  • Page 1 ADVANCE - ADVANCE - ADVANCE XL Operatore elettromeccanico per por te sezionali I str uz i o ni d’ u s o e d av ver te n z e Sectional door electromec hanical operator O p e r a t i ng in st ru c t i o n s an d war n in g s Moto-reducteur pour por tes sectionnelles Noti c e d ’e mplo i et ave r t is s e men t s Elektromec hanisc her Antrieb für Sc hwing- und Sektionaltore...
  • Page 3: Warnings Summary

    Sectional door ADVANCE electromechanical operator Operating instructions and warnings Index Warnings Summary Basic Functions Product Description Standard Programming Technical data Advanced Programming Installation and Assembly Messages shown on the Display Electrical Connections Start-up - ADVANCE Maintenance - ADVANCE XL Product Disposal SYMBOLS The following symbols are used within this manual to indicate potential hazards.
  • Page 4 WARNING Using spare parts not indicated by DEA System and/or incorrect re- assembly can create risk to people, animals and property and also damage the product. For this reason, always use only the parts indicated by DEA System and scrupulously follow all assembly instructions.
  • Page 5: Product Description

    WARNING Any external security devices used for compliance with the limits of impact forces must be conform to standard EN12978. WARNING In compliance with EU Directive 2012/19/EG on waste electrical and elec- tronic equipment (WEEE), this electrical product should not be treated as municipal mixed waste.
  • Page 6: Technical Data

    3 TECHNICAL DATA OPERATOR ADVANCE ADVANCE XL Motor power supply voltage (V) 24 V Absorbed power (W) Max Thrust (N) 1200 Work cycle (cycles/hour) Maximum n° of operations in 24 Operating temperature range (°C) -20÷50 °C Opening speed (cm/s) Weight of product with package (Kg) Sound pressure emitted (dBA) <...
  • Page 7: Control Unit

    In the event of a malfunction or power failure, the motor can be released as shown in Fig. 6a or 6b in order to move the door manually. CAUTION The safety and effi cacy of moving the automation manually is only guaranteed by DEA System if the system has been...
  • Page 8 5.1 ELECTRICAL CONNECTIONS FOR THE ADVANCE MODELS ! Risk of malfunction due to improper installation ! ! Risk of personal injury and property damage due to electric shocks ! Execute the wiring following the directions of “Table 1” and diagram (Pag. 31). WARNING To ensure an appropriate level of electrical safety always keep the 230V power supply cables apart (minimum 4mm in the open or 1 mm through insulation) from low voltage cables (motors power supply, controls, electric locks, aerial and auxiliary circuits power supply), and fasten the latter with appropriate clamps near the terminal boards.
  • Page 9 ADVANCE WIRING DIAGRAM INTERNAL WIRING SET BY THE FACTORY MOT 1 EXTERNAL WIRING SET BY THE INSTALLER FLASH MOT 1 Motor Terminal Block Plug COURTESY LIGHT CON2 CON2 CON3 230V CON1 ENC (M1) MOT 1 POWER SUPPLY 230V~ 50Hz ±10% H05VV-F 3x0,75mm FLASH PHOTO 1...
  • Page 10: Basic Functions

    5.2 ELECTRICAL CONNECTIONS FOR THE ADVANCE XL MODELS ! Risk of malfunction due to improper installation ! ! Risk of personal injury and property damage due to electric shocks ! Execute the wiring following the directions of “Table 2” and diagram (Pag. 33). WARNING To ensure an appropriate level of electrical safety always keep the 230V power supply cables apart (minimum 4mm in the open or 1 mm through insulation) from low voltage cables (motors power supply, controls, electric locks, aerial and auxiliary circuits power supply), and fasten the latter with appropriate clamps near the terminal boards.
  • Page 11 ADVANCE XL WIRING DIAGRAM INTERNAL WIRING SET BY THE FACTORY MOT 1 EXTERNAL WIRING SET BY THE INSTALLER FLASH MOT 1 Motor Terminal Block Plug COURTESY LIGHT CON2 CON2 CON1 +24VAUX CON3 230V ENC (M1) MOT 1 POWER SUPPLY 230V~ 50Hz ±10% H05VV-F 3x0,75mm FLASH PHOTO 1...
  • Page 12: Standard Programming

    7 STANDARD PROGRAMMING To access the control unit programming functions, remove the lid from the electric box and remove Jumper J4 from the bo- ard. NORMAL FUNCTIONING PROGRAMMING MODE 1 Power Supply When turned on, “ ”, “ ” (or the current fi rmware version) “ ”, “...
  • Page 13: Deletion Of All Transmitters

    3 Transmitters learning 1. Scroll down the parameters with keys until you visualise P005; 2. Confi rm by pressing on the key; 3. When the symbol “ ” appears, press on any key of the transmitter you want to memo- rize;...
  • Page 14: Advanced Programming

    8 ADVANCED PROGRAMMING Below fi nd the description of some programming procedures relative to the management of the radio-commands memory and advan- ced confi guration of the command inputs. To access the control unit advanced programming functions, remove the Jumper J4 from the board. Use the keys to go to P005 and hold the key down for 5 seconds (at this point, all of the parameters are visible and can be modifi...
  • Page 15: Adjustment Of Operating Parameters

    ! IMPORTANT ! 3 Selection operating with or without encoder 1. Scroll down the parameters with keys until you visua- lise P029; 2. Access the parameter by pressing the key; 3. Acting on keys, set: - d001 = 1 channel encoder; - d002 = 2 channel encoder;...
  • Page 16: Restoring Default Parameters

