SWITCHING ON THE BOILER

Before starting the boiler ensure electric, gas and
water connections are properly made and the
appliance is supplied with correct power as stated
in the data plate.
a. Open power supply connection.
b. Turn gas cock to open position.
off
c. Push on button (
d. Select Summer/Winter mode. (
WARNING: In summer mode the boiler does not
start unless a hot water tap is opened.
e. Start the boiler by adjusting to your desired
temperature through temperature adjustment
buttons. (When the temperature adjustment
button is used the temperature adjustment
is flashes on the display and temperature
adjustment changes with 1°C steps . When you
have adjusted the desired temperature the LED
display returns to the previous status after 5
seconds.)
WARNING: When the boiler is first started the
boiler may show ignition failures and go into block
several times till the air in the gas supply line is
evacuated. In that case push (
and wait for 3 seconds to restart the boiler.
DHW Temperature
Adjustment Button
Mode Button
DHW Symbol
Multiple Function Indicator
4
). Figure 1
Mode
) Figure 1
Reset
) button
Figure 1
Digital
Central Heating Flow
Display Temperature Adjustment Button
Reset Button
Manometer
Burner Burning Symbol
CH Symbol
DAILY OPERATION OF
5
THE BOILER
Summer/Winter mode selection;
When it is not required to use Central Heating mode
of the boiler, the appliance may be turned to Summer
mode sole to produce Domestic Hot Water. In order
to set Summer mode push (
WARNING: As the mode button also functions
as "on-off" button if pushed longer the boiler is
switched off. When the boiler is off pump blocking
safety is active, anti-freezing protection is not active.
a. When the appliance is in Summer mode the
display shows (
Mode
the button with (
to make desired selection. To set hot water
temperature you may use (
set the desired temperature.
In Summer mode pump anti blocking safety and
anti-frost protection are active.
b. When the appliance is in Winter mode the display
shows ( ) and (
Mode
the button with (
make desired selection.
c. To set Central Heating temperature you may use
( ) (+/-) buttons to set the desired temperature.
For domestic hot water temperature adjustment
with ( ) (+/-) buttons you may set the desired
temperature.
In Winter mode pump anti blocking safety and
anti-frost protection are active.
d. When the boiler is set to "only Heating" mode
the display shows (
Mode
the button with (
make desired selection. To set Central Heating
temperature you may use (
set the desired temperature.
In Only Heating mode pump anti blocking safety
and anti-frost protection are active.
WARNING: When the boiler switches on after a
heat demand (when the burner is on), (
is show in the display.
6

FILLING THE BOILER

Filling water is supplied through the filling valve
located in the bottom of the boiler, Figure 3. When
the boiler is cold the installation should be filled such
that the manometer located in the front of the boiler,
(Figure 2) indicates a water pressure between 1-1,5
Mode
) button.
) sign. To set this mode;
) sign may be pressed
) (+/-) buttons to
) signs. To set this mode;
) sign may be pressed to
) sign. To set this mode
) sign may be pressed to
) (+/-) buttons to
) sign
