Shadow-Caster SCM-DL–GW Quick Start Manual

SCM-DL–GW
Great White
Down Light

Specs:

Power consumption: 4 watts, 250mA at 12V,
125mw at 24V

Features:

Brightness control: Control intensity with standard on/off
switch.

Installation Instruction:

Drill 1-1/4" hole
Mount the retainer ring with the three screws provided
Connect the wiring
Put a 1/8" size ball of silicone sealant over each screw head
Gently push the light housing onto the retaining ring and rotate
it until it drops into place
Push more firmly to seat the light into the retainer.

Operation:

When power is applied to the SCM-Down Light, the
brightness slowly ramps up to full power over 8 seconds.
If the power switch is toggled on/ off quickly within this
ramp up period, this will program this brightness level
until the light is reset. To reset the light, turn the
lights off for 10 seconds.
