Summary of Contents for Foster S-DD2-L FLUSH TOP
- Page 1 S-DD2-L FLUSH TOP GHOST 2451 946 *** BEFORE INSTALLATION *** ENSURE THERE IS NO VISIBLE OR HIDDEN DAMAGE SUSTAINED DURING SHIPPING *** SHIPPING DAMAGE *** MUST BE REPORTED WITHIN 5 DAYS OF RECEIPT...
- Page 3 IMAGES SU-DD2...
- Page 4 Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 SU-DD2...
- Page 5 Fig. 7 Fig. 8 Fig. 9 Fig. 10 Fig. 11 Fig. 12 SU-DD2...
- Page 6 Fig. 13 SU-DD2...
-
Page 7: Table Of Contents
CONTENTS DESCRIPTION OF THE APPLIANCE ..................11 INSTALLING THE HOOD .......................12 Grease filter removal, mounting the activated charcoal filter ..........14 Electrical connection of the hood ..................15 HOW THE COOKER HOOD WORKS ..................16 CLEANING THE COOKER HOOD ..................18 OPERATIONAL ANOMALIES ....................19 AFTER SALES SERVICE ......................19 GUARANTEE .........................20 SU-DD2... - Page 8 WA RN IN G Thank you for purchasing a Foster Range Hood. Please read all the instructions in this manual before instal- ling the appliance. Save these instructions for future reference. Only use this appliance as an exhaust ventilation system for the removal of cooking vapors.
- Page 9 TO THE ATTENTION ● It is not allowed to cook food over open flames (flambé) or operate gas hobs without pots or pans OF THE USER on them under the hood itself (the flames sucked into the hood might damage the appliance). ●...
- Page 10 TO THE ATTENTION ● It is not allowed to cook food over open flames (flambé) or operate gas hobs without pots or pans OF THE USER on them under the hood itself (the flames sucked into the hood might damage the appliance). ●...
-
Page 11: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE SU-DD2... -
Page 12: Installing The Hood
INSTALLING THE Fix the downdraft inside the cabinet, using the special fixing brackets supplied with the pro- COOKER HOOD duct (Fig. 3). Insert the brackets in the lower side of the downdraft (Fig. 3), in such a way that there is a 2 mm distance between the lower side of Before carrying out the appliance installation, bracket and the bottom of the cabinet (Fig. - Page 13 After choosing the hole for the power cable Once the installation is complete and after entry, open the hole by removing the metal connecting the appliance to the mains power, material with a tool. lift up the downdraft and remove the door block (Fig.
-
Page 14: Grease Filter Removal, Mounting The Activated Charcoal Filter
HOW TO USE THE COOKER HOOD Filtering mode This appliance is intended to suck cooking fumes, In case fumes and vapour cannot be evacuated greases and steam. It has been designed to work outside, the appliance can be used in the filtering in both suctioning mode, with outside evacuation, mode. -
Page 15: Electrical Connection Of The Hood
ELECTRICAL CONNECTION WARNING OF THE COOKER HOOD The downdraft connection to the electrical network must be carried out only by profes- sional and qualified technicians. The downdraft must be connected to a pro- WARNING perly installed and suitable electrical network. The electrical system must comply with Place the metal box containing the electronic VDE0100 standard. -
Page 16: How The Cooker Hood Works
HOW THE COOKER Timer HOOD WORKS 10 min after setting, it serves to stop the extractor motor, close the carriage and switch the lights off, if they are on. The set function is signalled by the flashing LEDs “D” for the set speed. The timer can MODEL SDD2-L GLASS VERSION be cancelled by pressing the key again. - Page 17 Security system: If there is an obstacle while the extractable unit is closing, the Downdraft stops closing and rises again thanks to a security system. WARNING This operation has to be carried out by a specialized technician. SU-DD2...
-
Page 18: Cleaning The Cooker Hood
CLEANING THE COOKER HOOD Careful maintenance ensures proper operation and good performances over time. CAUTION The hood must be disconnected from the electrical network, both by unplugging the appliance from the socket and activating the magnetic circuit breaker (safety cut-out), before removing the metal grease filters. -
Page 19: Operational Anomalies
OPERATIONAL ANOMALIES PROBLEM SOLUTION Check that: ● There is not a power outage. ● A specific speed has actually been selected. ● The 9 pole connection is inserted properly. The cooker hood ● The red reset key, found over the electrical system box, is pushed. does not work... -
Page 20: Guarantee
GENERAL CONDITIONS OF GUARANTEE WHAT IS COVERED: FOSTER guarantees its products for a period of 24 months from the date of original purchase by final customer, in both EU countries and countries outside the EU where recognized. The purchase must be verified with a valid receipt issued by the dealer (receipt, invoice or delivery note) that identifies the pur- chased product, date of purchase and / or delivery of the same. - Page 21 Once the warrantee time has elapsed, the warranty becomes void and assistance will be made by debiting the cost of the replaced parts, and the costs of labour and transportation, according to the rates in force. Authorized technicians will be sent in due time by FOSTER, with the desire of offering the best service available.
- Page 22 SU-DD2...
- Page 23 SU-DD2...
