- Page 1 Conventional Combi Boiler Installation And User’s Manual Thermex Antares Read carefully before operating the appliance. HM 24 - HM 28 Room Sealed Conventional Combi Boiler www.thermex.com.tr...
- Page 2 Thermex Antares Room Sealed Conventional Combi Boiler Installation and User’s Manual - ENG INDEX PAGE 1- INTRODUCTION 2- WARNINGS FOR THE USER 3- CONDITIONS INELIGIBLE FOR WARRANTY 4- SWITCHING ON THE BOILER 5- DAILY OPERATION OF THE BOILER 6- FILLING THE BOILER...
-
Page 3: Warnings For The User
Thermex Antares Room Sealed Conventional Combi Boiler Installation and User’s Manual - ENG g. The appliance is not designed for children use INTRODUCTION so its installation is made in such way to make children difficult to access. THERMEX (ANTARES) HM 24 - HM 28 room sealed h. -
Page 4: Switching On The Boiler
Thermex Antares Room Sealed Conventional Combi Boiler Installation and User’s Manual - ENG SWITCHING ON THE BOILER DAILY OPERATION OF THE BOILER Before starting the boiler ensure electric, gas and water connections are properly made and the Summer/Winter mode selection;... -
Page 5: Installation Instructions
Thermex Antares Room Sealed Conventional Combi Boiler Installation and User’s Manual - ENG bar. When the pressure drops to the critical level the Check your installation before making connections appliance shuts-off automatically. to the boiler and ensure that the installation pipes are free from dirt or any particles. -
Page 6: Flue Connection
Thermex Antares Room Sealed Conventional Combi Boiler Installation and User’s Manual - ENG d. On the chimney walls Figure 5 e. Balconies f. Elevator shafts. The followings must be observed when making flue connection: a. Flue terminal vertical distance to eaves and roof... -
Page 7: Electric Connection
Thermex Antares Room Sealed Conventional Combi Boiler Installation and User’s Manual - ENG Figure 8 Figure 11 Total Equivalent Air Baffle Product Flue Lenght (mm) Ø46 Ø44 L1 + L2 = 3 m 90° elbow = equal to 1 m flue length... -
Page 8: Error Codes
Thermex Antares Room Sealed Conventional Combi Boiler Installation and User’s Manual - ENG ELECTRIC SCHEME AND ROOM THERMOSTAT The room thermostat can be connected to the main Figure 12 board by removing the bridge shown in Figure 12 and connecting the cables of the room thermostat to these terminals. -
Page 9: Technical Data
Thermex Antares Room Sealed Conventional Combi Boiler Installation and User’s Manual - ENG TECHNICAL DATA Figure 14 Technicial Specifications Thermex Thermex Condensing Boiler Models Unit Antares HM 24 Antares HM 28 Gas Type Gas Inlet Pressure (for G20) mbar Type... - Page 10 Thermex Antares Room Sealed Conventional Combi Boiler Installation and User’s Manual - ENG Pump Operating Field 15-5 Thermex Antares (HM 24 kW) Head Power 100,0 90,0 80,0 70,0 60,0 50,0 40,0 100,0 30,0 90,0 20,0 80,0 10,0 70,0 0,000 0,500...
- Page 11 Thermex Antares Room Sealed Conventional Combi Boiler Installation and User’s Manual - ENG This document is issued to provide information about the appliance. THERMEX, in order to develop/improve its products, preserves the right to modify instruction and user’s manual without prior notice.
- Page 12 Dear Customer, Thank you for choosing a Thermex product. www.thermex.com.tr Revision 2 / 25.04.2020...
