HBD-E190/E290/E490/E690
SERVICE MANUAL
Ver. 1.4 2013.01
• HBD-E190 is the amplifi er, video, HDMI, BD/DVD/CD system, USB,
LAN and FM tuner section in BDV-E190.
• HBD-E290 is the amplifi er, video, HDMI, BD/DVD/CD system, USB,
LAN and FM tuner section in BDV-E290.
• HBD-E490 is the amplifi er, video, HDMI, BD/DVD/CD system, USB,
LAN and FM tuner section in BDV-E490.
• HBD-E690 is the amplifi er, video, HDMI, BD/DVD/CD system, USB,
LAN and FM tuner section in BDV-E690.
Amplifi er Section
BDV-E690/BDV-E490/BDV-E290
US models:
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
(FTC)
Front L + Front R:
With 3 ohms loads, both channels
driven, from 180 Hz - 20 kHz;
rated 50 watts per channel minimum
RMS power, with no more than 1%
total harmonic distortion from 250
milli watts to rated output.
Other models:
POWER OUTPUT (rated)
Front L/Front R:
75 W + 75 W (at 3 ohms, 1 kHz,
1% THD)
POWER OUTPUT (reference)
Front L/Front R/Surround L/Surround R:
125 W (per channel at 3 ohms,1 kHz)
Center:
250 W (at 6 ohms, 1 kHz)
Subwoofer:
250 W (at 6 ohms, 80 Hz)
Inputs (Analog)
AUDIO (AUDIO IN)
Sensitivity: 1 V/400 mV
MIC 1/MIC 2
Sensitivity: 10 mV (Russian model)
Inputs (Digital)
TV (Audio Return Channel/OPTICAL)
Supported formats: LPCM 2CH
(up to 48 kHz), Dolby Digital, DTS
BDV-E190
POWER OUTPUT (rated)
Front L/Front R:
40 W + 40 W (at 3 ohms, 1 kHz,
1% THD)
POWER OUTPUT (reference)
Front L/Front R/Surround L/Surround R:
40 W (per channel at 3 ohms, 1 kHz)
Center:
70 W (at 6 ohms, 1 kHz)
Subwoofer:
70 W (at 6 ohms, 80 Hz)
9-890-582-05
Sony Corporation
2013A80-1
©
2013.01
Published by Sony EMCS (Malaysia) PG Tec
Photo: HBD-E290
Model Name Using Similar Mechanism
Mechanism Type
Optical Pick-up Block Name
SPECIFICATIONS
Inputs (Analog)
AUDIO (AUDIO IN)
Sensitivity: 2 V/700 mV
MIC 1/MIC 2
Sensitivity: 10 mV (Russian model)
Inputs (Digital)
TV (Audio Return Channel/OPTICAL)
Supported formats: LPCM 2CH
(up to 48 kHz), Dolby Digital, DTS
Video Section
Outputs
VIDEO: 1 Vp-p 75 ohms
HDMI Section
Connector
Type A (19pin)
BD/DVD/Super Audio CD/CD System
Signal format system
NTSC/PAL (except US, Canadian
and PX models)
NTSC (US, Canadian and PX models)
USB Section
(USB) port:
Type A (For connecting USB
memory, memory card reader,
digital still camera, and digital
video camera)
LAN Section
LAN (100) terminal
100BASE-TX Terminal
FM Tuner Section
System
PLL quartz-locked digital
synthesizer
Tuning range
87.5 MHz - 108.0 MHz
(50 kHz step) (except US, Canadian
and PX models)
(100 kHz step) (US, Canadian and
PX models)
BLU-RAY DISC/DVD RECEIVER
Canadian Model
HBD-E190/E490
AEP Model
E Model
HBD-E190/E290/E490/E690
UK Model
HBD-E190/E290/E490
Australian Model
HBD-E190/E290/E690
Chinese Model
Taiwan Model
HBD-E290/E490
Saudi Arabia Model
Thai Model
HBD-E290/E490/E690
South African Model
HBD-E190/E290
PX Model
BDP-S390
BPX-7
KEM480AAA
Antenna (aerial)
FM wire antenna (aerial)
Antenna (aerial) terminals 75 ohms, unbalanced
General
Power requirements
220 V - 240 V AC,
50/60 Hz (except US, Canadian, Taiwan,
Russian, Saudi Arabia and PX models)
127 V - 240 V AC, 50/60 Hz (Russian
and Saudi Arabia models)
120 V AC, 50/60 Hz (Taiwan model)
120 V AC, 60 Hz (US and Canadian
models)
110 V - 240 V AC, 50/60 Hz (PX
model)
Power consumption
BDV-E690/BDV-E490/BDV-E290
On: 130 W
Standby: 0.3 W
(at the Power Saving mode)
BDV-E190
On: 95 W
Standby: 0.3 W
(at the Power Saving mode)
Dimensions (approx.)
430 mm × 50 mm × 275 mm
(17 in × 2 in × 10 7 ⁄8 8 in) (w/h/d)
incl. projecting parts
Mass (approx.)
2.8 kg (6 lb 2 ¾ oz)
Design and specifications are subject to change without notice.
• Standby power consumption 0.3W.
• Over 85% power efficiency of amplifier block is achieved with
the full digital amplifier, S-Master.
HBD-E290
