Summary of Contents for Vivitek DVR5612
-
Page 2: Important Statement
FCC Warning This product has undergone tests in pursuance of Part 5 of the FCC Regulations and has been found to meet the regulations for Class B devices, which are provided for reasonable protections while keeping the product from hazardous interference when installed and used. This product may emit radioactive energy while in use. -
Page 3: Method To Replace The Filter
Important Statement Maintenance Clear methods For the reason of safety, please make sure to unplug the power cord before start to do the cleaning. Cleaning for the case ■ To mop the outside of the case with soft and clean cloth. Follow the instruction if use any cloth containing certain chemical materials. ■ Do not use alcohol or other material inflammable, which will result in the decay of the case or paint fading. ■ Do not use robber or other clue-related material to interface with the case. It possibly will leave scar on the case. -
Page 4: Replacement Method Of Projection Lamp
Replacement method of projection lamp Projection lamps are supplies and have life span. Please contact the resellers when the image turns dark or color gets deteriorated. When this happens, please replace it with a new projection lamp. If the projection lamp could not light up and have noise, the possible reasons are: 1.The life span for the projection lamp are ended or 2.Shutting down the TV right after the turn-on of power. At the moment, the temperature of projection lamp is too high and does not cool down to certain degree. Turn it on after a few minutes and it will work properly. or 3.The projection lamp does not connect correctly with the lamp cradle. Replacement Procedure Beware of the high temperature when replace the projection lamp. -
Page 5: Table Of Contents
Index 1.Important Statement FCC Warning Accessories Check Maintenance Method to replace the filter Replacement method of projection lamp 2.Before Use Correct viewing Remote Control Handling Moisture Condensation 3.Safety Instructions - Warning and Caution 4.Connection with Antenna Cable 5.System Connection Front Connector Rear Connector 6.Introduction the Control Panel and Remote Control 16 7.Power ON / OFF... - Page 6 9.Programming the universal remote control To program the remote to control other devices: Device program codes Searching for device codes Reassigning device buttons Teaching the remote control new functions Using the universal remote control Using picture-in-picture (PIP) mode Setting the sleep timer Troubleshooting 10.Display Modes Video Input Format...
-
Page 7: Correct Viewing
Before Use Correct viewing Distance The most appropriate viewing distance varies between 5~7 times the height of the screen. Viewing Angle and Height Suitable viewing angle and height will avoid fatigue. Volume As a courtesy to others, be sure to keep the volume down (especially in the evening). -
Page 8: Moisture Condensation
Handling When move this unit. Please put your hands here Moisture Condensation When this device is suddenly moved to a warm site from a cold one, or in case of abrupt change of the environmental temperature, moisture condensation may cause a foggy screen or incorrect display output. It s because moisture congeal inside. Please wait until the moisture is evaporated, then screen will restore normal display. -
Page 9: Safety Instructions - Warning And Caution
Safety Instructions - Warning and Caution Smoking emitting from device In the case of smoke emitting from the product, be sure to turn off the power switch and remove the power plug immediately. Using the product while it is smoking may cause a fire or electric shock. - Page 10 Safety Instructions - Warning and Caution Do not place flower vases, glasses, cosmetics, chemical solutions, liquids or small metal objects on this device Liquid or small objects inside the device may cause fire or electric shock. In this case, turn off the power supply and remove the power plug before contacting the dealer.
- Page 11 Safety Instructions - Warning and Caution Keep the ventilation grill free *Do not let the screen face up, to the side or up side down. *Do not keep this device in a closet or bookshelf with poor ventilation. *Do not place this device on a rug or flammable objects. *Do not cover this device with curtains or tablecloths. Doing any above may cause a fire. Do not stand or sit on this device Be sure to keep children from climbing on top of the television set, since it may fall over, break or result in damage.
- Page 12 Safety Instructions - Warning and Caution Do not remove back cover, case front panel or any other cover The high-voltage components inside the unit may cause electrical shock if mishandled. For all adjustments and servicing to interior circuitry please contact the dealer. Be sure to remove the plug by holding the power cord plug Remove the power cord at the receptacle by pulling on...
