KNOW YOUR PRODUCT
ROTARY HAMMER
DRILL KIT
• 5 JOULES
• 1250W POWER
INSTRUCTION MANUAL
WARNING: Read all safety warnings and instructions before use. Failure
to follow the warnings and instructions may result in electric shock, fire and/or
serious injury. Save these warnings and instructions for future reference.
02/17
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Full Boar FBT-0500U
Summary of Contents for Full Boar FBT-0500U
- Page 1 KNOW YOUR PRODUCT ROTARY HAMMER DRILL KIT • 5 JOULES • 1250W POWER INSTRUCTION MANUAL WARNING: Read all safety warnings and instructions before use. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save these warnings and instructions for future reference. 02/17...
-
Page 2: Table Of Contents
SPECIFICATIONS - MODEL NO. FBT-0500U TABLE OF CONTENTS Voltage: 230V ~ 50Hz SPECIFICATIONS............Page 02 Power: 1250W Impact Power: 5 Joules KNOW YOUR PRODUCT........... Page 02 Impact Rate: 0-4,100/min No Load Speed: 0-850/min INTRODUCTION............Page 04 Accessory Fitment: SDS-Plus Drilling Capacity: 32mm SAFETY INSTRUCTIONS........... -
Page 3: Introduction
INTRODUCTION GENERAL SAFETY INSTRUCTIONS Congratulations on purchasing a Full Boar rotary hammer kit. WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. It has been designed to rapidly drill, chip, chisel and break Save all warnings and instructions for future reference. - Page 4 GENERAL POWER TOOL SAFETY WARNINGS ROTARY HAMMER DRILL SAFETY WARNINGS • Use thick, cushioned gloves and limit the exposure time by taking frequent breaks. cannot be controlled with the switch is dangerous and must be repaired. • Vibration caused by the hammer action may be harmful to your hands and arms. c.
-
Page 5: Set Up
SET-UP & PREPARATION CHOOSING AN OPERATION MODE The Full Boar FBT-0500U has 4 different operating modes: drilling, hammer drilling, WARNING! Ensure the tool is turned off and disconnected from the power supply before chiselling with fixation and chiselling without fixation. Follow the instructions below to select performing any of the following operations. -
Page 6: Operation
OPERATION MAINTENANCE 1. Ensure your workpiece is securely clamped where possible. • Keep the ventilation vents of the rotary hammer drill clean at all times. • After each use, blow air through the rotary hammer drill housing to ensure it is free from all dust particles which may build up. -
Page 7: Troubleshooting
TROUBLESHOOTING DESCRIPTION OF SYMBOLS Problem Cause Remedy Volts Hertz Rotary hammer drill No power supplied. Make sure all plugs are connected Alternating current Watts is not working and power outlet is in working order. Revolutions or /min No load speed Mode Selectors in wrong Please refer to ‘Operating The reciprocation per minute... -
Page 8: Contents
CONTENTS 1 x Rotary hammer drill 1 x Dust cover 1 x Depth rod 1 x Carry case 1 x 250mm flat chisel bit Note: The manufacturer’s liability shall be deemed void if the machine is modified in any way, and the manufacturer shall, therefore, accept no liability for any damages arising as a result of modifications. -
Page 9: Warranty
WARRANTY All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the unlikely event that your device develops a fault, please contact our service department at the address shown on this guarantee card. You can also contact us by telephone using the customer service number shown.
