STEP 4 – MANAGING THE SD CARD
1. To install the camera's SD Card,
locate the SD card slot in the back
of the camera. Thumbnail view
2. Insert a class 10 SD/SDHC/
Select network to scan
SDXC card into the SD card slot
by pressing the SD card until it
"clicks" into place.
Show/hide thumbnail view
3. To remove the SD card, press the
Refresh thumbnail view
card inward to release it from the
Bulk IP assignment
card slot.
Bulk password assignment
Firmware upgrade
NOTE: When inserting the SD card
into the card slot, the SD card's
contacts should be facing
upward, as shown in the diagram.
STEP 5 – DW® IP FINDER
Use the DW® IP Finder™ software to scan the network and detect all MEGApix®
cameras, set the camera's network settings or access the camera's web client.
Filter results
Scan network
Network Setup
1. To install the DW® IP Finder™, go to:
http://www.digital-watchdog.com
2. Enter "DW® IP Finder" on the search box at the
top of the page.
3. Go to the "Software" tab on the DW® IP Finder™
page to download the installation file.
4. Follow the installation to install the DW® IP
Finder™. Open the DW® IP Finder™ and click
'Scan Devices'. It will scan the selected network
for all supported devices and list the results in
the table. During the scan, the DW® logo will
turn gray.
Select DHCP to allow the camera to receive its IP
address automatically from the DHCP server.
Select "Static" to manually enter the camera's
IP address, (Sub)Netmask, Gateway and DNS
information.
* The camera's IP must be set to Static if
connecting to
Spectrum® IPVMS
Contact your network administrator for more
information.
Default TCP/IP information: DHCP
5. When connecting to the camera for the first time,
a password must be set. To set up a password for
your new camera:
a. Check the box next to your new camera from the
IP Finder's search results. You can select multiple
cameras.
™
b. Click "Bulk Password Assign" on
the left.
c. In the pop-up window, enter
admin/ admin in the
current username and password
fields. Enter a new username
and password to the right.
d. Press "change" to apply all
changes.
6. Select a camera from the list by
double-clicking on the camera's
image or clicking on the 'Click'
button under the IP Conf. column.
The pop-up window will show
the camera's current network
settings, allowing admin users to
adjust the settings as needed.
7. To access the camera's web page,
go to the IP Config page and click
'View Camera Website'.
8. To save the changes made to
the camera's setting, input the
username and password of the
camera and click Apply.
'Port forwarding' has to be set in your
network's router for external access to
the camera.
STEP 6 – WEB VIEWER
DHCP status
Firmware version
Camera's uptime
Open IP configuration
settings
*
Ping camera
Port information
Gateway address
Netmask address
Camera's MAC address
Part number
Once the camera's network settings have been setup properly, you can
Camera's IP address
access the camera's web viewer using the DW® IP Finder
Camera's name
To open the camera's web viewer:
1. Find the camera using the DW® IP Finder
2. Double-click on the camera's view in the results table.
3. Press the 'View Camera Website'. The camera's web viewer will
open up in your default web browser.
4. Enter the camera's username and password you setup in the DW®
IP Finder™. If you did not setup a new username and password via
the DW® IP Finder™, you will not be able to view video from the
camera. A message will direct you to setup a new password for the
camera to view the video.
5. When accessing the camera for the first time, install the VLC player
for web files to view video from the camera.
NOTE: 32bit version of VLC player must to be installed. If you are
using 64bit system, uninstall the previous 64bit version and
reinstall using the 32bit version.
NOTE: Some menu options may not be available based on the
camera model. See the full manual for more information.
Rev Date: 05/20 Specifications and pricing are subject to change without notice.
Quick Start Guide
The GUI display may differ by camera models.
.
™
.
™