    7 Restoring default parameters WARNING At the end of the procedure, the display will be blocked on fl ashing “ ” and motor stroke learning must be carried out again before any other operation can be carried out. 7.1 Restoring operating parameters 1.
  • Page 17 8.2 Unlocking access to programming 1. Scroll through the parameters with the buttons until the display shows P008; 2. Access the parameter by pressing the button 3. The display shows alternately the writing to indicate that the control board is waiting for the transmission of the unlocking code;...
  • Page 18: Inputs Confi Guration

    9 Downloading/uploading data memory 9.1 Downloading data to an external memory unit (DOWNLOAD) 1. Scroll down the parameters with keys until you visualize P011; 2. Press the key, the display visualizes the word “ ” fl ashing; 3. Press the again and continue pressing it for 5 sec (if you release it before this period, the procedure is stopped);...
  • Page 19: Messages Shown On The Display

    9 MESSAGES SHOWN ON THE DISPLAY WORKING STATUS MESSAGES Mess. Description Gate is closed Gate is opened Opening under way Closing under way While in step-by-step mode, the control board awaits further instructions after a start command Stop input intervened or an obstacle is detected with limited inversion duration (P055 > 0 or P056 > 0) Board in BOOT-MODE: Indicates that the fi...
  • Page 20: Instructions For The User

    EN 12445, which establishes the testing methods for gate automation units. DEA System would like to emphasize that any system installation, cleaning or repair operations must only be carried out by qualifi ed personnel, who must conduct all the tests necessary based on the risks present;...
  • Page 21: Product Disposal

    12 PRODUCT DISPOSAL DISASSEMBLY The automation unit must be dismantled by qualifi ed personnel, in accordance with the current accident prevention and safety regulations, and with reference to the installation instructions, but in the reverse order. Before initiating the disassembly operations, disconnect the electrical power and make sure it cannot be reconnected.
  • Page 22 PROGRAMMING PROCEDURES INPUTS CONFIGURATION PARAMETERS...
  • Page 23 OPERATORS INPUTS CONFIGURATION PARAMETERS CONFIGURATION OPERATING PARAMETERS PARAMETERS...
  • Page 24 OPERATING PARAMETERS...
  • Page 25 OPERATING PARAMETERS...
  • Page 26 OPERATING PARAMETERS...
  • Page 27 Esempio di installazion tipica - Example of typical installation - Exemple d’installation typique - Installationsbeispiel - Ejemplo de insta- lación típica - Exemplo de instalação típica - Przyład standardowego systemu automatyzacji - Пример типового монтажа DEA System fornisce queste indicazioni che si possono ritenere valide per un im- System facilita estas indicaciones que pueden considerarse válidas para una pianto tipo ma che non possono essere complete.
  • Page 28 min. U max Cod. U max AB15 2576 3178 AB16 2776 3378 AB20 4178 3576 Motor...
  • Page 29 0,5 cm Motor Motor 180° Standard Not Standard...
  • Page 30 2x selflocking 2x screws nuts M8 M8x20 2x screws M8x20 2x nuts M8 2x screws M5x6 2x screws M8x16 1x Ø11xØ8,25x4 1x nut M8 1x screw 1x screw M8x20 M8x20 1x nut M8...
  • Page 32 Art. 240E (cod. 179006) Max PG13,5 min 1,5m Max PG13,5 H05VV-F 2x0,75mm...
  • Page 33 Tabella “ACCESSORI PRODOTTO”, Table “PRODUCT ACCESSORIES”, Tableau “ACCESSOIRES PRODUITS”, Tabelle „PRODUKTZU- BEHÖR”, Tabla “ACCESORIOS PRODUCTO”, Tabela “ACESSÓRIOS DO PRODUTO”, Tabela “AKCESORIA DODATKOWE”, Таблица “АКСЕССУАРЫ ИЗДЕЛИЯ”. Descrizione, Description, Description, Article Beschreibung, Descripción, Descrição, Opis Code 721/AB Sblocco base - Basic release - Déblocage base - Bowdenzug Standard - Desbloqueo base - Desbloqueio base - Odblokowanie podstawy - Базовая...
  • Page 34 Antenna supplementare per SPACE - Additional antenna for SPACE - Antenne 240E supplémentaire pour SPACE - Zusatzantenne für SPACE - Antena suplementaria para SPACE - Antena suplementare para SPACE - Dodatkowa antena dla SPACE - 179006 Дополнительная антенна для SPACE 1,6 m AB16 636090...
  • Page 35: Safety Rules

    The only operation the user can and must do is to remove any obstacle hindering the door or ADVANCE opera- tor travel range. Warning! Always disconnect the power supply whenever performing operations on the gate! DEA SYSTEM S.p.A. Via Della Tecnica, 6 - 36013 PIOVENE ROCCHETTE (VI) - ITALY tel: +39 0445 550789 - fax: +39 0445 550265 Internet: http:\\www.deasystem.com - E-mail: deasystem@deasystem.com...
  • Page 38 BATCH DEA SYSTEM S.p.A. Via Della Tecnica, 6 - 36013 PIOVENE ROCCHETTE (VI) - ITALY tel: +39 0445 550789 - fax: +39 0445 550265 Internet: http:\\www.deasystem.com - E-mail: deasystem@deasystem.com...