-
Page 13: Connection With Antenna Cable
Connecting and Checking the Antenna Connection with Antenna Cable E. Connection with Antenna Cable 1. Cable without a CATV Converter 2. VHF/UHF Combination Antenna Cable TV lead-in VHF, UHF or VHF/UHF combination antenna 75 ohm coaxial cable (round) 300 ohm twin-lead (flat) 3. -
Page 14: System Connection
Please unplug the power cord of the machine and other devices attached before start to connect the device on the side of the machine. Front Connector Find the front connector here Use the Remote control or Machine front "Input" key to select the Input Front RGB source to Use the Remote control or Machine front "Input"... -
Page 15: Rear Connector
System Connection Rear Connector - 1 VCR, Stereo, VCD, DVD Player Video : Please use S-Video as the first priority for Video input, thus having a better image quality. Machines in early days, however, do not support S-Video; these devices only have Video for output. Please attach the Video output cable to the machine’s video input. If you attach the S-Video and Video output cable to the machine, the machine will use S-Video as the first priority for video input and at this moment, the video input for Video will not take any Audio: To left audio input (White) DVD, Satellite, Cable etc. Input video and Audio signal to the monitor. Video: To machine Y image input (Green) To machine Pb/Cb image input (Blue) To machine Pr/Cr image input (Red) Audio: To left audio input (White) To right audio input (Red) Use the Remote control or Machine front "Input" key to select COMP1 IN the Input source to If you are already using the COMP IN input for another... - Page 16 Rear Connector -2 Audio Connector (Hi-Fi stereo mini-jack plug) To audio out of computer Use the Remote control or Machine front "Input" key to select the Input source to The DVI port supports High-bandwidth Digital Content Protection (HDCP). HDCP encrypts the transmission between the video source and the digital Display for added security and protection. New generation for home entertainment Digital video equipment and other devices that have a digital interface compliant with the HDCP(High-bandwidth Digital Content Protection) & DVI (Digital Visual Interface) standard should be connected to the DVI/HDCP IN input of the RPTV.
-
Page 17: Introduction The Control Panel And Remote Control
Introduction the Control Panel and Remote Control .IR Sensor This is a windorw which receivers infrared signal from the remote controller 2.VOL When OSD disappear. Thess buttoms is used for adjust volume ◄Volume decreases ►Volume increases When OSD display. These are used for OSD menu ◄► item select 3.CH If the source of image is TV. These buttons are for selecting channels. If OSD display. These are used for OSD menu item select 4.OK Come with OSD menu. When choice one item, then press this button to adjust it's value. 5.Menu Press this button to show or disappear OSD menu. .INPUT Press this button to select correct image signal source. Such as TV, Video, PC...etc. 7.Power As long as the power cable on the back of the unit is plugged in the socket. This button can activate or deactivate the power at any time. - Page 18 Introduction the Control Panel and Remote Control Note: If remote control can not work. Please press buttom firstly and try again. Button name Function Starts all programming sequences. Setup Blinks when the remote is being programmed or is sending a signal Remote LED to your RP TV Power Turns your RP TV or other selected device on and off.
-
Page 19: Power On / Off
Power ON / OFF Power on Operation status 1.Connect the power cord into 110V~240V Plug 2.Push the power button on the front panel .Successfully power on Power off Operation status .Push the power button on the front panel 2.Press the power button again to make sure you want to power off this RPTV. .Successfully power off Note: In order to protect the lamp, when you press the wait at least 0 seconds for cooling down the lamp, then could press the RPTV again. -
Page 20: Before Use Osd, You Must Know
Before use OSD, You must know: Recommended ways to learn about operations Before starting, please follow the suggested steps to understand the fundamentals of operating the display, and then you will be able to learn the operations in a short time: 1.Please first learn to power on and power off the display. Refer to page 18 for the descriptions of the operations. -
