- Page 1 AVD4.6 Installation Guide...
- Page 2 Attachments - Do not use attachments which are not recommended by the manufacturer as they may cause hazards. Water and moisture - Do not install the AVD4.6 modules and power supply near water, for example, near a bath tub or sink; in a wet basement, or near a swimming pool etc.
- Page 3 The many different options and features of your new audio and video* distribution system will be a source of pleasure for you for many years to come. The Jamo AVD4.6 system is a distributed, multi-room home entertainment system capable of delivering high quality audio and video to multiple rooms and locations in your home.
- Page 4 Planning your system Detailed advanced planning should be done before installing the AVD4.6 system. It is therefore strongly recommended that the complete instructions are read before starting any installation. AM4.6 The main module (AM4.6) should be located close to the source components. This gives two location options.
- Page 5 AM4.6 IMPORTANT. The AM4.6 can be switched between Jamo A-BUS or standard A-BUS mode. The Jamo A-BUS position is used with the Jamo KP4.6 keypad and gives extra functions. When used with other A-BUS keypads it should be set to Standard A-BUS or they will not work.
- Page 6 The ALL COMMANDS sends remote signals from any remote control, and not only from the remote control as- sociated with the source selected. Two Jamo IF5 emitters are included with the AVD4.6 system. Speakers Main zone PS24 to AM4.6...
- Page 7 Video connections Video Source Connection A total of six video sources may be connected to the VM4.6. Cat5e The video output of the source VM4.6 equipment is connected to the RCA sockets on the VM4.6 labeled video inputs 1-6. Use quality 75 ohm coax- ial cable with RCA plugs in each end.
- Page 8 Hub Link in and out sock- ets on each AM4.6. The audio signals from the source equipment can be shared by joining the AM4.6’s using 12 pcs. Jamo C4.6 AM4.6 couplers. The couplers connect the 12 pcs.
- Page 9 CCTV (if applicable) (Cl os e d Circ uit T ele vis i on / surveillance) camera to the AVD4.6 system. The TV/monitor output from the VM4.6 camera is connected to the EXT/ CCTV in on the VM4.6. Live video can then be seen in each zone with a TV or monitor installed.
- Page 10 Specifications KP4.6 AM4.6 20Hz - 20kHz frequency range 6 source inputs -80dB, 32 step volume control 6 loop outputs +/- 16dB, 2db steps bass con- 1 external input/loop output trol 4 main & 4 sub-zones +/- 16dB, 2db steps treble con- Max 16 main &...
- Page 11 Jamo US or the Jamo Authorized Dealer will, at its option, repair or replace this product at no additional ch arge, except as set forth below. If this model is no longer available and can not be repaired effectively, Jamo US at its sole o ption, may replace the unit with a current model of equal or greater value.
