Axminster UJK Pro Router Table Original Instructions Manual page 34

Exploded Diagram/Parts List
Index No Part No
1 3.22E+17
2 32240015
3 32240016
4 32240017
5 32240018
6 32240019
7
32240020
8
32240021
9
32240022
10
S3224002
11 32240023
12 32240024
13 32240025
14 32240026
15 32240027
16 32240028
17 32240029
18
910M10007
19
32240030
20
904M06012
21
914M061602
22 901M06016
24 L32240001
25 904M08050
26 901M06012
27 912M08000
Router Table & Stand Assembly (E Type)
Description
Router Table
Stand Cross Relief
Stand Side Support
Stand Leg
Stand Tie Bar (F&R
Stand Tie Bar (L&R)
Wheel Frame Bracket
Router Bit Storage
Switch Base (OPTIONAL)
Switch Box (OPTIONAL)
Wheel Housing
Plastic Wheel
Wheel Frame
Foot Pedal
Wheel Base
Wheel
Square Nut
Hex Nut
Leg Foot
Hex Cap Bolt
Flat Washer
Hex Socket Cap Screw
Power Cord (OPTIONAL)
Hex Cap Bolt
Hex Socket Cap Screw
Nylon Nut
34
Size
(813mm×610mm)
76mm
M10
M10
M6×12
M6
M6×16
1.5 mm²×3C
M8×50
M6×12
M8
Qty
1
2
2
4
2
2
1
2
1
1
2
2
1
1
1
1
4
4
4
40
51
1
1
2
8
4
