O r d e r i n g I n f o r m a t i o n
Description
ADX200
1 rack (height) unit, for mounting in ETSI/19" rack
Without interface cards
With 4 interface cards
ADX201
2 rack (height) units, for mounting in ETSI/19" rack
Without interface cards
With 8 interface cards
Accessories
Blank faceplate
Interface card with LSA-PLUS
Horizontal cable management tray
Specifications
PhysICAl DEsIgN
Modular design includes:
• STM-1 module
• ADX200 19" version 1 RU (HE) for four interface cards, 32 E1s
• ADX201 19" version 2 RU (HE) for eight interface cards, 64 E1s
• Hot pluggable interface cards, with eight E1 interfaces each. Interface card for unshielded twisted pair,
using LSA-PLUS
connection technology
®
• Up to two STM-1 interface (optical or electrical) using small-form-factor pluggable (SFP)
size:
19" 1RU (HE) and 2RU (HE)
Weight:
2 kg
Power:
Power-over-Ethernet (PoE), 802.3af, < 14 Watt, DC 48V and redundant
power supply via external converter
slots:
Two SFPs, eight interface cards (2RU) and four interface cards (1RU)
ENvIRONmENTAl
Operations:
ETS300-019-2-3 class 3.1
storage:
ETS300-019-2-1 class 1.2
Transport:
ETS300-019-2-2 class 2.3
Interfaces:
64x E1, multiple mapping schemes are supported including 2Mbps framed,
2Mbps unframed, (2) STM-1, optical (IR/SR/LR) and electrical via SFP modules
Protection:
1+1 MSP
Reliability:
MTBF > 30 years.
management:
Web-based integrated craft interface (ICI) including the support of smart default settings
IP based management
Local management access via 10/100BaseT interface
SNMP with trap messages supported
Non-volatile software and database stores including back-up and restore
Timing:
E1 and line timing (Timing Marker) support
Integrated SDH equipment slave clock (SEC) according to ITU G.813
Re-timing option on the E1 interfaces
standards:
In compliance with the ITU, ETSI, IEC, IEEE, IETF standards for E1 and SDH equipment
Web Site: www.adc.com
From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080
Fax: +1-952-917-3237 • For a listing of ADC's global sales office locations, please refer to our Web site.
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may
verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products or features
contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
102189AE 7/06 Original © 2006 ADC Telecommunications, Inc. All Rights Reserved
connector
®
Catalogue Number
ADX-7077 2 018-00
ADX-7077 2 017-00
ADX-7077 2 020-00
ADX-7077 2 019-00
ADX-7077 2 010-01
ADX-7077 2 016-00
6527 1 006-01
