PER L'USO E LA MANUTENZIONE
*
OPERATION AND MAINTENANCE MANUAL FOR
MANUEL D'INSTRUCTIONS
POUR L'UTILISATION ET L'ENTRETIEN
GEBRAUCHS- UND WARTUNGSANLEITUNG
MANUAL DE INSTRUCCIONES
PARA EL USO Y EL MANTENIMIENTO
LIBRETTO ISTRUZIONI
DEI FRY TOP A GAS
GAS FRY TOPS
DES FRY TOPS
GAZ
FÜR GAS-FRY TOPS
DEL FRY TOP GAS
131.1413 / 131.1813
COD.: ZSL6508
REV. 04 / 2012
Advertisement
Table of Contents
Related Manuals for Bartscher 131.1413
Summary of Contents for Bartscher 131.1413
- Page 1 GAS FRY TOPS MANUEL D’INSTRUCTIONS POUR L’UTILISATION ET L’ENTRETIEN DES FRY TOPS GEBRAUCHS- UND WARTUNGSANLEITUNG FÜR GAS-FRY TOPS MANUAL DE INSTRUCCIONES PARA EL USO Y EL MANTENIMIENTO DEL FRY TOP GAS 131.1413 / 131.1813 COD.: ZSL6508 REV. 04 / 2012...
- Page 2 CONTENTS 1. INSTALLATION ..........................Pag. 8 1.1 IMPORTANT NOTICES ................................ Pag. 8 1.2 POSITIONING ..................................Pag. 9 1.3 EVACUATION OF EXHAUST FUMES ..........................Pag. 9 1.4 CONNECTING GAS ................................Pag. 9 INSTALLATION INSTRUCTIONS ............................Pag. 9 CHECK BEFORE INSTALLATION ............................Pag. 9 CHECKING THERMAL POWER ............................Pag.
- Page 3 POSITIONING Fig. 1 Remove the appliance from the packing, check it for damage and place it in the installation position. Level it and adjust its height by using the levelling feet indicated in (Fig. 1). The appliance must be kept at least 10 cm away from flammable walls. The bain marie may be placed against refractory and non-combustible walls. Do not obstruct the aspiration or heat di- scharge openings and gaps and place the appliance underneath an extraction hood that...
- Page 4 Check on the rating plate inside on the left-hand side that the appliance has been tested and approved for the type of gas that the user uses. Check that the nozzles on the appliance are suitable for the available gas supply. Use the rating plate data to check that the pressure reducer installed upstream of the appliance provides the appliance with sufficient pressure (Fig.2).
- Page 5 CONNECTING TO A DIFFERENT TYPE OF GAS REPLACING MAIN BURNER NOZZLE (Fig. 4) Burner Fig. 4 Nozzle Before adapting to a new type of gas, shut off the gas cock upstream. Loosen the screws that hold the front control panel in place and disconnect the electric cables of the piezoelectric ignition.
- Page 6 OPERATING INSTRUCTIONS The appliance must be used only for the purpose for which it was designed. Any other use is improper. During operation, supervise the appliance. STARTING UP FOR THE FIRST TIME Before starting up the appliance for the first time remove all the packing and thoroughly clean the protective industrial grease from the appliance using water and normal detergent. BIMETAL PLATE - INSTRUCTIONS FOR USE When the plate is warm, dampen very slightly with vegetable oil and wait until the plate reaches the desired tem- perature.
- Page 7 of the appliance. Use warm soapy water on steel surfaces and then rinse in plenty of water and dry with a soft cloth. Maintain the shine by regular polishing with a normal liquid polish. Do not wash the work top or floor with hydrochloric acid. PLATE In order to remove any encrusted residue, scrape with a hard plastic spatula positioned at an angle. Clean the plate regularly using a damp cloth.
