NOTE TO USERS
A
DDITIONAL
™
PXI -1000B

Replacing the Power Supply Fuse (AC-Only Chassis)

natinst.com ™ and PXI ™ are trademarks of National Instruments Corporation. Product and company names mentioned herein are trademarks
or trade names of their respective companies.
322512B-01
I
NFORMATION ABOUT
The following information was compiled after publication of the
PXI-1000B User Manual. Please read this note carefully and refer to it in
conjunction with your PXI-1000B User Manual.
The PXI-1000B AC-only chassis has a fuse inside the power supply
module for additional protection beyond the external AC mains circuit
breaker. Complete the following steps to replace the 250 V, 12 A NB
(normal blow) fuse, as shown in Figure 1:
1.
Turn the power switch to the Standby position.
2.
Disconnect the AC line cord.
3.
Loosen the six captive screws in the back of the chassis, as shown in
Figure 2.
4.
Grasp the handles of the power supply module and remove it from the
back of the chassis.
5.
Replace the fuse.
6.
Reinstall the power supply module in the chassis.
7.
Tighten the six captive screws.
8.
Reconnect the AC line cord.
© Copyright 1999 National Instruments Corp. All rights reserved.
Y
OUR
July 1999
