THE STANDING DESK THE KLOUD Assembly Instructions Manual

Flexi lift table
Hide thumbs

Advertisement

Quick Links

Download this manual
THE KLOUD
THE
FLEXI LIFT TABLE
STANDING
ASSEMBLY INSTRUCTIONS
DESK
CAUTION: It is important to read these instructions thoroughly before assembly to avoid potential risk and
injury. Familiarize yourself with the inventory of parts and the accompanying illustrations to assure safe and
proper assembly.
FOR VIDEO INSTALL INSTRUCTIONS GO TO TheStandingDesk.com/install
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the THE KLOUD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for THE STANDING DESK THE KLOUD

Summary of Contents for THE STANDING DESK THE KLOUD

  • Page 1 THE KLOUD FLEXI LIFT TABLE STANDING ASSEMBLY INSTRUCTIONS DESK CAUTION: It is important to read these instructions thoroughly before assembly to avoid potential risk and injury. Familiarize yourself with the inventory of parts and the accompanying illustrations to assure safe and proper assembly.

  • Page 2: Important Safety Information

    SAFETY INFORMATION Thank you for choosing The Kloud, a high-performance 2 column lift base. It has been manufactured with care and precision and it has passed numerous quality and safety checks to ensure trouble-free and safe operation. You can be assured of lasting satisfaction with your Kloud model.

  • Page 3: Cleaning Recommendation

    THE KLOUD FLEXI LIFT TABLE STANDING ASSEMBLY INSTRUCTIONS DESK CLEANING RECOMMENDATION Cleaning recommendations for powder-coated surfaces For optimal care and cleaning of powder-coated surfaces the recommendations below should be followed: • Use only a soft cloth or industrial cotton wool. Refrain from rubbing hard.

  • Page 4: Tools/ Accessories

    THE KLOUD FLEXI LIFT TABLE STANDING ASSEMBLY INSTRUCTIONS DESK Place work surface on floor. Set table base assembly on top of work surface. TOOLS/ Remove packaging wrap once the frame is placed on the work surface ACCESSORIES CAUTION: Never activate the manual release before the table is completely assembled and standing properly on the floor.
  • Page 5 THE KLOUD FLEXI LIFT TABLE STANDING ASSEMBLY INSTRUCTIONS DESK Move table base to rear of the work surface and slightly overhang the TOOLS/ table frame to remove the cover. Gently rotate the cover to allow the ACCESSORIES tabs to drop out of frame.
  • Page 6 THE KLOUD FLEXI LIFT TABLE STANDING ASSEMBLY INSTRUCTIONS DESK Replace cover by securing cover tabs into table frame. Gently rotate the TOOLS/ cover back into the flat position. ACCESSORIES Move table base into position on work surface. Secure base to work TOOLS/ surface with screws.
  • Page 7 THE KLOUD FLEXI LIFT TABLE STANDING ASSEMBLY INSTRUCTIONS DESK Attach cover using 8-12 xmas tree fasteners depending on frame size. TOOLS/ ACCESSORIES xmas tree fastener 8x - 12x Install tube caps. TOOLS/ ACCESSORIES End cap FOR VIDEO INSTALL INSTRUCTIONS GO TO TheStandingDesk.com/install...
  • Page 8 THE KLOUD FLEXI LIFT TABLE STANDING ASSEMBLY INSTRUCTIONS DESK Install handle to work surface with screws. Attach Bowden Cord with TOOLS/ Bowden Cord Clip to work surface. ACCESSORIES Bowden Cord Clip Attach feet with bolts. Use the single counter sunk bolt in the threaded TOOLS/ nut position on the leg as shown.
  • Page 9 THE KLOUD FLEXI LIFT TABLE STANDING ASSEMBLY INSTRUCTIONS DESK Install glides by screwing them in clockwise and adjusting TOOLS/ with wrench. (OPTION - Install locking casters in the front of ACCESSORIES table and non-locking casters in rear of table with wrench.) Glides 1/2”...
  • Page 10 THE KLOUD FLEXI LIFT TABLE STANDING ASSEMBLY INSTRUCTIONS DESK Add intended weight load while desk is in fixed position. TOOLS/ ACCESSORIES Remove pin from each column. TOOLS/ ACCESSORIES If pin is stuck, apply light downward pressure to the table top.
  • Page 11 THE KLOUD FLEXI LIFT TABLE STANDING ASSEMBLY INSTRUCTIONS DESK Using the ratchet wrench or manual driver with the l0mm hex bit, adjust TOOLS/ the pneumatic force by turning the hex adjustment found on the side, next ACCESSORIES to the gauge.
  • Page 12 THE KLOUD FLEXI LIFT TABLE STANDING ASSEMBLY INSTRUCTIONS DESK Lightly press one hand onto the tabletop and activate the lever with the TOOLS/ other hand until the table is at the desired height. ACCESSORIES REFERENCE Work surface mount hole diagram.
  • Page 13 THE KLOUD FLEXI LIFT TABLE STANDING ASSEMBLY INSTRUCTIONS DESK 500 mm Extension FOR VIDEO INSTALL INSTRUCTIONS GO TO TheStandingDesk.com/install...
