- Page 1 RIGEL CONDENSING COMBI BOILER COMBI BOILER INSTALLATION AND USER’S MANUAL Read carefully before operat ng the appl ance...
- Page 3 INDEX 1. INTRODUCTION 2. WARNINGS FOR THE USER 3. CONDITIONS INELIGIBLE FOR WARRANTY 4. SWITCHING ON THE BOILER 5. DAILY OPERATION OF THE BOILER 6. FILLING THE BOILER 7 . SWITCHING OFF THE BOILER 8 . MAINTENANCE OF THE BOILER 9 .
-
Page 4: Warnings For The User
Thermex authorised service. 3. CONDITIONS INELIGIBLE FOR WARRANTY The THERMEX warranty claim does not apply any failures arising from any use of the appliance out of such men oned in this manual as well as from the following cases: a. -
Page 5: Switching On The Boiler
h. Arising from the failure of observing the periodic maintenances specified in the instruc ons to be done in me by the authorized service agencies, i. arising from other accessories and ancillary products used with the appliance, j. Arising from freezing k. - Page 6 Figura 1 5. DAILY OPERATION OF THE BOILER Summer/Winter/Only Hea ng mode selec on When it is not required to use central hea ng, the appliance may be switched to Summer mode only to produce domes c hot water. To set Summer mode simply turn central hea ng temperature adjustment bu on to “Sun”...
-
Page 7: Filling The Boiler
6. FILLING THE BOILER Filling water is supplied through the filling valve located in the bo om of the boiler, Figure 3. When the boiler is cold the installa on should be filled such that the manometer located in the front of the boiler, (Figure 2) indicates a water pressure between 1-1,5 bar. -
Page 8: Maintenance Of The Boiler
8. MAINTENANCE OF THE BOILER In order to use your appliance trouble-free and efficiently for long years we recommend scheduling annual maintenance, preferably at early winter season, by Thermex authorised service. Do not clean external surfaces of your appliance with detergent or chemical materials. - Page 9 Figura 5 Figura 6...
-
Page 10: Connecting The Flue
11. CONNECTING THE FLUE When connec ng the flue, the flue gas accessories supplied by the manufactured must be used. When selec ng the loca on of the boiler the posi on of flue gas connec on and flue terminal should be considered. - Page 11 Figura 8 Figura 9 Figura 10...
-
Page 12: Electric Connection
12. ELECTRIC CONNECTION The appliance must be connected to a power supply line with an efficient earth connec on. The appliance must be connected to 220~230V single phase power supply line with efficient earth connec on through (3-10A)V. Automa c circuit breaker. 13. - Page 13 Figura 11...
-
Page 14: Error Codes
14. ERROR CODES The appliance displays certain failures or warnings on the display to inform the user, Figure 12. In such case if the error does not disappear a er performing the indicated ac on the closest authorised service must be called to fix the error of the appliance. Figura 12 The fail is signalled, all requests are inhibited, the TWV is switched in CH direc on and the Pump is ac vated un l... - Page 15 Figura 13...
- Page 18 Dear Customer, Thank you for choosing a Thermex product. www.thermex.com.tr 0850 775 05 15...
