DI/DO Diagram
Refer to the following illustration for connection method.
Status LED
The LED indicates the status of the Network Camera.
Status LED
Blinking red (two short, one long)
VIVOTEK - A Leading Provider of Multimedia Communication Solutions
12V
PIN 1
Power+12V
PIN 2
Digital output
+12V
PIN 3
Digital input
PIN 4
Ground
1. Power is being supplied to the Network Camera
2. Restore, or reboot the Network Camera
Description
User's Manual - 5
