0054 v. 090616...
- Page 2 Air Ride Hockey Table Instruction Manual Inspect Immediately after Transporting the Product After receiving the shipment, inspect the product thoroughly to ensure that it has been shipped with care. Before turning the power on, please check the following: • Check the cabinet for damage or shifting that may have occurred during shipping.
-
Page 3: Safety Instructions
Air Ride Multiplayer Hockey Table Instruction Manual Safety Instructions This equipment may contain hazardous voltage which can cause electrical shock. Only • qualified personnel* should work inside the equipment. *Note: Keep reading for a list of qualified personnel. • To maintain personal safety and the safe operation of this product, read the entire manual before using it. - Page 4 Air Ride Multiplayer Hockey Table Instruction Manual Definition of Site Maintenance Personnel or Other Qualified Individuals WARNING Servicing and maintenance work of the contents herein stated should be performed by the SERVICEMAN stipulated as per IEC Standard. Those who do not have technical expertise and knowledge other than the SERVICEMAN are not allowed to perform the work herein stated.
- Page 5 If any label is peeled off, apply it again immediately. Please contact Barron Games Technical Support at 1+716-866-0054 or email service@barrongames.com if you are in need of new stickers or parts.
-
Page 6: Installation And Maintenance Safety
Air Ride Multiplayer Hockey Table Instruction Manual NSTALLATION AND AINTENANCE AFETY This product is an indoor game machine. Do not install it outside. Even indoors, avoid installing it in the places mentioned below to avoid causing a fire, electric shock, machine malfunction, or even death. Do not install or maintain this product in/on/within/near: •... -
Page 7: Assembly Notes
Air Ride Multiplayer Hockey Table Instruction Manual ASSEMBLY NOTES 1. Read this Instruction Manual carefully before assembling or playing. 2. Ensure that there is sufficient space to place and shift the product prior to assembly 3. 2 strong adults are recommended to assemble the product. 4. - Page 8 Air Ride Multiplayer Hockey Table Instruction Manual Assembly – Step A (Prepare the Table) 1. Use scissors or a knife to cut through the packing tape. Use 2. Open the cardboard box to caution not to cut too deeply or you may damage the unit. ensure the wooden side is facing up and the playfield is facing down to the floor.
- Page 9 Air Ride Multiplayer Hockey Table Instruction Manual Assembly – Step A (Prepare the Table) 4. After taking out the keys, open the center door panel, and remove all parts from inside the machine’s body. ( Do not remove air blower) Inside Accessory Boxes: 20 Pucks, 4 Mallets, 1 Table Polish &...
- Page 10 Air Ride Multiplayer Hockey Table Instruction Manual Assembly – Step B (Assemble the Table Legs) 2. Ensure all legs are tightly attached then flip the table 90 degrees. This requires at least TWO adults. Flip another 90 degrees to place the legs on the ground. *Place the included foam padding on either side of the goal release bay.
- Page 11 Air Ride Multiplayer Hockey Table Instruction Manual Assembly – Step C (Locate Internal Hardware) First, ensure the power is off. Open the door with the key. Hold the handle and pull it out until half of the power panel is exposed. Do not touch open terminals or exposed wires while the game is on. Handle on the panel Open the door with a key Power Supply...
- Page 12 Air Ride Multiplayer Hockey Table Instruction Manual Assembly – Step C (Program the PC Board) LEDA: Running LED lights around table NC40: Rail Strike Detector NC2: Display panel connection outlet NC41: Rail Strike Detector NC313: Direct Current (DC) Input outlet NC42: Rail Strike Detector NC35: A1 Output Control point NC43: Strike Detector...
- Page 13 Air Ride Multiplayer Hockey Table Instruction Manual DIP Switch Settings I = UP & O = DOWN DIP SWITCH 1 (Default Position is Down) COINS CREDITS DIP SWITCH 2 LIVES NO LIMIT TIME (MIN) service@barrongames.com For assistance call: 1+(716) 866-0054...
- Page 14 Air Ride Multiplayer Hockey Table Instruction Manual Parts List Part Number Part Name 3202004 Air Hockey Key #2868 3213082 Solenoid Brackets 3601007 Power Cord (U.S. Style) 3604056 Coin Mech w/LED Indicator 3605091 Goal Solenoid DC 12V 3605117 Power Supply NES-100-12-+12V 73605118 Power Supply NES-100-5+5V 3607050...
- Page 15 Air Ride Multiplayer Hockey Table Instruction Manual After Installing the Game 1. Check the voltage regularly to avoid a short circuit or potential fire. Do not overload the circuit. 2. Keep the power cord out of areas with busy foot traffic to ensure the safety of users and the machine.
-
Page 16: Care And Maintenance
Air Ride Multiplayer Hockey Table Instruction Manual Care and Maintenance 1. Use a soft cloth and product-specific polishing spray to clean the unit. We recommend using a microfiber cloth. THE PLAYFIELD SHOULD BE CLEANED WITH PRE-APPROVED HOCKEY TABLE POLISH ONLY. Air holes on the playfield may become clogged if a household cleaner is used. -
Page 17: Troubleshooting
Air Ride Multiplayer Hockey Table Instruction Manual Troubleshooting Having trouble assembling your new table? Call our experts in the Parts and Service Department (1+716-866-0054) or email Service@BarronGames.com and we will be happy to assist you! Glossary of Common Errors • 5V and 12V Power Supplies: The 5V and 12V power supplies regulate and disperse power to the PC boards, LEDs, and other electronics. -
Page 18: Error Lights
Air Ride Multiplayer Hockey Table Instruction Manual Error Lights Check the Instruction Manual against the PC Board error codes to begin. For the digital models, the LED screens above each goal will show an errors code when the table is out of order. When there is an error, press the Troubleshooting Button. -
Page 19: Coin Mechanism Wiring Diagram
Air Ride Multiplayer Hockey Table Instruction Manual Coin Mechanism Wiring Diagram service@barrongames.com For assistance call: 1+(716) 866-0054... - Page 20 Barron Games International 84 Aero Drive, Suite 5 Buffalo, NY 14225 Phone: 1+716-866-0054 Fax: 1+716-630-0055 www.BarronGames.com For Parts and Service Information, please contact us: phone: 1+716-866-0054 email: Service@BarronGames.com...