Page 21: Osd Explanation
How to use OSD OSD explanation Picture Adjust For other input source (Except Front RGB, RGB, DVI) Only for Input source Mode: Front RGB, RGB, DVI Original image 1.CONTRAST Adjust the contrast of the screen image ◄ Reduce contrast ► Increase contrast 2.BRIGHTNESS Adjust the brightness of the screen image ◄ Reduce brightness ► Increase brightness 3.COLOR Adjust the color saturation of the screen image ◄ Reduce saturation ► Increase saturation 4.TINT Adjust the tone of the screen image ◄ Increase red tone ► Increase green tone 5.SHARPNESS ◄ Reduce sharpness ► Increase sharpness... -
Page 22: Noise Reduction
6.COLOR TEMPERATURE Use ◄ ►to adjust the color temperature ♦ NEUTRAL General neutral setting ♦ WARM To increase the red tone of the display, obtain the white and more vivid red colors among warm ones. ♦ COOL To increase the blue tone of screen images, obtain the white color among soft colors. Generally suitable for offices with fluorescent lamps. 7.NOISE REDUCTION Use ◄ ► to change on / off ♦ ON To reduce the Noise, regular do this action could help you to get the clear image. ♦ OFF Not reduce the souce image. Keep original image situation. -
Page 23: Auto Config
How to use OSD ♦ Stretch An image fully fills the screen. ♦ Dot by Dot Detects the resolution of the signal and displays an image with the same number of pixels on the screen. Notes: * Wide Format is not available when using the POP, SPLIT functions. * When you use 720p or 1080i signal input source. The screen will always keep STRETCH mode. 9. DEFAULT Use ◄ ►to select ON or OFF. Mean call the factury default setting for Picture Adjust. OFF Keep your picture adjust setting. 10.H POSITION Use ◄ ►to change image Horizontal position. 11.V POSITION Use ◄ ►to change image Vertical position. 12.AUTO CONFIG Press to auto get the input signal again. 13.ADC CLOCK Use◄ ►to change the clock value Adjusting the image interference. When the screen... -
Page 24: Pip Setup
PIP SETUP WIDE FORMAT, SIZE, H POSITION, V POSITION, TRANSPARENCY these function are only available for PIP STYLE. POP, SPLIT mode can't use. 1.PIP STYLE =remote control key "STYLE" Use ◄ ► to select OFF, PIP, SPLIT, POP ♦ OFF only display main picture, not display sub-picture. ♦ PIP Display the sub-picture on the screen. Sub-Picture Main-Picture ♦ SPLIT The screen is divided in half. Main-Picture Sub-Picture ♦ POP The screen is in the : mode and divided in half. Main-Picture Sub-Picture How to use OSD 2.WIDE FORMAT... -
Page 25: Input Setup
How to use OSD INPUT SETUP 1.MAIN INPUT =remote control key "INPUT" Press first, then use ◄ ► to change the Main picture input source signal. such as TV, FRONT RGB, RGB, DVI, AV1, AV2, FRONT AV, COMP1, COMP2 Change main picture's input signal source 2.PIP INPUT =remote control key "SOURCE" Press first, then use ◄ ► to change the Main picture input source signal. Change sub-picture's input signal source 3.INPUT SIGNAL Press first, then use ◄ ► to change. When input source is 640*480, you can use this function change it to 720*480. - Page 26 3.DIGITAL TV SETUP ♦ CHANNEL SETUP(DTV) ●AUTO SEARCH(DTV) Press to let machine auto search the whole channels. ●MANUAL SEARCH You could also search the channel by yourself. Just keyin the channel's no. then press add that channel. ●EDIT Edit channel for parenthesis. Use this function to easy control the channel by menu. ♦ CLOSED CAPTION(DTV) ●CAPTION SERVICE Depend on the input signal are supported which services, like CC1, CC2, CC3, CC4, CS1, CS2, CS3, CS4, CS5, CS6. How to use OSD ●CAPTION SIZE Adjust caption size. Such as, Default, small,...
-
Page 27: Audio Adjust
How to use OSD AUDIO ADJUST 1.BASS Use ◄► to djust the ratio of Bass 2.TREBLE Use ◄► to djust the high-pitched sound 3.BALANCE Use ◄► to djust the balance level between left and right speakers. 4.SPEAKER Use ◄► to select speaker on or off SP ON: Audio from built-in speakers. SP OFF: You can select speaker off to mute the audio. When use another amplifier device, you may need to setup the speaker off. 5.SUB VOL Use ◄► to djust sub-picture's volue. The RPTV audio will always sound main-picture's voice.You need to use Headphone or earphone to listen the sub-picture's voice and use this function to adjust the volue louder or lower. 6.EFFECT =remote control key "AUDIO" Use ◄► to select audio effect mode. ♦SRS = Sound Retrieval System Base on the human hearing system; use the HRTF characteristics to compensate difference between traditional recordings. Extract the hidden environment sounds from the recording, and then process and... -
