miniDSP DDRC-88A Firmware Update Procedures page 9

d. Click on the Import Firmware Image button and select the miniDSP_2x8_8x8_v2.10_release.hex file in
the firmware folder of the download.
You must select the correct firmware file. Check the file name carefully.
e. Click on the Erase/Program/Verify Device button. The status bar will indicate progress. Do not
disconnect the USB cable or remove power from the processor while this runs!
f. After the status indicates that the verify has completed successfully, click on the Reset Device button,
and then quit the upgrade utility.
g. Return to the MiniDSP-8x8-IO utility. (If there is a dialog informing "Connection to DSP closed," click on
OK.) Click on the Connect button. It will change to a green tick.
6. Click on "Load Factory Default to the Board." At the warning, click Yes.
7. When the completion message below displays, click on OK and then quit the program.
8. Click on the About button to confirm the new firmware version.
9. You can now uninstall the MiniDSP-8x8-IO program, as it is no longer needed. Locate it in the
Applications/MiniDSP folder and drag it to the Trash.
