- Page 1 Kofferträger / Side carrier festverschraubt / firmly bolted BMW G 310 GS 2017-2019 Artikel Nr.: / Item-no.: 6507 00 01 schwarz/black Baubreite des Kofferträgers 47 cm Width of the side carrier 47 cm Kombinierbar mit Easy-/Alurack Combinable with Easy-/Alurack...
- Page 2 8x U-Scheibe Ø6,4 1x Self lock nut M8 8x washer Ø6,4 2x Kabelbinder klein 1x Mutter M8 2x Cable ties 1x Nut M8 1x Selbstsichernde Bundmutter M8 1x Self lock collar nut M8 BENÖTIGTE WERKZEUGE TOOLS REQUIRED 6536507 00 01...
- Page 3 8 screws under the passenger seat. Take off the coverings. Now loosen the screw connection of the turn signals and pull them out as far back as possible. To do this, remove the cable ties in the rear section. Screws, nuts and washers are reused. Now reassemble all fairing parts. 6536507 00 01...
- Page 4 U- Scheiben und Muttern. Die Blinkerkabel mit den Kabelbindern am Halter fixieren. Installation of the indicators right/left: Mounted on the pre-assembled indicator holder with the original screws, washers and nuts. Fix the turn signal cables to the holder with the cable ties. 6536507 00 01...
- Page 5 Insert the allen screw M8x60 with was- her ø8,4 from above through the free hole of the pillion footrest and secure it with the nut M8. Tighten nut only so far that the footrest can still be folded. 6536507 00 01...
- Page 6 Die Montage erfolgt zwischen den Trägern mit den Sechskantschrauben M6x16 sowie U-Scheiben Ø6,4. Kunststoffkappen aufsetzen. Fastening of the bracing bow right/left: Between the carriers with hexagon screws M6x16 and washers Ø6,4. Cover the screws with caps M6. 6536507 00 01...
- Page 7 Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage. Hepco & Becker GmbH Tel.: +49 (0)6331 - 1453 - 100 An der Steinmauer 6 Fax: +49 (0)6331 - 1453 - 120 D-66955 Pirmasens eMail: vertrieb@hepco-becker.de Germany www.hepco-becker.de 6536507 00 01...