Page 28: Parental Control
PARENTAL CONTROL The parental controls feature prevents viewers from watching programs that are not age-appropriate, such as programs containing violence or adult language. The factury default access code is 0000. Just use remote control keyin the number to enter the parental controls sub-menu. When enter the parental controls sub-menu. It will display the OSD as below: 1.MPAA RATING U -> Unblock , B -> Block Use ▲▼to select which rating you want to block or ENTER... -
Page 29: Pecial Feature
How to use OSD SPECIAL FEATURE 1.OSD H POSITION Use ◄►to move OSD horizontal position. 2.OSD V POSITION Use ◄►to move OSD vertical position. 3.OSD TIMEOUT Use◄►to set up OSD display time, the value range is 5 seconds to 4 seconds. After press the MENU key, the OSD will appear. If the OSD TIMEOUT is set to 0 seconds, OSD screen will automatically disappear in 0 seconds if not any key is pressed. -
Page 30: To Program The Remote To Control Other Devices
Programming the universal remote control The TV device button has been preset to work with your RPTV TV (program code 0080). You can program the remote control to work with as many as seven other devices. To program the remote to control other devices: Turn on the device. 2 Press the matching device button on the remote control. SETUP Press and hold the button until the LED flashes twice. 4 Enter the programming code for the device and manufacturer. For a list of device programming codes, see“Device program codes” below. If the code is accepted, the LED flashes twice after the last digit is entered. If the LED does not flash twice, repeat Steps 2 through 4 with the next code listed for the device and manufacturer. Important If there more than one code listed for the device and manufacturer, make sure that you try all the codes listed to find the one that works for the device. -
Page 31: Cd Player Codes
Programming the universal remote control CD Player codes Manufacturer Aiwa Burmester California Audio Labs Carver Denon Emerson Fisher Garrard Genexxa Harman/Kardon Hitachi Kenwood Krell Linn Magnavox Marantz Mission Onkyo Optimus Computer and Home automation codes Manufacturer Gateway One For All Radio Shack Program Code Manufacturer... -
Page 32: Dvd Player Codes
Programming the universal remote control DVD Player codes Manufacturer Program Code Apex 0672 Denon 040 Fisher 070 Gateway 00 0522 Gradiente 05 Hitachi 057, 04 Hiteker 0672 0623, 0558 Kenwood 0682, 0534 Konka 0719, 0711, 0720, 0721 Magnavox 050, 075 Marantz 05 Mitsubishi 0521 Onkyo 050 Receiver codes Manufacturer... - Page 33 Programming the universal remote control Satellite set-top box codes Manufacturer AlphaStar Chaparral Echostar Expressvu General Instrument Hitachi Hughes Network Systems Magnavox Memorex Mitsubishi TV codes Manufacturer Admiral Aiko Aiwa Akai Alaron America Action Anam Audiovox Baysonic Belcor Bell & Howell Bradford Brockwood Broksonic Candle Carnivale Carver Celebrity...
- Page 34 Programming the universal remote control Manufacturer Program Code Crown 00 Curtis Mathes 000, 000, 00, 0047 005, 0054, 005, 00 045, 054, 0, 045 47, 47 Daewoo 0092, 0623, 0019 0624, 0451 Daytron 00 Denon 045 Dumont 007, 00 Electroband 0000 Emerson 0236, 0180, 0178 0179, 0463, 0624 0623, 0019, 0154 Envision...
-
Page 35: Vcr Codes
Programming the universal remote control Manufacturer Luxman Magnavox Majestic Marantz Matsushita Megatron VCR codes Manufacturer Admiral Adventura Aiko Aiwa America Action American High Asha Audiovox Beaumark Bell & Howell Broksonic Calix Canon Carver Cineral Citizen Colt Craig Curtis Mathes Cybernex Daewoo Denon Dynatech Electrohome Electrophonic Emerex... - Page 36 Programming the universal remote control Manufacturer Program Code Emerson 0184, 0002, 0209 0278, 0121, 0479 0000, 007, 004 Fisher 0047, 004 Funai 0000 0035, 0060, 0048, 0240 Garrard 0000 Go Video 0432 GoldStar 007, 00 Gradiente 0000 HI-Q 0047 Harley Davidson 0000 Harman/Kardon 00, 00 Harwood 0072 Hitachi 0042, 0000 Hughes Network 0042 Systems...
