Gsm mobile switching center
Table of Contents

Advertisement

Product Highlights:
Call forwarding (conditional, unconditional),
call waiting, call hold, call transfer
Calling party based routing, intelligent
call routing
Caller ID, CLIR/CLIP
E.164 support
Call intercept
Dual processor redundancy
DTMF tones
Generates GSM & CAMEL compliant
CDR records

Specifications

Interface Capacity:
Busy Hour Call Attempts:
E1 Ports:
Trunk Groups:
KEy MSC FEATuRES
HLR Capacity:
VLR Capacity:
SS7 LinkSets:
Redundancy:
InTERFACES
BSC Link:
PSTn:
Operations and Maintenance Link: Ethernet; SNMP based
Transmission:
Ethernet:
POwER SuPPLy
Input Voltage:
Power Consumption:
MECHAnICAL
Rack Mount:
Dimensions (wxDxH):
weight:

OPERATInG EnVIROnMEnT

Temperature:
Humidity (non-condensing):
Notes: 1. Grade of Service at trunk interface 2. With protocol converter
Website: www.adc.com
From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080
Fax: +1-952-917-3237 • For a listing of ADC's global sales office locations, please refer to our website.
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may
verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products or features
contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
106410AE 6/08 Original © 2008 ADC Telecommunications, Inc. All Rights Reserved
MAP-C, MAP-D, MAP-E
GTT translations, STP functionality
Support for SMS (MT/MO)
Implicit IMSI detach and VLR purge
GPRS support (Gr over SS7)
Optional built-in IN prepaid functions
(CAMEL based SSF)
Optional built-in SMSC, AuC
and EIR functions
Optional voicemail and external short message
entity platforms
900 Erlangs @ 0.1% GoS and 25 mErlang per subscriber
80,000 total
64 (32 + 32)
256
40,000
40,000
32
Traffic load sharing route redundancy
GSM Compliant A Interface; GSM Spec. 04.08, 08.08; ANSI 1992
CCITT 1988, 1992; BSSMAP, GSM 08.08 DTAP, GSM 04.07, 04.08,
SCCP & MTP GSM spec 08.06
ITU ISUP, ITU ISDN PRI, R2 MFC
Eight Port G7.03 compliant E1 75/120 Ohm; eight compliant T1 100 Ohm
10/100 Mbps Ethernet, RJ-45 connector
-48 VDC
85 Watts (32 + 32 ports)
19" rack mounted; cabinet optional
48.3 x 35.5 x 26.7 cm (19 x 14 x 10.5 inches)
16.7 kg (37 lbs)
10° to 45° C (50° to 113° F)
40% to 80%
1
, CAMEL Phase II/III
2
