- Page 1 Wideograficzne rejestratory temperatury i procesu VM7000A http://acse.pl BEZPAPIEROWE REJESTRATORY TEMPERATURY I PROCESU VM7000A Wprowadzanie opisów i komentarzy do rejestrowanego procesu YXP627B0104 June 2016 (Second edition) Copyright © 2009-2016 Ohkura Electric Co., Ltd. All Rights Reserved.
- Page 2 To use this equipment safely Thank you for purchasing our VM7000A Paperless Recorder. P lease installs it, operates it and prepares it, after this manual is often read, and it understands enough. ・ There is danger where the accident and the trouble occur when handling is mistaken.
- Page 3 The symbols below are used on this instrument for the cautioning information. CAUTION Symbols used on the instrument This shows “Caution for handling”. This symbol is used on the parts need to reference the instruction manual for saving human body and the instrument. This shows “Protective grounding”.
- Page 4 Do not put your foot on the installed instrument or get on it, because it is dangerous. ● Only our serviceman or persons authorized by OHKURA are allowed to remove ● Maintenance and take the inner module, the main unit and printed circuit boards apart.
-
Page 5: Table Of Contents
＜ ＜ ＜ ＜ CONTENTS＞ ＞ ＞ ＞ 1. O u t l i n e O u t l i n e ....... . . -
Page 6: Modifications
1. Outline This is the operation manual for the model VM7000A paperless recorder, equipped, in addition to its standard functions, with the ability to register and display manufacturing information compatible with industry 4.0 standards. This document explains the differences compared to the standard product. Before using the product, you are advised... -
Page 7: Software Versions
Versions for these specifications are as follows. Please use these version combinations for the main unit, parameter loader, and data viewer. Table 3: Versions Item Function Version Remarks VM7000A main unit Main V12.01 V1.50 Standard Data Viewer Ver12.01 Parameter loader Ver1.50... -
Page 8: Manufacturing Information Display Function
2. Description of Special Main Unit Functions 2.1 Manufacturing information display function The following manufacturing information is displayed along the vertical and horizontal trends. (1)Title (2)Registration Data (1)Title (2)Registration Data Figure 2.1: Trend Display (Real-time) (1)Title Displays the information number and title of each registered piece of manufacturing information. (2)Registration data Displays manufacturing data sent via transmission. - Page 9 [Note] It can be displayed as a historical trend, but the current manufacturing information is shown. Past manufacturing information is not displayed. If a measurement file is loaded, the manufacturing information is hidden. [Caution] Registration data is not saved when the power supply is turned OFF. Be sure to transmit all the registration information items each time.
-
Page 10: Manufacturing Information Display Setting
2.2 Manufacturing information display setting The manufacturing information display may be set by selecting MENU -> Parameter -> Others -> Products Display. Item Name Setting Default Description Product display ON/OFF Turns the display of all manufacturing information ON or OFF. Information No. -
Page 11: Manufacturing Information Comment Data Registration Function
2.3 Manufacturing Information Comment Data Registration Function The manufacturing information registered via transmission is recorded as a comment in the record file. Manufacturing information comment registration function Comments are recorded in the "Date Time Title: Registration data" format. Comments are registered in the file at the following times. [REC Start] For ongoing registrations, the comment is recorded at the time of transmission. - Page 12 [ User operation (for HMI) ] Batch:004 Model:VM7000A Model:VM7000A Batch:002 Batch:001 Batch:005 Serial:150904001 Serial:150904002 Batch:003 STOP RECORD STOP RECORD Model:VM7000A Model:VM7000A Batch:002 Batch:004 Batch:005 Batch:001 Serial:150904002 Serial:150904001 [Measurement file...Comment] Time Figure: Relationship between User Operation through HMI and File 1 1 1 1 1 1 1 1...
-
Page 13: Manufacturing Information Registration Function (Main Unit Operation)
2.4 Manufacturing Information Registration Function (Main Unit Operation) Manufacturing information may be registered from the recorder's main unit as described below. 1) Preparation Assign the manufacturing information function to the Func key to register. MENU->Setup->Device/Other->Func key [Note] If the Func key has been set to register manufacturing information, other functions, such as the caption function and message registration function can no longer be accessed through the Func key. - Page 14 Registration The registration window can be displayed by pressing the Func key on the trend screen. Touch the text box to display the keyboard and input the information. The previously registered value is stored, so if there are no changes it does not need to be input. (If the power supply is turned OFF, the information in the text box will be cleared.) If there are a number of items to be registered, proceed to the next window by pressing "Back"...
-
Page 15: Manufacturing Information Registration Function (Transmission)
2.5 Manufacturing Information Registration Function (Transmission) The manufacturing information is registered using the Modbus transmission (Ethernet, RS-485). The registration is carried out from the HMI. ( A sample HMI program is attached separately.) To transmit the manufacturing information via Modbus, batch transmits the 20-word data to the Holder Register. - Page 16 ■ Example of slave response (with a start address of 1b58H and a data count of 20) Data length Component Data MBAP header (only for Modbus TCP) Slave address Function code Relative start address (high-order) Relative start address (low-order) Data Write data count (high-order) Write data count (low-order) Error check...
-
Page 17: Added Message Function Transmission Registration Function
2.6 Added message function transmission registration function Messages usually registered with the keys, DIs, and alerts are recorded via Modbus transmission (Ethernet, RS-485). The registration is carried out from the HMI. (A sample HMI program is attached separately.) To transmit the manufacturing information via Modbus, transmit the 1-word data to the Holder Register. Use the Function Code = 06H (Write Single Register) to transmit. -
Page 18: Special Data Viewer Functions
3. Special Data Viewer Functions 3.1 Trend Display Open a file registered with manufacturing information display function, and manufacturing information is registered in the comment display area. 1 1 1 1 7 7 7 7... - Page 19 [Print Function] To display a comment using the data viewer's print function, set the comment item on the print preview screen as shown below. Comment display Comment data is shown within the trend. 1 1 1 1 8 8 8 8...