-
Page 37: Reassigning Device Buttons
Programming the universal remote control Searching for device codes If you cannot find your manufacturer in the device list or the program code does not work, you can use the remote control to search for the correct device code. To search for a device code: Turn on the device. 2 Press the matching device button on the remote control. SETUP Press and hold the 4 Press . The LED flashes twice. 5 Point the remote control at the device and alternate between POWER pressing the... -
Page 38: Teaching The Remote Control New Functions
Programming the universal remote control Teaching the remote control new functions The remote control can learn up to 25 additional functions from the device’s original remote control. Example: Your DVD player remote control has a scan function that you may use frequently. There is not a scan button on the remote control. You can assign a button and use the DVD remote to teach the remote control the scan function. Important Make sure that you have already programmed the remote control for the device. See “ Programming the universal remote control” on page 29. Make sure that area lighting is not too bright or it will interfere with the learning process. To teach the remote control a new function: 1 Press and hold the SETUP button on the remote control until the LED flashes twice. -
Page 39: Using Picture-In-Picture (Pip) Mode
Programming the universal remote control Using picture-in-picture (PIP) mode When the picture-in-picture (PIP) mode is active, one picture is displayed on the full screen (main picture) and the other picture is displayed in a small window (sub-picture). To control PIP mode using the universal remote control: Press the device button. 2 Press the button on the remote control once to turn on PIP mode. A small window appears in one corner of the screen. The picture on the full screen is the main picture. The picture in the window is the sub- picture. -
Page 40: Troubleshooting
Programming the universal remote control Troubleshooting Use the following information to solve common problems. The LED doesn’t blink when a button is pressed. Replace the batteries. Insert two AA batteries into the remote control. Make sure that you match the + and – on the batteries with the + and –... -
Page 41: Default Pc Input Mode
Display Modes Video Input Format Input Format 40i 4: 480p 4:3 / SMPTE 293M 720p / SMPTE 296M 1080i / SMPTE 274M Default PC Input Mode The display automatically detects: 1) Horizontal sync signal frequency between 30.0 ~ 60.0 kHz 2) Vertical sync signal frequency between 50 ~ 85 Hz. But 60 Hz vertical sync input signal is recommended, for it will take the display longer to display the screen when other input signals are used. The display supports resolution up to 1024 * 768, the higher mapping ratio entered will be automatically changed to 1024*768. The display supports the general industry factory default modes as follows: Resolution 640x350 @70Hz 640x350 @85Hz... -
Page 42: Specifications
Multimedia digital projector display / TV Product Name Main system Power AC 110V/220V 50 Hz / 60 Hz Power Consumption 220W Weight 40Kg Viewable Area 853 mm - Length 640 mm - Hight 1066 mm - Diagonal Physical Dimensions 1381 mm - Length 482 mm - Hight 1113.5 mm - Diagonal Speaker 2 circular ones, 120 mm Audio Output Maximum output 10W + 10W (Total audio output 20W) Simulated RGB input Video signal: D-SUB 15 pin RGB video signal connector Simulation: 0.7V (p-p) 75 Ohm Maximum dpi: XGA (1024*768) Horizontal Sync: Positive / Negative TTL Frequency: 30KHz-70K HzVertical Sync: Positive / Negative TTL Frequency: 50Hz-85Hz Audio Signal: 150mV (rms) over 47 thousand Ohms (AV Terminal) Number T. M. D. S Video signal: Standard T.M.D.S DVI-D 24 Pin input Audio signal: 150mV (rms) over 47 thousand Ohm (AV Terminal) Headphone 3.5 mm diameter stereo connector Resistance larger than 20 Ohm TV System Standard NTSC 181 CH or PAL system Received Channels Regular TV (VHF: 2-13 UHF:14-69) Cable TV (2-125) Image output / input S-Video: terminals(video, audio) -
Page 43: Troubleshooting
Troubleshooting Sometime the set up problems or other reasons will result in the false impression of display malfunctions. Please check before sent for repair: If following situations Power LED does not light No image The remote does not work Delays for video and audio outputs Dim image Blurry image Overlapped... -
Page 44: Led Status
Lamp LED Power LED Normal Operation States Power LED AC off Not lit Standby mode Orange Warm-up/Cool down Blue Operation mode Blue Error Codes States Power LED Flashes blue twice, then orange once Flashes blue three times, then orange twice. Flashes blue five times, then orange twice. -
Page 45: Service Information And Announcement
Service Information and Announcement Service Information If troubleshooting information does not resolve your problem or if you have other questions relating to you Micro Chip Display Projection, visit www.vivitek.us You can also call our Announcement All Rights Reserved. Vivitek Corp 407 Fremont Blvd. Fremont, CA 45 All Rights Reserved This publication is protected by copyright and all rights are reserved. No part it may be reproduced or transmitted by any means or in any form, without prior consent in writing from Vivitek. - Page 47 Vivitek Corp. 407 Fremont Blvd. Fremont, CA 45 Tel: (510) 651-0881 Efax: (510) 226-4163 © 2005 Vivitek Copyrights...
